Porsche 911 Targa 4 991 facelift (2015-2019) two-tone horns relay Wiring diagrams

ANTI-THEFT SYSTEM BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/YEL WIRE BRAKE FLUID LEVEL BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CAN COMFORT HIGH CAN COMFORT LOW COMPUTER DATA LINES SYSTEM CRASH SIGNAL INPUT (PWM) DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS EISS ILLUMINATION ELV DRIVE LINK SPLY ENABLE TERM 15 FOOTWELL LIGHT FRONT BCM (LEFT END OF DASH) FRONT DUAL WASHER PUMP FRONT LID ACTUATING ELEMENT FRONT LID LIGHT FRONT LID MICROSWITCH FUSE 1 FUSE 2 FUSE 6 FUSE 7 GLOVE BOX MICRO SW GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HAZARD WARNING LIGHT BUTTON HEADLIGHT WASHER HEADLIGHTS SYSTEM HEADLIGHTS,EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS HORNS SYSTEM HOT AT ALL TIMES HOT W/ EMERGENCY VOLTAGE SUPPLY 1 RELAY ENERGIZED IGNITION LOCK SW 2 IGNITION LOCK SW 5 IGNITION LOCK SW 6 IGNITION SWITCH INSTRUMENT CLUSTER, ANTI-LOCK BRAKES SYSTEMS INTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM LEFT FRONT FUSE BOX (ROW B) LEFT FRONT FUSE BOX (ROW C) LF BUTTON, CLOSE LF SIDE DIRECTION IND LF SIDE MARKER LIGHT LF SPLY PROXIMITY SENSOR LF TERM 31 PROXIMITY SENSOR LF TURN SIGNAL LH HIGH BEAM LH LOW BEAM LIGHT SW POSITION 0 LIN 1 LIN 2 LIN 3 LR IND MAIN FUSE BOX ORG/BRN WIRE ORG/GRN WIRE PASS ANTENNA CONSOLE+ PASS ANTENNA LUGGAGE COMPT + PASS ANTENNA SEATS+ POWER DISTRIBUTION SYSTEM PROXIMITY SENSOR PSW/NEUTRAL SW REAR DUAL WASHER PUMP RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY TERM 50 HS RELAY TERMINAL 15 RF BUTTON, CLOSE RF LOW BEAM RF SIDE DIRECTION IND RF SPLY PROXIMITY SENSOR RF TERM 31 PROXIMITY SENSOR RF TURN SIGNAL RH HIGH BEAM RH SIDE MARKER LIGHT RL OUTER WHEEL - RR DIR IND RR OUTER WHEEL+ SENSOR GROUND SHIFT INTERLOCK SYSTEM SHUTTER LID RH/LH STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM SW 1 IGNITION LOCK SW 3 IGNITION LOCK SW 4 IGNITION LOCK TANK LID OPEN TANK LID SHUT TERM 15 TERM 15 IN RELAY DIAGNOSIS TERM 30 1 TERM 30 HEADLIGHT WASHER SYSTEM TERM 30-2 TERM 30-3 TERM 31 TERM 31 PROXIMITY SENSOR TERM 50 DIAGNOSIS TRUNK, TAILGATE, FUEL DOORS SYSTEM TWO-TONE HORNS RELAY VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/YEL WIRE WARNING LIGHT BUTTON WASHER FLUID LEVEL WHT WIRE WHT/BLK WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

A/T BRN WIRE CARD READER DSRC CENTER COCKPIT AIR VENT LIGHTING DIAGNOSTIC PLUG SOCKET DRIVER'S DOOR CENTRAL LOCK SAFE LED DRIVER'S DOOR CONTROL UNIT DRIVER'S DOOR IGNITION LOCK LIGHT DRIVER'S DOOR LOCK DRIVER'S DOOR OUTER HANDLE SWITCH E-BOX STEERING WHEEL ELECTRONIC IGNITION LOCK EMERGENCY VOLTAGE SUPPLY 1 RELAY EPB BUTTON FRONT BCM FRONT CONTROL UNIT FRONT PASSENGER DOOR CENTRAL LOCK SAFE LED FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER DOOR LOCK FRONT PASSENGER DOOR OUTER HANDLE SWITCH FRONT WIPER MOTOR GATEWAY CONTROL UNIT GLOVE COMPARTMENT SWITCH GRY WIRE HEAD AIR BAG DS ESD GROUND HEAD AIR BAG PS ESD GROUND INSTRUMENT CLUSTER KNEE AIR BAG PS ESD GROUND LEFT COCKPIT AIR VENT LIGHTING LEFT FAN RELAY LEFT FRONT FOOTWELL LIGHT LEFT REAR DOOR CONTROL UNIT M/T MAIN FUSE BOX PASSENGER AIR BAG ESD GROUND RIGHT COCKPIT AIR VENT LIGHTING RIGHT FAN RELAY RIGHT FRONT FOOTWELL LIGHT RIGHT REAR DOOR CONTROL UNIT ROTARY LIGHT SWITCH STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN LOCK STEERING COLUMN MODULE AIR BAG GROUND STEERING COLUMN SWITCHING MODULE STEERING WHEEL ELECTRONICS CONTROL UNIT STEERING WHEEL GROUND STEERING WHEEL TIPTRONIC BUTTON STOPWATCH TWO-TONE HORNS RELAY USB- HUB WHT WIRE

BLU WIRE BRN WIRE BRN/WHT WIRE CAN COMFORT HIGH CAN COMFORT LOW COMPUTER DATA LINES SYSTEM FRONT BCM (LEFT END OF DASH) FUSE 4 GRN/BLK WIRE HORN HOT AT ALL TIMES LEFT FRONT FUSE BOX (ROW C) LEFT TWO-TONE HORN LIN 1 LIN 2 LIN 3 ORG/BRN WIRE ORG/GRN WIRE RELAY SUPPORT 1 (LEFT END OF DASH) RELAY TWO-TONE HORNS RIGHT TWO-TONE HORN STEERING COLUMN SWITCHING MODULE STEERING WHEEL ELECTRONICS CONTROL UNIT STEERING WHEEL HORN BUTTON TWO-TONE HORNS RELAY VIO WIRE VIO/GRN WIRE WHT/RED WIRE YEL/GRN WIRE
