Porsche 911 Targa 4 992 (2019-2024) tire pressure monitoring system control unit Wiring diagrams
This page contains all the electrical diagrams for the component. tire pressure monitoring system control unit, in which he is found in the car Porsche 911 Targa 4 992 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tire pressure monitoring system control unit (1 of 2)
ADAPTIVE SUSPENSION CONTROL UNIT
AIR BAG CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
AUDIO, VIDEO ADDITIONAL CONNECTIONS UNIT
BLUETOOTH MOBILE PHONE COUPLING AERIAL
CENTER CONSOLE SWITCH MODULE 1
EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT
FROM FUSE CARRIER 2 (DIAGRAM 3 OF 7)
FRONT PASSENGER DOOR CONTROL UNIT
FRONT ROOF MODULE
FUSE 1
FUSE 1 N/A
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16 N/A
FUSE 2
FUSE 2 N/A
FUSE 3 N/A
FUSE 4
FUSE 4 N/A
FUSE 5 N/A
FUSE 6
FUSE 6 N/A
FUSE 7
FUSE 7 N/A
FUSE 8
FUSE 8 N/A
FUSE 9
FUSE 9 N/A
FUSE HOLDER J
FUSE HOLDER K
GARAGE DOOR OPERATION CONTROL UNIT
GRY/VIO WIRE
IN REAR LOUDSPEAKER WIRING HARNESS CONNECTION (AERIAL)
MOBILE TELEPHONE AERIAL AMPLIFIER
MULTIMEDIA SYSTEM
MULTIMEDIA SYSTEM OPERATING UNIT
MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT
N/A
ONBOARD SUPPLY CONTROL UNIT
ONBOARD SUPPLY CONTROL UNIT 2
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT HEADLIGHT
RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT BELT
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
W/ MEMORY
W/O MEMORY
WHT/BRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (4 of 7) -> TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
Wiring diagram tire pressure monitoring system control unit (2 of 2)
Go to component -> Warning systems circuit -> TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
