Porsche Cayenne GTS II (2010-2014) front passenger's door central lock safe led Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door central lock safe led, which is found in the car Porsche Cayenne GTS II (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door central lock safe led (1 of 1)
A/C COMPRESSOR VALVE +
ANTI-DAZZLE INTERIOR MIRROR
BRAKE BOOSTER
BRAKE FLUID SENSOR
BRN WIRE
CAN DISTRIBUTOR
CLUTCH SENSOR
DC/DC CONVERTER 1
DIAGNOSTIC PLUG SOCKET
DRIVER DOOR LOCK
DRIVER'S DOOR CENTRAL LOCK SAFE LED
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR OUTER DOOR HANDLE SWITCH
FRONT CAMERA CONTROL UNIT
FRONT CAMERA WINDOW HEATING
FRONT PASSENGER'S DOOR CENTRAL LOCK SAFE LED
FRONT PASSENGER'S DOOR CONTROL UNIT
FRONT PASSENGER'S DOOR LOCK
FRONT PASSENGER'S DOOR OUTER DOOR HANDLE SWITCH
FRONT PASSENGER'S FOOTWELL PLUG SOCKET
GATEWAY CONTROL UNIT
GLASS ROOF BLIND MOTOR
GLASS ROOF I MOTOR
GP-20
GP-21 (LEFT KICK PANEL)
GP-FSH LL
GP-FSH RE
HEATED WINDSCREEN
HOMELINK CONTROL UNIT
LEFT FRONT FOOTWELL LIGHT
M/T
PARK ASSIST CONTROL UNIT
RAIN SENSOR
REAR CENTER CONSOLE PLUG SOCKET 2
RIGHT FRONT FOOTWELL LIGHT
ROOF CONSOLE
ROTARY LIGHT SWITCH
SLIDING ROOF DRIVE
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN SWITCHING MODULE
STOPLIGHT SWITCH
TO GROUND GP-22 (DIAGRAM 4 OF 6)
W/ CAMERA W/O CAMERA
WHT WIRE
Go to component: -> Ground distribution circuit (3 of 6) -> FRONT PASSENGER'S DOOR CENTRAL LOCK SAFE LED
