Porsche 911 Targa 4 991 facelift (2015-2019) shift lock Wiring diagram
This page shows the only wiring diagram for the component.shift lock, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
CAN HIGH
CAN LOW
COM TX
COMPUTER DATA LINES SYSTEM
DME CONTROL UNIT
FRONT BCM (LEFT END OF DASH)
FUSE 1
FUSE 7
GRN/RED WIRE
HOT W/ DME 1 RELAY ENERGIZED
HOT W/ KL 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
KEY LOCK (KYLCK)
LEFT FRONT FUSE BOX (ROW D)
LOCKING SOL -
ORG/BLK WIRE
ORG/BRN WIRE
ORG/VIO WIRE
P/N SW
PDK CONTROL UNIT
REAR BCM (UNDER DRIVER SEAT)
REAR FUSE BOX RELAY SUPPORT 2 (ROW B)
RED/BLK WIRE
RED/GRN WIRE
SELECTOR LEVER CONTROL UNIT
SELECTOR LEVER POSITION
SELECTOR LEVER SUPPLY
SERIAL INTER FACE
SHIFT LOCK
STOP LIGHT SW
STOP LIGHT SWITCH
SUPPLY
TERM 15
TERM 31
TERM 87
WHT WIRE
WHT/BLK WIRE
YEL/BLU WIRE
