Porsche Boxster 986 (1996-2002) tip sw lo hi int Wiring diagram
This page shows the only wiring diagram for the component.tip sw lo hi int, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tip sw lo hi int (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
FLASHER UNIT
FUSE
GRN WIRE
GRN/BLK WIRE
GRY/BLU/RED WIRE
HEADLIGHT WASHER FLUID PUMP
HEADLIGHT WASHER RELAY (RELAY SUPPORT 1)
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ACC, RUN OR START
INT OFF TIP SW LO HI INT OFF
INTER- MITTENT WIPER CONTROL RELAY (RELAY SUPPORT 1)
INTERMITTENT WIPING CONTROL MODULE (3.2L ONLY)
J/C (BS 11)
LEFT HEATED SPRAY JET
OFF
RED WIRE
RED/GRY WIRE
RIGHT HEATED SPRAY JET
SOLID STATE
SR WIPE/ WASH
TIP SW LO HI INT
TIP SW LO HI WIPE/ WASH
WASHING OFF
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
WIPE/WASH SWITCH
WIPE/WASH WASHING OFF
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Wiper/washer circuit -> TIP SW LO HI INT
