Porsche 911 GT3 991 (2013-2017) out side temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.out side temperature sensor, which is found in the car Porsche 911 GT3 991 (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram out side temperature sensor (1 of 1)
A/C COMPRESSOR VALVE +
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE BUTTON MODULE
CENTRAL VALVE SERVO MOTOR
COOLANT SHUT-OFF VALVE 5
DEFROST FLAP SERVO MOTOR
ENGINE COMPARTMENT PURGE FAN 2
EXTENDED VENT ELEMENT SERVO MOTOR
FAN CONTROL UNIT
FRESH AIR FAN MOTOR
FRESH/ RECIRCULATED AIR FLAP SERVO MOTOR
FUSE 1
GROUND
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT FUSE BOX (ROW A)
LEFT TEMPERATURE VALVE SERVO MOTOR
LIN
LIN INPUT
LIN OUTPUT
OUT SIDE TEMPERATURE SENSOR
OUTPUT
POSITIVE
PWM
RAM AIR FLAP SERVO MOTOR
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT END OF DASH)
RIGHT FOOTWELL SERVO MOTOR
RIGHT TEMPERATURE VALVE SERVO MOTOR
SIG
SIGNAL
TERM 30
TERM 31
TERM 87
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> OUT SIDE TEMPERATURE SENSOR
