Porsche 911 Targa 4 991 facelift (2015-2019) wind deflector control unit Wiring diagram
This page shows the only wiring diagram for the component.wind deflector control unit, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wind deflector control unit (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CODING
COMPUTER DATA LINES SYSTEM
ES/SIGNAL
ES/VERSORGUNG
FUSE 2
FUSE 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
MAXI FUSE RELAY SUPPORT 2
NCA WIRE
NEGATIVE
PHASE A 1
PHASE A 2
PHASE B 1
PHASE B 2
POSITIVE
REAR FUSE BOX RELAY SUPPORT 2 (ROW C)
RED WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT FUSE BOX (ROW C)
ROOF BLIND GLASS MOTOR
ROOF CONSOLE
ROOF MOTOR
SHIELD
SIGNAL
SLIDING ROOF CONTROL UNIT
SUNROOF DIAGNOSIS
TERM 30
TERM 30 SUN BLIND
TERM 30 SUNROOF
TERM 31
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WIND DEFLECTOR CONTROL UNIT
WIND DEFLECTOR MOTOR
WIND DEFLECTOR SENSOR
YEL WIRE
