Porsche 911 Targa 4 991 facelift (2015-2019) can extended low Wiring diagram
This page shows the only wiring diagram for the component.can extended low, which is found in the car Porsche 911 Targa 4 991 facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can extended low (1 of 1)
BLK WIRE
BRN/GRY WIRE
BRN/WHT WIRE
CAN EXTENDED HIGH
CAN EXTENDED LOW
CAN PRIVATE HIGH
CAN PRIVATE LOW
COMPUTER DATA LINES SYSTEM
DRIVER INNER DOOR PANEL
FRONT PASSENGER INNER DOOR PANEL
FUSE 7
HOT W/ TERMINAL 15 RELAY ENERGIZED
LCA LED -
LCA LED LE
LCA LED, RI+
LEFT LANE CHANGE ASSISTANT
ORG/BLU WIRE
ORG/BRN WIRE
ORG/VIO WIRE
REAR FUSE BOX RELAY SUPPORT 2 (ROW C)
RIGHT LANE CHANGE ASSISTANT
TERM 15
TERM 31
VIO/GRY WIRE
Go to component -> Lane change assistance circuit -> CAN EXTENDED LOW
