Porsche Boxster 986 (1996-2002) 1 2 3 4 5 6 term 15 term 31 backup sig actuation actuation Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 term 15 term 31 backup sig actuation actuation, which is found in the car Porsche Boxster 986 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 term 15 term 31 backup sig actuation actuation (1 of 1)
1 2 3 4 5 6 TERM 15 TERM 31 BACKUP SIG ACTUATION ACTUATION
A/T
ANTI DAZZLE MIRROR
ANTI-DAZZLE INTERIOR MIRROR
BACK-UP LIGHT SWITCH (ON GEAR BOX)
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BRN WIRE
FUSE HOLDER
GRN WIRE
HOT IN RUN OR START FUSE
J/C (BS 11)
J/C (BS 16/2)
J/C (BS 20)
LIFTING SWITCH (ON TRANSMISSION)
M/T
YEL WIRE
Go to component -> Auto anti-dazzling inside mirror -> 1 2 3 4 5 6 TERM 15 TERM 31 BACKUP SIG ACTUATION ACTUATION
