Porsche 911 Targa 4 991 facelift (2015-2019) term 15 wake up temperature water pump temp sens Wiring diagram
This page shows the only wiring diagram for the component.term 15 wake up temperature water pump temp sens, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 15 wake up temperature water pump temp sens (1 of 1)
ALL-WHEEL DRIVE CONTROL UNIT
ALL-WHEEL DRIVE OIL PRESSURE SENSOR
ALL-WHEEL DRIVE OIL PUMP MOTOR
ALL-WHEEL DRIVE TEMPERATURE SENSOR
ALL-WHEEL TEMP SENS
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/VIO WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FRONT AXLE COOLING WATER PUMP
FUSE 2
FUSE 8
GRN WIRE
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
MTR
ORG/BRN WIRE
ORG/RED WIRE
PRESSURE SENS +
PRESSURE SENS SIG
RED WIRE
RED/GRN WIRE
RIGHT FRONT FUSE BOX (ROW B)
RIGHT FRONT FUSE BOX (ROW D)
SIG
TERM 15 WAKE UP TEMPERATURE WATER PUMP TEMP SENS
TERM 30
TERM 31
TERM 87
VIO/YEL WIRE
WATER PUMP
Go to component -> Awd circuit -> TERM 15 WAKE UP TEMPERATURE WATER PUMP TEMP SENS
