Porsche 911 Carrera 992 (2018-2024) lh vers hall perf Wiring diagram
This page shows the only wiring diagram for the component.lh vers hall perf, which is found in the car Porsche 911 Carrera 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh vers hall perf (1 of 1)
AERODYNAMICS CONTROL UNIT
BATT DC OUTPUT
BATT LOGIC
BATT PWM OUTPUT
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMFORT CAN HIGH
COMFORT CAN LOW
COMPUTER DATA LINES SYSTEM
FRONT SPOILER POSITION SENSOR
FUSE 12
FUSE 16
FUSE 2
FUSE 7
FUSE 9
FUSE HOLDER P
FUSE HOLDER Q
FUSE HOLDER S
GND DC OUTPUT
GND PWM OUTPUT
GRN/WHT WIRE
GRN/YEL WIRE
GRY/WHT WIRE
HALL REAR SPOILER SPLY
HOT AT ALL TIMES
LH SPOILER HALL CW
LH SPOILER HALL PERF
LH VERS HALL CW
LH VERS HALL PERF
N/A
NTC GND MOTOR
NTC MOTOR
ORG/BRN WIRE
ORG/GRN WIRE
PUMP
PUMP GND
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RH SPOILER HALL CW
RH SPOILER HALL PERF
RH VERS HALL CW
RH VERS HALL PERF
VALVE 1 SIG +
VALVE 1, 2 GND
VALVE 2 PRESS 2
VALVE 2 SIG +
VALVE 2 SPLY +
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Active rear spoiler circuit, w/ aerodynamics (1 of 2) -> LH VERS HALL PERF
