Porsche 911 Carrera 992 (2018-2024) so mtr fsk extend so mtr wind deflector + Wiring diagram
This page shows the only wiring diagram for the component.so mtr fsk extend so mtr wind deflector +, which is found in the car Porsche 911 Carrera 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram so mtr fsk extend so mtr wind deflector + (1 of 1)
ANGLE OF ROTATION HOOD
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CLOSE
CLOSE FSK + /
COMPUTER DATA LINES SYSTEM
CONVERTIBLE ROOF ACTUATION CONTROL UNIT
CONVERTIBLE ROOF ACTUATION HYDRAULIC PUMP
CONVERTIBLE ROOF BOX LID CLOSED SWITCH
CONVERTIBLE ROOF BOX LID LOCK MOTOR
CONVERTIBLE ROOF BOX LID OPEN SWITCH
CONVERTIBLE ROOF LOCKING READINESS SWITCH
DASH PANEL INSERT
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HALL FSK EXTENDED
HALL FSK RETRACTED
HALL SENSOR 1
HALL SENSOR 2
HALL VDKD LI CLOSED
HALL VDKD RE CLOSED
HYDRAULIC CONTROL VALVE 1
HYDRAULIC CONTROL VALVE 2
HYDRAULIC PUMP MOTOR
HYDRAULIC TEMPERATURE SENDER
LEFT CONVERTIBLE ROOF BOX LID CLOSED SWITCH
LEFT CONVERTIBLE ROOF BOX LID OPEN SWITCH
LEFT CONVERTIBLE ROOF FLAP
MICROSWITCH A
MICROSWITCH B
NCA WIRE
OPEN FSK -
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
REED SWITCH A
REED SWITCH B
RIGHT CONVERTIBLE ROOF BOX LID CLOSED SWITCH
SO ENGINE WIND DEFLECTOR -
SO MTR FSK EXTEND SO MTR WIND DEFLECTOR +
SO RETRACT THE FSK MTR
TEMP
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Convertible top circuit (2 of 2) -> SO MTR FSK EXTEND SO MTR WIND DEFLECTOR +
