Porsche 911 Targa 4 991 facelift (2015-2019) steering column fore/aft adjustment motor Wiring diagrams
This page contains all the electrical diagrams for the component. steering column fore/aft adjustment motor, in which he is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering column fore/aft adjustment motor (1 of 2)
ADJUSTMENT BTN GND
ADJUSTMENT BTN SIG
ADJUSTMENT CODED
BLU/BLK WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 8
GRN/BLK WIRE
GRN/VIO WIRE
GRN/YEL WIRE
HALL SENS
HALL SENS FORE/AFT +
HALL SENS HEIGHT +
HOT AT ALL TIMES
MOTOR
MOTOR + UP
MOTOR +FORE/AFT
RED/WHT WIRE
RIGHT FRONT FUSE BOX (ROW C)
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
TERM 30
TERM 31
VIO/BLU WIRE
Go to component -> Power tilt steering column circuit -> STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
Wiring diagram steering column fore/aft adjustment motor (2 of 2)
1, 2, OFF
ADJUSTMENT BUTTON GND
ADJUSTMENT BUTTON SIG
ADJUSTMENT CODED
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DISPLAY ON
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR MEMORY BUTTON MODULE
FUSE 6
FUSE 8
GRN/BLK WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
HALL SENS
HALL SENS FORE/AFT +
HALL SENS HEIGHT +
HOT AT ALL TIMES
IND OFF
LEFT FRONT FUSE BOX (ROW C)
MEMORY OFF BUTTON
MEMORY SAVE SWITCH
MEMORY SET
MOTOR
MOTOR + UP
MOTOR +FORE/AFT
ORG/BRN WIRE
ORG/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT FUSE BOX (ROW C)
SET BUTTON
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
TERM 30
TERM 31
VIO/BLU WIRE
VIO/YEL WIRE
YEL WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
