Porsche 911 Turbo 992 (2018-2024) right front seat adjustment operating unit Wiring diagrams
This page contains all the electrical diagrams for the component. right front seat adjustment operating unit, in which he is found in the car Porsche 911 Turbo 992 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front seat adjustment operating unit (1 of 5)
AIR BAG PULSE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CLASS 31 PNEUMATICS
COMPUTER DATA LINES SYSTEM
CRASH SIGNAL
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL UNIT
FRONT PASSENGER SEAT MULTI-CONTOUR COMPRESSOR
FUSE 16
FUSE HOLDER J
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LIN 2
LNV + IN
LNV BACK
LNV VOR
N/A
ORG/BRN WIRE
PUMP VERS +
RED WIRE
RED/WHT WIRE
RIGHT FRONT BACKREST ADJUSTMENT MOTOR
RIGHT FRONT FUSE BOX
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR
SHV AB
SHV AUF
SUPPLY
TERM 30
TERM 31
VIO WIRE
VIO/GRY WIRE
W/ MEMORY
W/O MEMORY
WIDTH MODULATION
Go to component -> Front passenger power seat circuit -> RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
Wiring diagram right front seat adjustment operating unit (2 of 5)
14/18-WAY SEATS
4-WAY SEATS
BRN WIRE
COUPE
DATA BUS DIAGNOSTIC INTERFACE
DRIVER SIDE AIR BAG IGNITER
DRIVER SIDE CURTAIN AIR BAG IGNITER
DRIVER SIDE ROLL-OVER PROTECTION IGNITER
FRONT PASSENGER SIDE AIR BAG IGNITER
FRONT PASSENGER SIDE CONTAIN AIR BAG IGNITER
FRONT PASSENGER'S SIDE ROLL-OVER PROTECTION IGNITER
LEFT "C" PILLAR)
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT BELT
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT EXTENSION HEATER ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATED SEAT CUSHION
LEFT REAR WINDOW REGULATOR MOTOR
REAR WHEEL STEERING CONTROL UNIT
REAR WHEEL STEERING CONTROL UNIT 2
RIGHT FRONT HEATED SEAT CUSHION
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT BACKREST FAN 1
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT CUSHION FAN 1
RIGHT FRONT SEAT EXTENSION HEATER ELEMENT
RIGHT FRONT SEAT HEATED BACKREST
RIGHT REAR WINDOW REGULATOR MOTOR
SEAT OCCUPIED RECOGNITION CONTROL UNIT
Go to component -> Ground distribution circuit (5 of 5) -> RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
Wiring diagram right front seat adjustment operating unit (3 of 5)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CODING PIN (DS-PS)
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL UNIT
FRONT PASSENGER SEAT MULTI-CONTOUR COMPRESSOR
FUSE 16
FUSE HOLDER J
GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
KL. 31 PNEUMATIK
LEFT "C" PILLAR)
LIN 2
LNV TASTER
LORD HIGH LOW
LORD NEXT PREVIOUS
N/A
ORG/GRN WIRE
PUMPE VERS +
RED WIRE
RED/WHT WIRE
RIGHT FRONT FUSE BOX
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
SHV TASTER
SLV TASTER
SNV TASTER
STV BEFORE RETURN
STV TASTER
SUPPLY
TERM 30
TERM 31
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
WANGENV L OPEN-CLOSE
WANGENV SI ON TO
YEL WIRE
Go to component -> Passenger"s memory seat circuit (1 of 2) -> RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
Wiring diagram right front seat adjustment operating unit (4 of 5)
ADAPTIVE SUSPENSION CONTROL UNIT
AIR BAG CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
AUDIO, VIDEO ADDITIONAL CONNECTIONS UNIT
BLUETOOTH MOBILE PHONE COUPLING AERIAL
CENTER CONSOLE SWITCH MODULE 1
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
FROM FUSE CARRIER 2 (DIAGRAM 3 OF 7)
FRONT PASSENGER DOOR CONTROL UNIT
FRONT ROOF MODULE
FUSE 1
FUSE 1 N/A
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16 N/A
FUSE 2
FUSE 2 N/A
FUSE 3 N/A
FUSE 4
FUSE 4 N/A
FUSE 5 N/A
FUSE 6
FUSE 6 N/A
FUSE 7
FUSE 7 N/A
FUSE 8
FUSE 8 N/A
FUSE 9
FUSE 9 N/A
FUSE HOLDER J
FUSE HOLDER K
GARAGE DOOR OPERATION CONTROL UNIT
GRY/VIO WIRE
IN REAR LOUDSPEAKER WIRING HARNESS CONNECTION (AERIAL)
MOBILE TELEPHONE AERIAL AMPLIFIER
MULTIMEDIA SYSTEM
MULTIMEDIA SYSTEM OPERATING UNIT
MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT
N/A
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT HEADLIGHT
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT BELT
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
W/ MEMORY
W/O MEMORY
WHT/BRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (4 of 7) -> RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
Wiring diagram right front seat adjustment operating unit (5 of 5)
AIR BAG CONTROL UNIT (FRONT CENTER FLOOR CONSOLE)
AIR BAG PULSE
BLK WIRE
BRN WIRE
CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH SIGNAL
DRIVER SIDE AIR BAG PRESSURE SENSOR
DRIVER SIDE AIR BAG, HEAD CRASH SENSOR B-PILLAR
DRIVER SIDE UP FRONT SENSOR
DRV DOOR PRESSURE SENSOR
DRV SIDE AIR BAG CRASH SENSOR
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
FLEXRAY INPUT 1+
FLEXRAY INPUT 2 -
FRONT PASSENGER AIR BAG, HEAD CRASH SENSOR
FRONT PASSENGER UP FRONT SENSOR
FRT PASS SIDE AIR BAG CRASH SENSOR
FRT PRESSURE SENSOR PASS DOOR
GRN WIRE
GRN/BLU WIRE
GRY WIRE
IGNITION ON
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/ WIRE
PASS UP FRONT SENSOR +
PNK WIRE
PRESSURE SENSOR
RED WIRE
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
SIGNAL
SIGNAL GROUND
TERMINAL 15
UP FRONT SENSOR DRIVER +
VIO WIRE
W/ 14/18 WAY SEATS
W/ 4-WAY SEATS
WHT WIRE
WHT/RED WIRE
WIDTH MODULATION
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
