Porsche 911 Turbo 992 (2018-2024) reversing light switch Wiring diagrams
This page contains all the electrical diagrams for the component. reversing light switch, in which he is found in the car Porsche 911 Turbo 992 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram reversing light switch (1 of 3)
AUTOMATIC GEARBOX CONTROL UNIT
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ENGINE/MOTOR CONTROL UNIT
EXTERIOR MIRROR ENTRY LIGHT
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 12
FUSE 14
FUSE HOLDER K
FUSE HOLDER P
GRN WIRE
GROUND
GROUND ACTUATORS/SENSORS
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HIGH-LEVEL BRAKE LIGHT BULB
HIGH-LEVEL BRAKE LIGHT BULB 2
HOT AT ALL TIMES
LEFT NUMBER PLATE LIGHT
LIGHTING
LIN 1
LUGGAGE COMPARTMENT MANUAL RELEASE BUTTON
MARKER LIGHT
NEGATIVE
ONBOARD SUPPLY CONTROL UNIT
ORG/BRN WIRE
ORG/GRN WIRE
PASS SIDE EXIT WARNING LAMP
PASSENGER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR
PASSENGER SIDE EXIT WARNING LAMP
PASSENGER SIDE EXTERIOR MIRROR ENTRY LIGHT
PASSENGER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP
POSITIVE
POWER
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
REVERSING LIGHT SWITCH
RIGHT FRONT FUSE BOX
RIGHT FRONT HEADLIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL, SIDE LIGHT
RIGHT NUMBER PLATE LIGHT
RIGHT REAR FOG LIGHT
RIGHT TAIL LIGHT CLUSTER
SIDE MARKER LIGHT
SIGNAL
STOP LIGHT
TERM 30
TERM 30 SWITCHED
TERM 31
TURN SIGNAL
TURN SIGNAL LIGHT
VIO/WHT WIRE
WARNING LIGHT EXTERIOR MIRR
WHT/VIO WIRE
Go to component -> Exterior lights circuit (2 of 2) -> REVERSING LIGHT SWITCH
Wiring diagram reversing light switch (2 of 3)
AERIAL, IN REAR LOUDSPEAKER WIRING HARNESS CONNECTION
AIR BAG CONTROL UNIT
AIR CONDITIONER SENSOR FOR FINE PARTICLE CONCENTRATION
AUTOMATIC GEARBOX CONTROL UNIT
AUXILIARY PUMP FOR HEATING
BLK WIRE
BRN WIRE
CENTER CONSOLE BACKGROUND LIGHTING 1
CENTER CONSOLE BACKGROUND LIGHTING 2
CENTER CONSOLE SWITCH MODULE 1
CENTER TAIL LIGHT CLUSTER
CENTRAL DASH PANEL SWITCH MODULE
CENTRAL VENT DASH PANEL ILLUMINATION
CONVERTIBLE ROOF ACTUATION CONTROL UNIT
CONVERTIBLE ROOF LOCK UNIT
DRIVER SIDE KNEE AIR BAG IGNITER
ELECTRICALLY ADJUSTABLE STEERING COLUMN CONTROL UNIT
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRONT REAR RIGHT ILLUMINATED VANITY MIRROR
FRONT ROOF MODULE
GRN WIRE
IONISER 1
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
LEFT FRONT FOOTWELL LIGHT 2
LEFT REAR BRAKE PAD WEAR SENDER
LEFT REAR INTERIOR LIGHT
LEFT TAIL LIGHT CLUSTER
MULTIMEDIA SYSTEM OPERATING UNIT
ONBOARD SUPPLY CONTROL UNIT 2
POSITIVE CONNECTION AUXILIARY HEATER WIRING HARNESS
POSITIVE CONNECTION CLIMATRONIC WIRING HARNESS
POWER UNIT MOUNTING CONTROL UNIT
REAR WINDOW HEATER
REAR WINDOW WIPER MOTOR
REVERSING LIGHT SWITCH
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
RIGHT FRONT FOOTWELL LIGHT
SELECTOR LEVER SENSORS CONTROL UNIT
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
WIND DEFLECTOR HALL SENSOR
WIND DEFLECTOR MOTOR
WINDOW DEFLECTOR CONTROL UNIT
Go to component -> Ground distribution circuit (2 of 5) -> REVERSING LIGHT SWITCH
Wiring diagram reversing light switch (3 of 3)
