Porsche 911 Targa 4 991 facelift (2015-2019) high end subwoofer Wiring diagrams
This page contains all the electrical diagrams for the component. high end subwoofer, in which he is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high end subwoofer (1 of 2)
BLU WIRE
BLU/BLK WIRE
BOSE AMPLIFIER (UNDER RIGHT FRONT SEAT)
BRN WIRE
BRN/WHT WIRE
CENTER DASHBOARD LOUDSPEAKER
CENTER LSP -
DRIVER'S DOOR MID-RANGE SPEAKER
DRIVER'S DOOR WOOFER
FRONT PASSENGER DOOR MID-RANGE SPEAKER
FRONT PASSENGER DOOR WOOFER
FUSE 6
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HIGH END SUBWOOFER
HOT AT ALL TIMES
LEFT DASHBOARD LOUDSPEAKER
LEFT REAR MID-RANGE SPEAKER
LEFT REAR TWEETER
LF MID-RANGE LSP+/WOOFER
LF MID-RANGE LSP-/WOOFER
LF TWEETER LSP +
LF WOOFER LSP +
LR MID-RANGE LSP+/WOOFER
LR MID-RANGE LSP-/WOOFER
LR TWEETER LSP -
LSP +
MICROPHONE
OPTICAL WAVEGUIDE IN
OPTICAL WAVEGUIDE OUT
RED/YEL WIRE
RF MID-RANGE LSP+/WOOFER
RF MID-RANGE LSP-/WOOFER
RF TWEETER LSP -
RF WOOFER LSP +
RIGHT DASHBOARD LOUDSPEAKER
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW B)
RIGHT REAR MID-RANGE SPEAKER
RIGHT REAR TWEETER
RING BRAKE DIAGNOSIS
RR MID-RANGE LSP+/WOOFER
RR MID-RANGE LSP-/WOOFER
RR TWEETER LSP -
SOUND SYSTEMS
SOUND SYSTEMS (TV TUNER CIRCUIT)
SURROUND SUBWOOFER +
TERM 30
TERM 31
VIO WIRE
VIO/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, premium w/ bose amplifier (4 of 4) -> HIGH END SUBWOOFER
