Auto anti-dazzling mirror circuit for Porsche 911 GT3 991 facelift (2017-2019)
Auto anti-dazzling mirror circuit
ANTI-DAZZLE INTERIOR MIRROR
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
EC MIRROR
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 6
FUSE 7
FUSE 9
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT ELECTROCHROMIC HEATED MIRROR
LEFT FRONT FUSE BOX (ROW C)
LEFT FRONT FUSE BOX (ROW D)
LIN
MIRROR EC GLASS
MIRROR EC GLASS GND
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/VIO WIRE
RIGHT ELECTROCHROMIC HEATED MIRROR
RIGHT END OF DASH)
RIGHT FRONT FUSE BOX (ROW C)
TERM 15
TERM 30
TERM 31
VIO WIRE
