Wiring diagram microphone 1 - (1 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (1 of 8)

Get access

ANTENNA AUX 1 IN L + AUX 1 IN R + AUX GND AUX L + AUX R + AUX SHIELD BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COUPE DATA DATA 1 (+) DATA 2 (+) FUSE 3 FUSE 4 GLOBAL POSITIONING SYSTEM ANTENNA GPS GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LVDS IN + LVDS OUT 1+ MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MOST IN MOST OUT ORG/ WIRE PASSENGER AIR BAG ESD GROUND REAR LID SDARS ANTENNA RED WIRE RED/YEL WIRE RIGHT FRONT FUSE BOX (ROW B) SDARS SDARS ANTENNA SHIELD SIG SOUND SYSTEMS TERM 30 TERM 31 UNIVERSAL AUDIO INTERFACE USB USB DATA - USB GND USB HUB ACT USB VCC USB- HUB VIO WIRE WHT WIRE YEL WIRE

Go to component -> Base radio circuit, 4 speakers (1 of 2) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (2 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (2 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX GND AUX L + AUX R + AUX SHIELD BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MOST IN MOST OUT ORG/ WIRE PASSENGER AIR BAG ESD GROUND RED WIRE RED/YEL WIRE SHIELD SIG SOUND SYSTEMS TERM 15 TERM 30 TERM 31 UNIVERSAL AUDIO INTERFACE USB USB DATA - USB GND USB HUB ACT USB VCC USB- HUB VIO WIRE WHT WIRE YEL/RED WIRE

Go to component -> Base radio circuit, 8 speakers (1 of 3) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (3 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (3 of 8)

Get access

ANTENNA AUX 1 IN L + AUX 1 IN R + AUX GND AUX L + AUX R + AUX SHIELD BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COUPE DATA DATA 1 (+) DATA 2 (+) FUSE 3 FUSE 4 GLOBAL POSITIONING SYSTEM ANTENNA GPS GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LANGUAGE LVDS IN + LVDS OUT 1+ MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MOST IN MOST OUT ORG/ WIRE PASSENGER AIR BAG ESD GROUND REAR LID SDARS ANTENNA RED WIRE RED/YEL WIRE RIGHT FRONT FUSE BOX (ROW B) SDARS SDARS ANTENNA SHIELD SIG SOUND SYSTEMS TERM 30 TERM 31 UNIVERSAL AUDIO INTERFACE USB USB DATA - USB GND USB HUB ACT USB VCC USB- HUB VIO WIRE WHT WIRE YEL WIRE

Go to component -> Navigation circuit, base w/ 4 speakers (1 of 2) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (4 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (4 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX GND AUX L + AUX R + AUX SHIELD BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MOST IN MOST OUT ORG/ WIRE PASSENGER AIR BAG ESD GROUND RED WIRE RED/YEL WIRE SHIELD SIG SOUND SYSTEMS TERM 15 TERM 30 TERM 31 UNIVERSAL AUDIO INTERFACE USB USB DATA - USB GND USB HUB ACT USB VCC USB- HUB VIO WIRE WHT WIRE YEL/RED WIRE

Go to component -> Navigation circuit, base w/ 8 speakers (1 of 3) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (5 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (5 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX L + AUX R + AUX SHIELD AUX-GROUND BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) EXCEPT TURBO FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MICROPHONE 2 + MOST IN MOST OUT ORG/ WIRE REC RED WIRE SHIELD SIG SOUND SOUND SYSTEMS TERM 15 TERM 31 TURBO UNIVERSAL AUDIO INTERFACE USB USB GND USB VCC VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Navigation circuit, premium w/ bose amplifier (1 of 4) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (6 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (6 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX L + AUX R + AUX SHIELD AUX-GROUND BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) EXCEPT TURBO FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MICROPHONE 2 + MOST IN MOST OUT ORG/ WIRE REC RED WIRE SHIELD SIG SOUND SOUND SYSTEMS TERM 15 TERM 31 TURBO UNIVERSAL AUDIO INTERFACE USB USB GND USB VCC VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Navigation circuit, premium w/ burmester amplifier (1 of 4) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (7 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (7 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX L + AUX R + AUX SHIELD AUX-GROUND BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) EXCEPT TURBO FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MICROPHONE 2 + MOST IN MOST OUT ORG/ WIRE REC RED WIRE SHIELD SIG SOUND SOUND SYSTEMS TERM 15 TERM 31 TURBO UNIVERSAL AUDIO INTERFACE USB USB GND USB VCC VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, w/ bose (1 of 4) -> MICROPHONE 1 -

Wiring diagram microphone 1 - (8 of 8)

Wiring diagram microphone 1 - for Porsche 911 Targa 4 991 facelift (2015-2019) (8 of 8)

Get access

AUX 1 IN L + AUX 1 IN R + AUX L + AUX R + AUX SHIELD AUX-GROUND BACKUP CAMERA BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CENTRAL PROCESSOR COMPUTER DATA LINES SYSTEM DATA DATA 1 (+) DATA 2 (+) EXCEPT TURBO FUSE 2 GRN WIRE HOME LINK CONTROL UNIT HOT W/ TERMINAL 15 RELAY ENERGIZED LANGUAGE LEFT FRONT FUSE BOX (ROW D) MICROPHONE MICROPHONE (HANDS-FREE OPERATION) MICROPHONE 1 - MICROPHONE 2 + MOST IN MOST OUT ORG/ WIRE REC RED WIRE SHIELD SIG SOUND SOUND SYSTEMS TERM 15 TERM 31 TURBO UNIVERSAL AUDIO INTERFACE USB USB GND USB VCC VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Go to component -> Premium radio circuit, w/ burmester (1 of 4) -> MICROPHONE 1 -

Porsche 911 Targa 4 991 facelift (2015-2019) microphone 1 - Wiring diagrams

Wiring diagram microphone 1 - (1 of 8)

List of components:

Wiring diagram microphone 1 - (2 of 8)

List of components:

Wiring diagram microphone 1 - (3 of 8)

List of components:

Wiring diagram microphone 1 - (4 of 8)

List of components:

Wiring diagram microphone 1 - (5 of 8)

List of components:

Wiring diagram microphone 1 - (6 of 8)

List of components:

Wiring diagram microphone 1 - (7 of 8)

List of components:

Wiring diagram microphone 1 - (8 of 8)

List of components:
