Porsche 911 Carrera 992 (2018-2024) pass side exit warning lamp Wiring diagram
This page shows the only wiring diagram for the component.pass side exit warning lamp, which is found in the car Porsche 911 Carrera 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass side exit warning lamp (1 of 1)
AUTOMATIC GEARBOX CONTROL UNIT
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
ENGINE/MOTOR CONTROL UNIT
EXTERIOR MIRROR ENTRY LIGHT
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 12
FUSE 14
FUSE HOLDER K
FUSE HOLDER P
GRN WIRE
GROUND
GROUND ACTUATORS/SENSORS
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HIGH-LEVEL BRAKE LIGHT BULB
HIGH-LEVEL BRAKE LIGHT BULB 2
HOT AT ALL TIMES
LEFT NUMBER PLATE LIGHT
LIGHTING
LIN 1
LUGGAGE COMPARTMENT MANUAL RELEASE BUTTON
MARKER LIGHT
NEGATIVE
ONBOARD SUPPLY CONTROL UNIT
ORG/BRN WIRE
ORG/GRN WIRE
PASS SIDE EXIT WARNING LAMP
PASSENGER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR
PASSENGER SIDE EXIT WARNING LAMP
PASSENGER SIDE EXTERIOR MIRROR ENTRY LIGHT
PASSENGER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP
POSITIVE
POWER
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
REVERSING LIGHT SWITCH
RIGHT FRONT FUSE BOX
RIGHT FRONT HEADLIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL, SIDE LIGHT
RIGHT NUMBER PLATE LIGHT
RIGHT REAR FOG LIGHT
RIGHT TAIL LIGHT CLUSTER
SIDE MARKER LIGHT
SIGNAL
STOP LIGHT
TERM 30
TERM 30 SWITCHED
TERM 31
TURN SIGNAL
TURN SIGNAL LIGHT
VIO/WHT WIRE
WARNING LIGHT EXTERIOR MIRR
WHT/VIO WIRE
Go to component -> Exterior lights circuit (2 of 2) -> PASS SIDE EXIT WARNING LAMP
