Porsche 911 Targa 4 992 (2019-2024) front passenger seat occupied sensor Wiring diagram
This page shows the only wiring diagram for the component.front passenger seat occupied sensor, which is found in the car Porsche 911 Targa 4 992 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger seat occupied sensor (1 of 1)
ANALOG GROUND
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT (PWM)
DETECTION SENSOR
DISPOSAL LINE ACL (PWM)
DRIVER SEAT POSITION
DRIVER SIDE BELT SWITCH
DRIVER SIDE SEAT POSITION SENSOR
DRIVER'S BUCKLE
FRONT PASSENGER SEAT OCCUPIED SENSOR
FRT SEAT OCCUP
FRT SEAT OCCUP DETECTION SENSOR
FUSE 4
FUSE HOLDER K
GRN WIRE
GRN/BLU WIRE
GROUND
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
IGNITION ON (TERMINAL 15)
LEFT FRONT BELT SWITCH
LEFT REAR BELT SWITCH
MASSEKO SEAT PAN
NEGATIVE
PASSENGER SEAT POSITION
PASSENGER SIDE BELT SW
PASSENGER'S BUCKLE
POSITIVE
RED/BLU WIRE
RED/GRY WIRE
RIGHT FRONT FUSE BOX
RIGHT REAR BELT SWITCH
SEAT HEATING IN -
SEAT HEATING OUT +
SEAT OCCUPIED RECOGNITION CONTROL UNIT
SEATS SYSTEM
SENSOR GROUND
SHIELDING
TERM 15
TERM 87
VIO/GRN WIRE
W/ 14/18 WAY SEATS
W/ 4-WAY SEATS
WHT/VIO WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> FRONT PASSENGER SEAT OCCUPIED SENSOR
