Porsche 911 Targa 4 991 facelift (2015-2019) close ctrl valve 2 Wiring diagram

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CAN HIGH CAN LOW CLOSE CTRL VALVE 2 CLOSE CTRL VALVE- CLOSE HD+ HYDRAULIC PUMP CLOSE LATCH MOTOR + CLOSE MTR + COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL UNIT ELECTRIC CONVERTIBLE TOP MOTOR EXT SENS - FUSE 1 FUSE 2 FUSE 3 GRN WIRE GRN/BLK WIRE GROUND GRY WIRE GRY/BRN WIRE GRY/WHT WIRE HALL CLOSED HALL OPEN HALL SENS HALL SENS CLOSED HALL SENS SUPPLY 2+ HOOD COMP LID CLOSED/OPEN HALL SENS HOOD TORQUE ANGLE SENS+ HOOD LATCH SENSOR HOOD LATCHING HOOK MOTOR HOOD LATCHING HOOK SWITCH HOOD ROT ANGLE SENS HALL HOOD TORQUE ANGLE SENS- HOOD TORQUE ANGLE SENSOR HOT AT ALL TIMES INSTRUMENT CLUSTER LATCHING HOOK MICRO SWITCH LATCHING MICRO SWITCH GND LEFT HOOD COMP LID CLOSED HALL SENS LEFT HOOD COMP LID OPEN HALL SENS MS LATCH LOCKED LEFT HOOD COMPARTMENT LID HALL SENSOR (LEFT SIDE OF HOOD COMPT) MAXI FUSE RELAY SUPPORT 2 MICROSWITCH 18 MICROSWITCH 19 MICROSWITCH A MICROSWITCH B MOTOR - (EXTENDED) MS LATCH RELEASED NCA WIRE OPEN CTRL VALVE 1 OPEN CTRL VALVE- OPEN HD+ HYDRAULIC PUMP OPEN LATCH MOTOR + ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE PUMP REAR FUSE BOX RELAY SUPPORT 2 (ROW C) REAR SIDE CLOSE FLAP MTR + REAR SIDE FLAP HALL SENSOR 1 REAR SIDE FLAP HALL SENSOR 2 REAR SIDE FLAP MOTOR REAR SIDE FLAPS CLOSED HALL SENS LATCHING HOOK READY REAR SIDE FLAPS OPEN HALL SENS REAR SIDE OPEN FLAP MTR + RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE REED SWITCH A REED SWITCH B RIGHT FRONT FUSE BOX (ROW C) RIGHT HOOD COMPARTMENT LID HALL SENSOR (RIGHT SIDE OF HOOD COMPT) ROOF CONSOLE SUPPLY TEMPERATURE TERM 30 TERM 30 ELECTRONICS TERM 30 LOAD TERM 31 VIO WIRE VIO/GRN WIRE VIO/YEL WIRE WHT WIRE WIND DEFLECTOR MOTOR WIND DEFLECTOR RAISED HALL SENSOR WIND DEFLTR LOWERED HALL SENS RIGHT HOOD COMP LID CLOSED HALL SENS WIND DFLTR MOTOR LOWER + WIND DFLTR MOTOR RAISE + WIND DFLTR RAISD HALL SENS WIND LOWERED DEFLECTOR HALL SENSOR YEL WIRE YEL/BLK WIRE YEL/GRY WIRE
