Porsche 911 Turbo 992 (2018-2024) turn signal light Wiring diagrams
This page contains all the electrical diagrams for the component. turn signal light, in which he is found in the car Porsche 911 Turbo 992 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram turn signal light (1 of 2)
AUTOMATIC GEARBOX CONTROL UNIT
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ENGINE/MOTOR CONTROL UNIT
EXTERIOR MIRROR ENTRY LIGHT
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 12
FUSE 14
FUSE HOLDER K
FUSE HOLDER P
GRN WIRE
GROUND
GROUND ACTUATORS/SENSORS
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HIGH-LEVEL BRAKE LIGHT BULB
HIGH-LEVEL BRAKE LIGHT BULB 2
HOT AT ALL TIMES
LEFT NUMBER PLATE LIGHT
LIGHTING
LIN 1
LUGGAGE COMPARTMENT MANUAL RELEASE BUTTON
MARKER LIGHT
NEGATIVE
ONBOARD SUPPLY CONTROL UNIT
ORG/BRN WIRE
ORG/GRN WIRE
PASS SIDE EXIT WARNING LAMP
PASSENGER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR
PASSENGER SIDE EXIT WARNING LAMP
PASSENGER SIDE EXTERIOR MIRROR ENTRY LIGHT
PASSENGER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP
POSITIVE
POWER
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
REVERSING LIGHT SWITCH
RIGHT FRONT FUSE BOX
RIGHT FRONT HEADLIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL, SIDE LIGHT
RIGHT NUMBER PLATE LIGHT
RIGHT REAR FOG LIGHT
RIGHT TAIL LIGHT CLUSTER
SIDE MARKER LIGHT
SIGNAL
STOP LIGHT
TERM 30
TERM 30 SWITCHED
TERM 31
TURN SIGNAL
TURN SIGNAL LIGHT
VIO/WHT WIRE
WARNING LIGHT EXTERIOR MIRR
WHT/VIO WIRE
Go to component -> Exterior lights circuit (2 of 2) -> TURN SIGNAL LIGHT
Wiring diagram turn signal light (2 of 2)
ADJUSTABLE REAR SPOILER CONTROL UNIT
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTER TAIL LIGHT CLUSTER
CONTINUED COOLANT CIRCULATION PUMP
ENGINE COMPARTMENT COOLING FAN
ENGINE COMPARTMENT COOLING FAN 2
ENGINE/MOTOR CONTROL UNIT 2
FRONT AXLE LIFT SYSTEM CONTROL UNIT
HEATED REAR WINDOW RELAY
HIGH-LEVEL BRAKE LIGHT BULB
HIGH-LEVEL BRAKE LIGHT BULB 2
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
LEFT NUMBER PLATE LIGHT
NCA WIRE
REAR LID CLOSED SWITCH
RIGHT NUMBER PLATE LIGHT
RIGHT REAR FOG LIGHT
RIGHT REAR INTERIOR LIGHT
RIGHT TAIL LIGHT CLUSTER
SERVOTRONIC CONTROL UNIT
SPOILER
TAILGATE RELEASE ACTUATOR
TURN SIGNAL LIGHT
VALVE BLOCK ON ENGINE
Go to component -> Ground distribution circuit (4 of 5) -> TURN SIGNAL LIGHT
