Porsche Boxster 986 (1996-2002) ground voice out dsp amp rxd a/c Wiring diagram
This page shows the only wiring diagram for the component.ground voice out dsp amp rxd a/c, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground voice out dsp amp rxd a/c (1 of 1)
6 11 INFOSYSTEM IN INFOSYSTEM OUT
ALARM CNTCT
ALARM SYSTEM/ CENTRAL LOCKING SYSTEM CONTROL UNIT (UNDER DRIVER'S SEAT)
BLK WIRE
BLK/BLU WIRE
BLK/RED/BLU WIRE
BLK/RED/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DIAGNOSIS CONNECTOR (BELOW LEFT SIDE OF DASH)
DSP AMP MICROPHONE
FUSE
FUSE SUPPORT FUSE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GROUND TERM 30
GROUND VIDEO SYNC
GROUND VOICE OUT DSP AMP RXD A/C
GRY WIRE
GRY/BLU/RED WIRE
GRY/PNK WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN OFF, ACC RUN AND START
HOT IN RUN OR START
INFOSYSTEM DISPLAY AND CONTROL UNIT
INSTRUMENT CLUSTER
J/C (BS 1)
J/C (BS 13/1)
KVA
KVA MFI+DI SPEEDO A
MICROPHONE
NAVIGATION COMPUTER
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/RED WIRE
RADIO CONTACT
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RXD
SOUND SYSTEM
SOUND SYSTEM A/C SYSTEM
SPEEDO A
TERM 30
TERM 31
TERM 31 TXD CLUSTER RXD CLUSTER
TXD
VIDEO SIG BLU WIRE
VIDEO SIG GRN WIRE
VIDEO SIG RED WIRE
VIDEO SYNC GROUND
VIO WIRE
VOICE (OUT)
WHT WIRE
YEL WIRE
Go to component -> Infosystem circuit -> GROUND VOICE OUT DSP AMP RXD A/C
