Porsche Boxster 986 (1996-2002) infosystem display, control unit Wiring diagram
This page shows the only wiring diagram for the component.infosystem display, control unit, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram infosystem display, control unit (1 of 1)
A/C- HEATING CONTROL UNIT (CENTER OF DASH)
ABS CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT)
ABS/ABD HYDRAULIC UNIT (LEFT SIDE OF LUGGAGE COMPT)
AHVAC CONTROL UNIT
AIRBAG CONTROL UNIT (UNDER CENTER CONSOLE)
ALARM SYSTEM/CENTRAL LOCKING SYSTEM CONTROL UNIT (UNDER DRIVER'S SEAT)
AUTOMATIC AU TEST
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
DIAGNOSIS
DIAGNOSIS CONNECTOR (BELOW LEFT SIDE OF DASH)
ENGINE SPD TN SIG
FUSE
FUSE SUPPORT
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INFOSYSTEM DISPLAY, CONTROL UNIT
INSTRUMENT CLUSTER
K LEAD
MEMORY SYSTEM CONTROL UNIT
MFI, DI CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
ORG/BLK WIRE
ORG/BLU WIRE
PARKING ASSISTANT CONTROL UNIT (UNDER DRIVER'S SEAT)
RED/BLK WIRE
TIPTRONIC TRANSMISSION CONTROL UNIT (FRONT CENTER OF ENGINE COMPT)
TN-SIGNAL
VIO/GRN WIRE
W/ TRACTION CONTROL
W/O TRACTION CONTROL
Go to component -> Computer data lines -> INFOSYSTEM DISPLAY, CONTROL UNIT
