Porsche 911 Targa 4 991 facelift (2015-2019) right rear mid-range speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right rear mid-range speaker, in which he is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear mid-range speaker (1 of 6)
ANTENNA
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH (DISPLAY CTRL PANEL) RESET DISPLAY CTRL PANEL
CAN INFO HIGH
CAN INFO LOW
CAN LOW (DISPLAY CTRL PANEL) RESET CENTRAL COMPUTER
CAN MIB HIGH
CAN MIB LOW
CENTER COMP
CENTRAL PROCESSOR
COMP D C P
COMPUTER DATA LINES SYSTEM
COUPLING ANTENNA
COUPLING BOX STATUS
CRADLE
DISPLAY CONTROL PANEL
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
LF SPEAKER (+)
LR SPEAKER (+)
LS WOOFER VL-
LS WOOFER VR-
MULTI- MODE COMPENSER
ORG/BRN WIRE
ORG/VIO WIRE
POWER ON
RED/YEL WIRE
RESET CENTER
RESET D C P
RF SPEAKER (+)
RIGHT DASHBOARD LOUDSPEAKER
RIGHT END OF DASH)
RIGHT REAR MID-RANGE SPEAKER
RING BRAKE DIAGNOSIS
RR SPEAKER (+)
SHIELD
SIG
SOUND SYSTEMS (TV TUNER CIRCUIT)
STATUS
TEL ON
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
Go to component -> Base radio circuit, 8 speakers (3 of 3) -> RIGHT REAR MID-RANGE SPEAKER
Wiring diagram right rear mid-range speaker (2 of 6)
ANTENNA
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH (DISPLAY CTRL PANEL) RESET DISPLAY CTRL PANEL
CAN INFO HIGH
CAN INFO LOW
CAN LOW (DISPLAY CTRL PANEL) RESET CENTRAL COMPUTER
CAN MIB HIGH
CAN MIB LOW
CENTER COMP
CENTRAL PROCESSOR
COMP D C P
COMPUTER DATA LINES SYSTEM
COUPLING ANTENNA
COUPLING BOX STATUS
CRADLE
DISPLAY CONTROL PANEL
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
LF SPEAKER (+)
LR SPEAKER (+)
LS WOOFER VL-
LS WOOFER VR-
MULTI- MODE COMPENSER
ORG/BRN WIRE
ORG/VIO WIRE
POWER ON
RED/YEL WIRE
RESET CENTER
RESET D C P
RF SPEAKER (+)
RIGHT DASHBOARD LOUDSPEAKER
RIGHT END OF DASH)
RIGHT REAR MID-RANGE SPEAKER
RING BRAKE DIAGNOSIS
RR SPEAKER (+)
SHIELD
SIG
SOUND SYSTEMS (TV TUNER CIRCUIT)
STATUS
TEL ON
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
Go to component -> Navigation circuit, base w/ 8 speakers (3 of 3) -> RIGHT REAR MID-RANGE SPEAKER
Wiring diagram right rear mid-range speaker (3 of 6)
BLU WIRE
BLU/BLK WIRE
BOSE AMPLIFIER (UNDER RIGHT FRONT SEAT)
BRN WIRE
BRN/WHT WIRE
CENTER DASHBOARD LOUDSPEAKER
CENTER LSP -
DRIVER'S DOOR MID-RANGE SPEAKER
DRIVER'S DOOR WOOFER
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
FUSE 6
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HIGH END SUBWOOFER
HOT AT ALL TIMES
LEFT DASHBOARD LOUDSPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LF MID-RANGE LSP+/WOOFER
LF MID-RANGE LSP-/WOOFER
LF TWEETER LSP +
LF WOOFER LSP +
LR MID-RANGE LSP+/WOOFER
LR MID-RANGE LSP-/WOOFER
LR TWEETER LSP -
LSP +
MICROPHONE
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
RED/YEL WIRE
RF MID-RANGE LSP+/WOOFER
RF MID-RANGE LSP-/WOOFER
RF TWEETER LSP -
RF WOOFER LSP +
RIGHT DASHBOARD LOUDSPEAKER
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW B)
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR TWEETER
RING BRAKE DIAGNOSIS
RR MID-RANGE LSP+/WOOFER
RR MID-RANGE LSP-/WOOFER
RR TWEETER LSP -
SOUND SYSTEMS
SOUND SYSTEMS (TV TUNER CIRCUIT)
SURROUND SUBWOOFER +
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, premium w/ bose amplifier (4 of 4) -> RIGHT REAR MID-RANGE SPEAKER
Wiring diagram right rear mid-range speaker (4 of 6)
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
BURMESTER AMPLIFIER (UNDER RIGHT FRONT SEAT)
BURMESTER SUBWOOFER
BURMESTER SUBWOOFER AMPLIFIER
CENTER DASHBOARD LOUDSPEAKER
CENTER LSP -
DRIVER'S DOOR MID-RANGE SPEAKER
DRIVER'S DOOR WOOFER
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
FUSE 6
FUSE 7
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
I/P
LEFT DASHBOARD SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LF LSP WOOFER -
LF MID-RANGE LSP-/WOOFER
LF TWEETER LSP +
LR MID-RANGE LSP-/WOOFER
LR TWEETER LSP -
LSP +
MICROPHONE
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
RED/WHT WIRE
RED/YEL WIRE
REMOTE SUBWOOFER
RF LSP WOOFER -
RF MID-RANGE LSP-/WOOFER
RF TWEETER LSP -
RIGHT DASHBOARD SPEAKER
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW B)
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR TWEETER
RING BRAKE DIAGNOSIS
RR MID-RANGE LSP-/WOOFER
RR TWEETER LSP -
SIG
SOUND SYSTEMS (OPTICAL WAVEGUIDE CIRCUIT)
SOUND SYSTEMS (TV TUNER CIRCUIT)
SUBWOOFER
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, premium w/ burmester amplifier (4 of 4) -> RIGHT REAR MID-RANGE SPEAKER
Wiring diagram right rear mid-range speaker (5 of 6)
BLU WIRE
BLU/BLK WIRE
BOSE AMPLIFIER (UNDER RIGHT FRONT SEAT)
BRN WIRE
BRN/WHT WIRE
CENTER DASHBOARD LOUDSPEAKER
CENTER LSP -
DRIVER'S DOOR MID-RANGE SPEAKER
DRIVER'S DOOR WOOFER
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
FUSE 6
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HIGH END SUBWOOFER
HOT AT ALL TIMES
LEFT DASHBOARD LOUDSPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LF MID-RANGE LSP+/WOOFER
LF MID-RANGE LSP-/WOOFER
LF TWEETER LSP +
LF WOOFER LSP +
LR MID-RANGE LSP+/WOOFER
LR MID-RANGE LSP-/WOOFER
LR TWEETER LSP -
LSP +
MICROPHONE
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
RED/YEL WIRE
RF MID-RANGE LSP+/WOOFER
RF MID-RANGE LSP-/WOOFER
RF TWEETER LSP -
RF WOOFER LSP +
RIGHT DASHBOARD LOUDSPEAKER
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW B)
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR TWEETER
RING BRAKE DIAGNOSIS
RR MID-RANGE LSP+/WOOFER
RR MID-RANGE LSP-/WOOFER
RR TWEETER LSP -
SOUND SYSTEMS
SOUND SYSTEMS (TV TUNER CIRCUIT)
SURROUND SUBWOOFER +
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, w/ bose (4 of 4) -> RIGHT REAR MID-RANGE SPEAKER
Wiring diagram right rear mid-range speaker (6 of 6)
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
BURMESTER AMPLIFIER (UNDER RIGHT FRONT SEAT)
BURMESTER SUBWOOFER
BURMESTER SUBWOOFER AMPLIFIER
CENTER DASHBOARD LOUDSPEAKER
CENTER LSP -
DRIVER'S DOOR MID-RANGE SPEAKER
DRIVER'S DOOR WOOFER
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
FUSE 6
FUSE 7
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
I/P
LEFT DASHBOARD SPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LF LSP WOOFER -
LF MID-RANGE LSP-/WOOFER
LF TWEETER LSP +
LR MID-RANGE LSP-/WOOFER
LR TWEETER LSP -
LSP +
MICROPHONE
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
RED/WHT WIRE
RED/YEL WIRE
REMOTE SUBWOOFER
RF LSP WOOFER -
RF MID-RANGE LSP-/WOOFER
RF TWEETER LSP -
RIGHT DASHBOARD SPEAKER
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW B)
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR TWEETER
RING BRAKE DIAGNOSIS
RR MID-RANGE LSP-/WOOFER
RR TWEETER LSP -
SIG
SOUND SYSTEMS (OPTICAL WAVEGUIDE CIRCUIT)
SOUND SYSTEMS (TV TUNER CIRCUIT)
SUBWOOFER
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, w/ burmester (4 of 4) -> RIGHT REAR MID-RANGE SPEAKER
