Porsche 911 Targa 4 992 (2019-2024) center console background lighting 2 Wiring diagrams
This page contains all the electrical diagrams for the component. center console background lighting 2, in which he is found in the car Porsche 911 Targa 4 992 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram center console background lighting 2 (1 of 2)
AERIAL, IN REAR LOUDSPEAKER WIRING HARNESS CONNECTION
AIR BAG CONTROL UNIT
AIR CONDITIONER SENSOR FOR FINE PARTICLE CONCENTRATION
AUTOMATIC GEARBOX CONTROL UNIT
AUXILIARY PUMP FOR HEATING
BLK WIRE
BRN WIRE
CENTER CONSOLE BACKGROUND LIGHTING 1
CENTER CONSOLE BACKGROUND LIGHTING 2
CENTER CONSOLE SWITCH MODULE 1
CENTER TAIL LIGHT CLUSTER
CENTRAL DASH PANEL SWITCH MODULE
CENTRAL VENT DASH PANEL ILLUMINATION
CONVERTIBLE ROOF ACTUATION CONTROL UNIT
CONVERTIBLE ROOF LOCK UNIT
DRIVER SIDE KNEE AIR BAG IGNITER
ELECTRICALLY ADJUSTABLE STEERING COLUMN CONTROL UNIT
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
FRONT PASSENGER AIR BAG UNIT
FRONT PASSENGER SIDE KNEE AIR BAG IGNITER
FRONT REAR RIGHT ILLUMINATED VANITY MIRROR
FRONT ROOF MODULE
GRN WIRE
IONISER 1
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
LEFT FRONT FOOTWELL LIGHT 2
LEFT REAR BRAKE PAD WEAR SENDER
LEFT REAR INTERIOR LIGHT
LEFT TAIL LIGHT CLUSTER
MULTIMEDIA SYSTEM OPERATING UNIT
ONBOARD SUPPLY CONTROL UNIT 2
POSITIVE CONNECTION AUXILIARY HEATER WIRING HARNESS
POSITIVE CONNECTION CLIMATRONIC WIRING HARNESS
POWER UNIT MOUNTING CONTROL UNIT
REAR WINDOW HEATER
REAR WINDOW WIPER MOTOR
REVERSING LIGHT SWITCH
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
RIGHT FRONT FOOTWELL LIGHT
SELECTOR LEVER SENSORS CONTROL UNIT
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
WIND DEFLECTOR HALL SENSOR
WIND DEFLECTOR MOTOR
WINDOW DEFLECTOR CONTROL UNIT
Go to component -> Ground distribution circuit (2 of 5) -> CENTER CONSOLE BACKGROUND LIGHTING 2
Wiring diagram center console background lighting 2 (2 of 2)
BLK/GRN WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
CENTER CONSOLE BACKGROUND LIGHTING 1
CENTER CONSOLE BACKGROUND LIGHTING 2
GROUND
GRY WIRE
GRY/BLU WIRE
LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 1
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT FOOTWELL LIGHT 2
LEFT REAR ILLUMINATED VANITY MIRROR
LIN INPUT
LIN OUTPUT
LUGGAGE COMPARTMENT RELEASE SWITCH
POSITIVE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT FOOTWELL LIGHT 2
RIGHT REAR ILLUMINATED VANITY MIRROR
TERM 30
TERM 31
UNLOCK FRONT LID
UNLOCK REAR LID
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Interior lights circuit (2 of 4) -> CENTER CONSOLE BACKGROUND LIGHTING 2
