Porsche 911 Turbo 992 (2018-2024) passenger's side 12 v socket Wiring diagram
This page shows the only wiring diagram for the component.passenger's side 12 v socket, which is found in the car Porsche 911 Turbo 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side 12 v socket (1 of 1)
ADJUSTABLE REAR SPOILER CONTROL UNIT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
CAN COMFORT HI
CAN COMFORT LO
COMPUTER DATA LINES SYSTEM
CONVERTIBLE ROOF ACTUATION CONTROL UNIT
DATA BUS DIAGNOSTIC INTERFACE
ELECT IGNITION LOCK SW 1
ELECT IGNITION LOCK SW 2
ELECT IGNITION LOCK SW 3
ELECT IGNITION LOCK SW 4
FROM CENTER DASH PANEL SWITCH MODULE (DIAGRAM 2 OF 7)
FROM FUSE CARRIER 3 (DIAGRAM 6 OF 7)
FROM FUSE HOLDER L (DIAGRAM 5 OF 7)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE HOLDER Q
GROUND
GRY WIRE
IGNITION, LIGHT BUTTON MODULE
LEFT REAR WINDOW REGULATOR MOTOR
LIN 1
N/A
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S SIDE 12 V SOCKET
PLUG SOCKETS OUTPUT RELAY F
POWER UNIT MOUNTING CONTROL UNIT
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY A
RELAY B
RIGHT REAR WINDOW REGULATOR MOTOR
STARTER MOTOR RELAY
SW 1
SW 2
SW 3
SW 4
TERM 30
TERM 31
VIO WIRE
VIO/WHT WIRE
WHT WIRE
Go to component -> Power distribution circuit (7 of 7) -> PASSENGER'S SIDE 12 V SOCKET
