Porsche 911 Targa 4 991 facelift (2015-2019) hall sensor, backrest angle adjustment Wiring diagram

BACKREST ANGLE ADJUSTMENT 1 BACKREST ANGLE ADJUSTMENT 2 BACKREST WIDTH ADJUSTMENT BACKREST WIDTH ADJUSTMENT VALVE 1 BLEED BACKREST WIDTH ADJUSTMENT VALVE 2 VENT BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER SEAT CONTROL UNIT (UNDER DRIVER SEAT) DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR DRIVER'S SEAT LUMBAR SUPPORT DRIVER'S SEAT SEAT HEIGHT ADJUSTMENT MOTOR GRY/BLK WIRE GRY/GRN WIRE HALL SENS HALL SENSOR, BACKREST ANGLE ADJUSTMENT HALL SENSOR, SEAT DEPTH ADJUSTMENT LOAD LUMBAR BOTTOM VALVE 3 LUMBAR BOTTOM VALVE 3 VENT LUMBAR BOTTOM VALVE 4 LUMBAR BOTTOM VALVE 4 BLEED LUMBAR GROUND LUMBAR PRESSURE BOTTOM LUMBAR PRESSURE TOP LUMBAR SW FORWARD/BACK LUMBAR SW HIGH/LOW LUMBAR TOP VALVE 1 LUMBAR TOP VALVE 1 VENT LUMBAR TOP VALVE 2 LUMBAR TOP VALVE 2 BLEED ORG/BRN WIRE ORG/GRN WIRE PLUS VALVE PUMP PUMP GROUND RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE SEAT ADJUSTMENT SW ANGLE ADJUSTMENT SEAT ADJUSTMENT SW BACKREST ANGLE ADJUSTMENT SEAT ADJUSTMENT SW GROUND SEAT ADJUSTMENT SW HEIGHT ADJUSTMENT SEAT ANGLE ADJUSTMENT 1 SEAT ANGLE ADJUSTMENT 2 SEAT ANGLE ADJUSTMENT MOTOR SEAT BACKREST ADJUSTMENT 1 SEAT BACKREST ADJUSTMENT 2 SEAT BACKREST ADJUSTMENT SW SEAT CUSHION SW SEAT DEPTH ADJUSTMENT 1 SEAT DEPTH ADJUSTMENT 2 SEAT DEPTH ADJUSTMENT SW SEAT FORE/ AFT ADJUSTMENT MOTOR SEAT HEIGHT ADJUSTMENT 1 SEAT HEIGHT ADJUSTMENT 2 SEAT WIDTH ADJUSTMENT SEAT WIDTH ADJUSTMENT VALVE 3 BLEED SEAT WIDTH ADJUSTMENT VALVE 4 VENT TERM 30 TERM 31 VALVE 1 VALVE 2 VALVE 3 VALVE 4 VALVE BLACK GROUND VALVE BLOCK GROUND VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
