Porsche Boxster 986 (1996-2002) spoiler extend relay Wiring diagram
This page shows the only wiring diagram for the component.spoiler extend relay, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spoiler extend relay (1 of 1)
3 LEVEL COOLANT SWITCH
AIR CONDITIONING CONTROL
AIRBAG CONTROL UNIT
ALARM SIREN
AMPLIFIER
ANTI-DAZZLE INTERIOR MIRROR
ASHTRAY LIGHT
AUTOMATIC AU TEST
BLK WIRE
BRN WIRE
CIGAR LIGHTER
CONTACT UNIT
DRIVER'S SIDE AIRBAG SENSOR PASSENGER'S SIDE AIRBAG SENSOR
FOG LIGHT BACKUP LIGHT STOP LIGHT
FRESH AIR VALVE
FUEL FILTER
FUEL TANK FILLER NECK
HAZARD WARNING LIGHT SWITCH
HIGH MOUNTED STOP LIGHT
IGNITION/OXYGEN SENSOR RELAY
INFOSYSTEM DISPLAY AND CONTROL UNIT
INSIDE TEMPERATURE SENSOR
INTERMITTENT WIPER CONTROL MODULE
J/C (BS 11)
KICK DOWN SWITCH
LEFT LICENSE LIGHT
LEFT POWER WINDOW SWITCH RIGHT POWER WINDOW SWITCH
LEFT SEAT BELT SWITCH
LEFT TAIL LIGHT ASSEMBLY SIDE MARKER LIGHTS TURN SIGNAL
NAVIGATION COMPUTER
NCA WIRE
ORVR VALVE
PACKAGE TRAY SWITCH
PARKING BRAKE SWITCH
PASSENGER SIDE CHILD SEAT RECOGNITION SWITCH
PASSENGER'S DOOR LOCK MODULE
POWER TOP SWITCH
RADIO
REAR LUGGAGE COMPARTMENT SWITCH SPOILER DRIVE MOTOR COOLANT LEVEL SWITCH
RIGHT HEATED MIRROR
RIGHT HEATED SPRAY JET
RIGHT LICENSE LIGHT
RIGHT POWER SEAT SWITCH
RIGHT POWER WINDOW MOTOR
RIGHT SEAT BELT SWITCH
RIGHT SEAT HEATER CONTROL UNIT RIGHT SEAT HEATER SWITCH
RIGHT SEAT HEATING ELEMENT
RIGHT TAIL LIGHT ASSEMBLY TURN SIGNAL
SELECTOR LEVER SWITCH
SIDE MARKER LIGHTS
SPOILER EXTEND RELAY
SPOILER RETRACT RELAY A/C COMPRESSOR RELAY
STOP LIGHT BACKUP LIGHT FOG LIGHT
TELEPHONE E-BOX
TELEPHONE E-BOX SHIELD
TIPTRONIC STEERING WHEEL SWITCH
TWO-TONE HORN CONTACT
Go to component -> Ground distribution circuit (2 of 3) -> SPOILER EXTEND RELAY
