Porsche 911 Carrera 992 (2018-2024) left cooling flap position sender Wiring diagrams
This page contains all the electrical diagrams for the component. left cooling flap position sender, in which he is found in the car Porsche 911 Carrera 992 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left cooling flap position sender wiring diagram (1 of 2)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/VIO WIRE
ENGINE COMPARTMENT COOLING FAN
ENGINE COMPARTMENT COOLING FAN 2
FUSE 2
FUSE 7
FUSE 8
FUSE HOLDER C
FUSE HOLDER L
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FLAP POSITION SENDER
LEFT FAN RELAY
MAIN FUSE BOX
PWM
RADIATOR BLIND CONTROL MOTOR
RADIATOR BLIND CONTROL MOTOR 2
RADIATOR FAN RELAY (MAIN FUSE BOX)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FAN RELAY
RIGHT FRONT FUSE BOX
SIGNAL
TERM 30
TERM 31
TERM 87
VIO/WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> LEFT COOLING FLAP POSITION SENDER
