Porsche 911 GT3 992 (2020-2024) Radio circuit, w/ bose

BLK WIRE BLK/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE CENTER LOUDSPEAKER CENTER SPEAKER DIGITAL SOUND PACKAGE AMPLIFIER FUSE 1 FUSE HOLDER M GRN WIRE GRN/BLK WIRE GROUND HOT AT ALL TIMES LEFT FRONT BASS LOUDSPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TREBLE LOUDSPEAKER LEFT REAR MID-RANGE SPEAKER LEFT REAR TREBLE LOUDSPEAKER LF LOW RANGE SPEAKER - LF MID-RANGE LSP + LF TWEETER+ LR MID-RANGE SPEAKER + LR MID-RANGE SPEAKER - RR MID-RANGE SPEAKER - LR TWEETER + MICROPH SOUND REC + RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RF LOW RANGE SPEAKER - RF MID-RANGE LSP + RF TWEETER - RIGHT FRONT BASS LOUDSPEAKER RIGHT FRONT FUSE BOX RIGHT FRONT TREBLE LOUDSPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TREBLE SPEAKER RR MID-RANGE SPEAKER + RR TWEETER - SUBWOOFER TERM 30 WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

AUDIO, VIDEO ADDITIONAL CONNECTIONS UNIT BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE DRIVER SIDE MICROPHONE 1 DRIVER SIDE MICROPHONE 2 GRN WIRE GRN/BRN WIRE GROUND LEFT SUN SENS LTE 2 LTE AERIAL 2 MIC 1 GND MIC 1+ MIC 2 GND MIC 2+ MICROPHONE MICROPHONE 1 - MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT NCA WIRE RED WIRE RED/GRN WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT SUN SENS SENS GND SHIELD SUNLIGHT PENETRATION PHOTO SENSOR TELEPHONE, TELEMATICS CONTROL UNIT TERM 30 TERM 31 VDA OUT + WHT WIRE WHT/BRN WIRE

BLK WIRE BLU/RED WIRE BLU/YEL WIRE BLUETOOTH MOBILE PHONE COUPLING AERIAL BRN WIRE BRN/BLU WIRE BRN/VIO WIRE CAN INFO HIGH CAN INFO LOW COMPUTER DATA LINES SYSTEM COUPLING BOX TELEPHONE ANTENNA CRADLE EMERGENCY CALL LOUDSPEAKER MODULE FUSE 5 FUSE HOLDER J GRN WIRE GROUND HOT AT ALL TIMES LEFT SUN SENS LTE MOBILE TELEPHONE AERIAL AMPLIFIER MULTIMEDIA SYSTEM OPERATING UNIT N/A NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RED WIRE RIGHT FRONT FUSE BOX RIGHT SUN SENS SENS GND SHIELD TERM 30 TERM 31 VIO/WHT WIRE WHT WIRE

AM/FM AM/FM 1 BLK WIRE BRN WIRE CAN COMFORT HIGH CAN COMFORT LOW CENTER DASH PANEL SWITCH MODULE CENTRAL LOCK COMPUTER DATA LINES SYSTEM DAB FLEXRAY BRANCH 1 BM FLEXRAY BRANCH 1 BP FM 2 FUSE 9 FUSE HOLDER K GRN WIRE GROUND HOT AT ALL TIMES LEFT WINDSCREEN AERIAL LIN 1 MULTIMEDIA SYSTEM N/A NCA WIRE ONBOARD SUPPLY CONTROL UNIT 2 ORG/BRN WIRE ORG/GRN WIRE PNK WIRE RED WIRE RED/WHT WIRE RIGHT FRONT FUSE BOX RIGHT WINDSCREEN AERIAL SATELLITE TUNER AERIAL SDARS SHIELD STEERING COLUMN ELECTRONICS CONTROL UNIT TERM 30 VIO/WHT WIRE VIO/YEL WIRE

BLK WIRE BLUETOOTH BRN WIRE CAN HIGH CAN LOW CENTER CONSOLE SWITCH MODULE 1 COMPUTER DATA LINES SYSTEM FRONT BLUETOOTH FUSE 1 FUSE 10 FUSE 8 FUSE HOLDER A FUSE HOLDER B FUSE HOLDER K HOT AT ALL TIMES MAIN FUSE BOX NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO CONTROLLED PARKING AERIAL 3 RADIO CONTROLLED PARKING AERIAL 4 RADIO CONTROLLED PARKING CONTROL UNIT REAR BLUETOOTH RED WIRE RED/YEL WIRE RIGHT FRONT FUSE BOX SHIELD TERM 30 TERM 31 VIO/WHT WIRE
