Porsche 911 Carrera 992 (2018-2024) tailgate main catch Wiring diagram
This page shows the only wiring diagram for the component.tailgate main catch, which is found in the car Porsche 911 Carrera 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate main catch (1 of 1)
ADJUSTABLE REAR SPOILER CONTROL UNIT
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN COMFORT HIGH
CAN HIGH
CAN LOW
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMPUTER DATA LINES SYSTEM
DECKEL OEF VO HI
DRIVER DOOR CONTROL UNIT
ENGINE + LOCKING
ENGINE + UNLOCKING
FRONT LUGGAGE COMPARTMENT MANUAL RELEASE ACTUATOR
FRONT LUGGAGE COMPARTMENT RELEASE ACTUATOR
FUEL TANK FILLER FLAP CENTRAL LOCKING ACTUATOR
FUSE 15
FUSE HOLDER J
GRN/YEL WIRE
GROUND
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
L TAIL/BRAKE LIGHT 3
LOCK TANK LID
LUGGAGE COMPARTMENT MANUAL RELEASE BUTTON
LUGGAGE COMPARTMENT RELEASE SWITCH
MOTOR
MTR 2 EXTENSION
MTR 2 RETRACTION
NEGATIVE
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
ORG/GRN WIRE
POS
REAR LID CLOSED SWITCH
RIGHT FRONT FUSE BOX
ROTARY LATCH CONTACT
SW, TAILGATE REL
TAILGATE MAIN CATCH
TAILGATE RELEASE ACTUATOR (BOTTOM CENTER OF TAILGATE)
TERM 30 1
TERM 31
UNLOCK FRONT LID
UNLOCK REAR LID
UNLOCK TANK LID
UNLOCKING +
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Tailgate & fuel door release circuit -> TAILGATE MAIN CATCH
