Porsche Cayenne GTS II (2010-2014) adjustment back Wiring diagrams
This page contains all the electrical diagrams for the component. adjustment back, in which he is found in the car Porsche Cayenne GTS II (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram adjustment back (1 of 2)
ADJUST BACK
ADJUST FWD
ADJUSTMENT BACK
ADJUSTMENT FWD
AFT ADJ 1
AFT ADJ 2
ANGLE ADJ 1
ANGLE ADJ 2
BACKREST ADJ 1
BACKREST ADJ 2
BLU WIRE
BRN WIRE
DRIVER SEAT ADJUSTMENT OPTICAL CONTROL UNIT
DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR
FUSE 1
GRN WIRE
GRY WIRE
HEIGHT ADJ 1
HEIGHT ADJ 2
HOT W/
LEFT FUSE BOX
PIPE FRAME SERVO MOTOR
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY ENERGIZED
SEAT FRT HIGH
SEAT FRT LOW
SEAT REAR HIGH
SEAT REAR LOW
TERMINAL 30
TERMINAL 31
VIO WIRE
Go to component -> Driver power seat circuit -> ADJUSTMENT BACK
Wiring diagram adjustment back (2 of 2)
ADJUST BACK
ADJUST FWD
ADJUSTMENT BACK
ADJUSTMENT FWD
AFT ADJ 1
AFT ADJ 2
ANGLE ADJ 1
ANGLE ADJ 2
BACKREST ADJ 1
BACKREST ADJ 2
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ADJUSTMENT OPTICAL CONTROL UNIT
FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR
FUSE 20
GP-26
GRN WIRE
GRY WIRE
HEIGHT ADJ 1
HEIGHT ADJ 2
HOT W/
PIPE FRAME SERVO MOTOR
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FUSE BOX
SEAT FRT HIGH
SEAT FRT LOW
SEAT REAR HIGH
SEAT REAR LOW
TERMINAL 30
TERMINAL 31
VIO WIRE
Go to component -> Passenger power seat circuit -> ADJUSTMENT BACK
