Porsche 911 Targa 4 991 facelift (2015-2019) rear lid lock switch Wiring diagram
This page shows the only wiring diagram for the component.rear lid lock switch, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear lid lock switch (1 of 1)
4.0L
A/C COMPRESSOR
BAR IGNITION CYLINDER 1 MODULE
BAR IGNITION CYLINDER 2 MODULE
BAR IGNITION CYLINDER 3 MODULE
BAR IGNITION CYLINDER 4 MODULE
BAR IGNITION CYLINDER 5 MODULE
BAR IGNITION CYLINDER 6 MODULE
BLK WIRE
BLU WIRE
BOOST PRESSURE ADJUSTER 1
BOOST PRESSURE ADJUSTER 2
BRN WIRE
CIGAR LIGHTER
COUPE
DME CONTROL UNIT
ELECTRICAL STEERING GEAR
ENGINE COMPARTMENT PURGE FAN 1
ENGINE COMPARTMENT PURGE FAN 2
ENGINE FLUSH LOW RELAY
FAN CONTROL UNIT
FRONT CENTER CONSOLE PLUG SOCKET
HIGH MOUNTED STOP LIGHT
LEFT MAKE-UP LIGHT
OIL LEVEL SENSOR SHIELD
RDK CONTROL UNIT
REAR ADAPTER 7 (REAR WINDOW HEATER) RELAY
REAR LID LOCK SWITCH
RIGHT END OF DASH)
RIGHT LANE CHANGE ASSISTANT
RIGHT MAKE-UP LIGHT
RIGHT REAR BRAKE PAD WEAR INDICATOR
RIGHT TAILLIGHT
TAILGATE RELEASE ACTUATOR
VIO WIRE
W/ REAR SPOILER
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> REAR LID LOCK SWITCH
