Porsche Cayenne GTS II (2010-2014) driver door mirror Wiring diagrams

AMBIENT LIGHTING BLK WIRE BLK/RED WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/GRY WIRE BUT 1,2,OFF CAN HIGH CAN LOW CEN LK OUTTER DR HANDLE COMPUTER DATA LINES SYSTEM COURTESY LIGHT DR WARNING LIGHT DRIVER DOOR MIRROR DRIVER'S DOOR BUTTON MODULE DRIVER'S DOOR CENTRAL LOCK SAFE LED DRIVER'S DOOR CONTROL UNIT DRIVER'S DOOR GUARD LIGHT DRIVER'S DOOR INNER DOOR HANDLE LIGHTING DRIVER'S DOOR MEMORY BUTTON MODULE DRIVER'S DOOR ODDMENTS TRAY LIGHTING DRIVER'S DOOR PANEL LIGHTING DRIVER'S OUTER DOOR HANDLE SWITCH FRONT PASSENGER'S DOOR CONTROL UNIT FRONT PASSENGER'S DOOR GUARD LIGHT FRONT PASSENGER'S DOOR ODDMENTS TRAY LIGHTING FRONT PASSENGER'S DOOR PANEL LIGHTING FRONT PASSENGER'S INNER DOOR HANDLE LIGHTING FRONT PASSENGER'S OUTER DOOR HANDLE SWITCH FUSE 10 FUSE 11 GP-20 GP-21 GP-23 GRN WIRE GRN/VIO WIRE GRY WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LANE CHANGE ASSISTANT SLAVE MEM OFF FUNCT DISPLAY MEM SET FUNCT DISPLAY ODDMENTS TRAY LIGHTING PACKAGE TRAY SWITCH PASSENGER DOOR MIRROR PASSENGER DOOR POWER WINDOW BUTTON PASSENGER'S DOOR MEMORY BUTTON MODULE REAR LUGGAGE COMPARTMENT LIGHT RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FUSE BOX RIGHT REAR DOOR ASHTRAY LIGHT SET BUT SIG SWA LED, DS+ SWA LED, PS+ SWA LED- TERM 31 VIO WIRE VIO/GRN WIRE VIO/RED WIRE W/ MEMORY WHT WIRE YEL WIRE YEL/GRY WIRE YEL/WHT WIRE

BRN WIRE BRN/GRY WIRE BUTTON CAN HIGH 1 CAN HIGH 2 CAN LOW 1 CAN LOW 2 COMPUTER DATA LINES SYSTEM DRIVER DOOR MIRROR DRIVER'S DOOR BUTTON MODULE FUN LED FUNCTION IND SWA FUSE 46 GP-41 HOT W/ TERMINAL 15 RELAY ENERGIZED LANE CHANGE ASSISTANT MASTER LANE CHANGE ASSISTANT SLAVE LEFT FUSE BOX ORG/BLU WIRE ORG/BRN WIRE PASSENGER DOOR MIRROR SWA BUTTON SWA LED, DS+ SWA LED, PS+ SWA LED- TERM 15 TERM 31 VIO/BLK WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE YEL/RED WIRE

AUTO ANTI-DAZZLING MIRROR CIRCUIT BLK WIRE BRN WIRE BRN/GRY WIRE BRN/VIO WIRE CAMERA GROUND CAMERA OUTPUT CAMERA SHIELD CAMERA SUPPLY CHANGEOVER SWITCH COURTESY LIGHT DRIVER DOOR CONTROL UNIT DRIVER DOOR MIRROR DRIVER'S DOOR BUTTON MODULE EC MIRROR FUSE 16 GRY WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT FUSE BOX LEFT LANE CHANGE ASSISTANT MIRROR ADJUSTMENT MIRROR FOLDING 1 MIRROR FOLDING 2 MIRROR HEATING MOTOR 1 MOTOR 1/2 MOTOR 2 PASSENGER DOOR CONTROL UNIT PASSENGER DOOR MIRROR POTENTIOMETER POTI ENGINE 1 POTI ENGINE 2 RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT LANE CHANGE ASSISTANT SWA LED, PS+ SWA LED- TERM 31 VIO WIRE VIO/BLK WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE YEL/VIO WIRE YEL/WHT WIRE
