Porsche 911 Targa 4 991 facelift (2015-2019) card reader dsrc Wiring diagram
This page shows the only wiring diagram for the component.card reader dsrc, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram card reader dsrc (1 of 1)
A/T
BRN WIRE
CARD READER DSRC
CENTER COCKPIT AIR VENT LIGHTING
DIAGNOSTIC PLUG SOCKET
DRIVER'S DOOR CENTRAL LOCK SAFE LED
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR IGNITION LOCK LIGHT
DRIVER'S DOOR LOCK
DRIVER'S DOOR OUTER HANDLE SWITCH
E-BOX STEERING WHEEL
ELECTRONIC IGNITION LOCK
EMERGENCY VOLTAGE SUPPLY 1 RELAY
EPB BUTTON
FRONT BCM
FRONT CONTROL UNIT
FRONT PASSENGER DOOR CENTRAL LOCK SAFE LED
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER DOOR OUTER HANDLE SWITCH
FRONT WIPER MOTOR
GATEWAY CONTROL UNIT
GLOVE COMPARTMENT SWITCH
GRY WIRE
HEAD AIR BAG DS ESD GROUND
HEAD AIR BAG PS ESD GROUND
INSTRUMENT CLUSTER
KNEE AIR BAG PS ESD GROUND
LEFT COCKPIT AIR VENT LIGHTING
LEFT FAN RELAY
LEFT FRONT FOOTWELL LIGHT
LEFT REAR DOOR CONTROL UNIT
M/T
MAIN FUSE BOX
PASSENGER AIR BAG ESD GROUND
RIGHT COCKPIT AIR VENT LIGHTING
RIGHT FAN RELAY
RIGHT FRONT FOOTWELL LIGHT
RIGHT REAR DOOR CONTROL UNIT
ROTARY LIGHT SWITCH
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN LOCK
STEERING COLUMN MODULE AIR BAG GROUND
STEERING COLUMN SWITCHING MODULE
STEERING WHEEL ELECTRONICS CONTROL UNIT
STEERING WHEEL GROUND
STEERING WHEEL TIPTRONIC BUTTON
STOPWATCH
TWO-TONE HORNS RELAY
USB- HUB
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> CARD READER DSRC
