Porsche Boxster 986 facelift (2002-2004) front lock micro switch wiring diagram
This page shows the only wiring diagram for the component.front lock micro switch, which is found in the car Porsche Boxster 986 facelift (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front lock micro switch wiring diagram (1 of 1)
ABS CONTROL UNIT
ALARM HORN
BATTERY
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CD CHANGER
DIAGNOSIS CONNECTOR EMERGENCY POWER SUPPLY RELAY
DRIVER'S DOOR LOCK UNIT
DRIVER'S ORIENTATION LIGHT
DRIVER'S POWER WINDOW MOTOR
DRIVER'S SIDE OUTSIDE MIRROR
ENGINE COMPARTMENT BLOWER
FRONT LOCK MICRO SWITCH
FRONT LUGGAGE COMPARTMENT SOLENOID
GP PSM/GP ABS (AT LEFT SIDE OF ENGINE COMPT)
HIGH BEAM FOG LIGHT
HIGH RANGE HORN DEEP RANGE HORN
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INTERMITTENT WIPER CONTROL POTENTIOMETER RAIN SENSOR CONTROL UNIT
INTERMITTENT WIPER CONTROL UNIT
LEFT FRONT SPEED SENSOR RIGHT FRONT SPEED SENSOR
LEFT HEADLIGHT ASSEMBLY
LEFT HEATED SPRAY JET
LEFT RADIATOR FAN MOTOR LOW BEAM
LEFT SIDE MARKER LIGHT
LIGHT SWITCH
LIGHT SWITCH LIGHT ASSEMBLY
LOW BEAM
MFI-DI CONTROL UNIT
NCA WIRE
POWER TOP CONTROL UNIT
PSM CONTROL UNIT
RIGHT HEADLIGHT ASSEMBLY
RIGHT SIDE MARKER LIGHT RIGHT RADIATOR FAN MOTOR
SECONDARY AIR PUMP MOTOR
SIGNAL TRANSFORMER ALARM HORN
TIPTRONIC LIFTING SWITCH
TIPTRONIC TRANSMISSION CONTROL UNIT
TRUNK ENTRAPMENT MICRO-SWITCH
TURN SIGNAL SIDE MARKER
TURN SIGNAL SIDE MARKER FOG LIGHT HIGH BEAM
W/ ANTI- JOY RIDE
W/ RAIN SENSING WIPERS
W/ RAIN SENSING WIPERS W/ RAIN SENSING WIPERS
W/O RAIN SENSING WIPERS
WINDSHIELD WIPER MOTOR
