Porsche 911 Carrera S 992 (2018-2024) coding pin fs bfs Wiring diagram
This page shows the only wiring diagram for the component.coding pin fs bfs, which is found in the car Porsche 911 Carrera S 992 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coding pin fs bfs (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
CODING PIN FS BFS
COMPUTER DATA LINES SYSTEM
DRIVER MULTI-CONTOUR SEAT CONTROL UNIT
DRIVER SEAT MULTI-CONTOUR COMPRESSOR
FUSE 16
FUSE HOLDER A
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
KL 31 PNEUMATICS
LEFT "C" PILLAR)
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LIN
LIN 2
LNV TASTER
LORD HIGH LOW
LORD NEXT PREVIOUS
MAIN FUSE BOX
N/A
ORG/BRN WIRE
PUMPE VERS +
RED WIRE
RED/WHT WIRE
SHV TASTER
SLV TASTER
SNV TASTER
STV BEFORE RETURN
STV TASTER
SUPPLY
TERM 30
TERM 30 SWITCHED
TERM 31
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
WANGENV L OPEN-CLOSE
WANGENV SI ON TO
WHT WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit (1 of 2) -> CODING PIN FS BFS
