Porsche 911 Turbo 991 facelift (2016-2020) light switch pos o Wiring diagram
This page shows the only wiring diagram for the component.light switch pos o, which is found in the car Porsche 911 Turbo 991 facelift (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light switch pos o (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FRONT BCM (LEFT END OF DASH)
FUSE 1
GRN/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT DAYTIME RUNNING LIGHT
LEFT FRONT FUSE BOX (ROW C)
LEFT HIGH BEAM
LEFT LOW BEAM
LEFT TAILLIGHT ASSEMBLY
LIGHT REDUNDANT
LIGHT SWITCH POS O
LR FOG LT
ORG/BRN WIRE
ORG/GRN WIRE
RAIN SENSOR
REAR BCM (UNDER DRIVER SEAT)
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT DAYTIME RUNNING LIGHT
RIGHT FRONT FUSE BOX (ROW B)
RIGHT HIGH BEAM
RIGHT LOW BEAM
RIGHT TAILLIGHT ASSEMBLY
RIGHT/LEFT SHUTTER LID
ROTARY LIGHT SWITCH
RR FOG LT
SHIELD
SUP PROX SENS
TERM 30
TERM 31
TERMINAL 30
TERMINAL 31
TERMINAL 31 PROX SENS
VIO WIRE
VIO/GRN WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, w/o led headlights (2 of 2) -> LIGHT SWITCH POS O
