Porsche Boxster 986 (1996-2002) left tail light assembly back- up light wiring diagram
This page shows the only wiring diagram for the component.left tail light assembly back- up light, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left tail light assembly back- up light wiring diagram (1 of 1)
1 2 (6-SPEED) (5-SPEED) BACKUP LIGHT SWITCH (ON TRANSMISSION)
3 2 (5-SPEED) (6-SPEED)
A/T
ANTI-DAZZLE INTERIOR MIRROR
BACK- UP LIGHT
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
FUSE SUPPORT
HOT IN RUN OR START FUSE
J/C (BS 16/2)
LEFT TAIL LIGHT ASSEMBLY BACK- UP LIGHT
LIFTING SWITCH (ON TRANSMISSION)
M/T
MEMORY SYSTEM CONTROL UNIT
NAVIGATION COMPUTER
PARKING ASSISTANT CONTROL UNIT
RED WIRE
RIGHT TAIL LIGHT ASSEMBLY
Go to component -> Back-up lamps circuit -> LEFT TAIL LIGHT ASSEMBLY BACK- UP LIGHT
