Porsche Boxster 986 (1996-2002) abs control unit or abs/asr control unit Wiring diagram
This page shows the only wiring diagram for the component.abs control unit or abs/asr control unit, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram abs control unit or abs/asr control unit (1 of 1)
2 4 (W/O MEMORY) (W/ MEMORY)
ABS CONTROL UNIT OR ABS/ASR CONTROL UNIT
ALARM HORN IR SENSOR
ALARM SYSTEM/ CENTRAL LOCKING SYSTEM CONTROL UNIT
BRN WIRE
CONVERTIBLE TOP LOCK/UNLOCK SWITCH SIGNAL TRANSFORMER
COOLING FAN 1
COOLING FAN 2
DAYTIME RUNNING LIGHT RELAY
DIAGNOSIS CONNECTOR
DRIVER'S DOOR LOCK MODULE
FLASHER
FOG LIGHT TURN SIGNAL SIDE MARKER LOW BEAM
FRONT LUGGAGE COMPARTMENT HOOD SWITCH
FUEL PUMP
HEADLIGHT WASHER FLUID PUMP HEADLIGHT WASHER RELAY
HIGH BEAM
INSIDE LIGHT
INTERMITTENT WIPER CONTROL RELAY
J/C (BS 12)
LEFT HEADLIGHT ASSEMBLY
LEFT HEATED MIRROR
LEFT HEATED SPRAY JET
LEFT MAKE-UP MIRROR
LEFT POWER SEAT SWITCH LEFT SEAT HEATER CONTROL UNIT
LEFT POWER WINDOW MOTOR
LEFT SEAT HEATER SWITCH
LEFT SIDE MARKER LIGHT
LIGHT SWITCH
LIGHT SWITCH LIGHT ASSEMBLY
LOW BEAM SIDE MARKER
MEMORY SWITCH MEMORY SYSTEM CONTROL UNIT
MIRROR ADJUSTMENT SWITCH CLUTCH INTERLOCK SWITCH
NCA WIRE
PARKING ASSISTANT CONTROL UNIT
POWER TOP RELAY
REAR WINDOW/ MIRROR DEFOGGER RELAY
RED/BRN WIRE
RIGHT HEADLIGHT ASSEMBLY
RIGHT MAKE-UP MIRROR
RIGHT SIDE MARKER LIGHT
SPOILER MANUAL OPERATION SWITCH ACTUATION HEATING RELAY
TELEPHONE PREP
TELEPHONE TRANSMITTER/ RECEIVER
TERMINAL X RELAY
TURN SIGNAL FOG LIGHT HIGH BEAM
TWO TONE HORN 1
TWO TONE HORN 2
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> ABS CONTROL UNIT OR ABS/ASR CONTROL UNIT
