Porsche Boxster 986 (1996-2002) 15 16 17 hi beam on term 15 ground sens Wiring diagram

15 16 17 HI BEAM ON TERM 15 GROUND SENS AHVAC CONTROL UNIT (RIGHT REAR OF LUGGAGE COMPARTMENT) BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE BRN/BLK WIRE DIAGNOSIS CONNECTOR (BELOW LEFT SIDE OF DASH) ESO REAR FUSE FUSE SUPPORT GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GROUND GRY WIRE HOT IN PARK OR HEAD HOT IN RUN OR START HOT W/ HIGH BEAMS ON J/C (BS 2/1) J/C (BS 5/1) LEFT AHVAC DRIVE LEFT FRONT AHVAC SENSOR MFI, DI CONTROL UNIT (LEFT SIDE OF ENGINE COMPT) ORG/BLU WIRE PNK WIRE RED/WHT WIRE RIGHT AHVAC DRIVE RIGHT FRONT AHVAC SENSOR VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE
