Porsche 911 Carrera 992 (2018-2024) si ms dvh unlocked Wiring diagram

ANGLE OF ROTATION HOOD BLK WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CABRIOLET WINDBREAK MOTOR CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM CONVERTIBLE ROOF ACTUATION CONTROL UNIT CONVERTIBLE ROOF LOCK UNIT DEFOGGER SYSTEM FUSE 1 FUSE 10 FUSE 2 FUSE HOLDER Q FUSE HOLDER V GND ROTARY ENCODER GRN/RED WIRE GROUND, MICROSWITCH GRY WIRE GRY/WHT WIRE HALL WIND DEF HOOK RECORDING HOT AT ALL TIMES KL 30 LOGIC MOTOR ROOF LOCK + MOTOR ROOF UNLOCK + MS DHV LOCKED MS DVH LOCKED MS DVH UNLOCKED MS VG IN LOCK ITEM MTR MTR HYDRAULIC PUMP VG CLOSE + CLOSE CTRL VLV + MTR HYDRAULIC PUMP VG OEFF + SI TEMP HYDRAULICS N/A NCA WIRE OPEN CTRL VLV + ORG/BRN WIRE ORG/GRN WIRE PWM PWM GND REAR FUSE BOX REAR WINDOW HEATING+ RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE ROTARY VANE POSITION SENS SI HALL VDKD LI OPEN SI HALL WINDS SET UP SI MS DVH UNLOCKED SI TEMP HYDRAULIC GND SUPPLY DWG SUPPLY HALL 1 SUPPLY HALL 2 VERS ROTARY ENCODER VIO/YEL WIRE VLV - WHT WIRE WHT/VIO WIRE WIND DEFLECTOR FIELD WIND DEFLECTOR SETUP YEL WIRE
