Rear axle steering circuit for Porsche 911 Carrera S 992 (2018-2024)
Rear axle steering circuit
BRN WIRE
CAN PRIVATE HIGH CAN PRIVATE LOW
CAN PRIVATE LOW
COMPUTER DATA LINES SYSTEM
FLEXRAY 1- INPUT
FLEXRAY 1- INPUT PNK FLEXRAY 1+ OUTPUT WIRE
FLEXRAY 1- OUTPUT CAN PRIVATE HIGH
FUSE 6
GRN WIRE
GROUND
HOT AT ALL TIMES
LEFT "C" PILLAR)
MAIN FUSE BOX
ORG/BRN WIRE
ORG/WHT WIRE
PNK FLEXRAY 1+ INPUT WIRE
REAR WHEEL STEERING CONTROL UNIT
REAR WHEEL STEERING CONTROL UNIT 2
RED/BLU WIRE
TERM 30
