Porsche 911 Targa 4 991 facelift (2015-2019) right steering wheel tiptronic button Wiring diagram
This page shows the only wiring diagram for the component.right steering wheel tiptronic button, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right steering wheel tiptronic button (1 of 1)
AIR BAG 1-
AIR BAG 2+
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
E-BOX STEERING WHEEL
FUSE 2
FUSE 5
FUSE 7
GRY WIRE
HORN
HORNS SYSTEM
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT STEERING WHEEL TIPTRONIC BUTTON
LIFT FUNCTION CONTROL UNIT (UNDER DRIVER SEAT)
MOTOR
NTC ENGINE TEMP
NTC-
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/GRY WIRE
RED/VIO WIRE
RIGHT FRONT FUSE BOX (ROW A)
RIGHT FRONT FUSE BOX (ROW D)
RIGHT STEERING WHEEL TIPTRONIC BUTTON
SEATS SYSTEM
STEERING WHEEL ELECTRONICS CONTROL UNIT
STEERING WHEEL GROUND
STEERING WHEEL HEATING
SUPPLEMENTAL RESTRAINTS SYSTEM
TERM 15
TERM 30
TERM 31
TIP-DOWN
TIP-UP
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Pdk circuit (2 of 3) -> RIGHT STEERING WHEEL TIPTRONIC BUTTON
