Wiring diagrams for Porsche 911 Carrera GTS 992 (2018-2024)

Active rear spoiler circuit, w/ aerodynamics Active rear spoiler circuit, w/o aerodynamics Virtual engine sound system circuit

Automatic a/c circuit

Anti-lock brakes circuit

Anti-theft circuit

Body control modules circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defogger circuit Heated mirrors circuit

Electronic power steering circuit Power tilt steering column circuit Rear axle steering circuit

Electronic suspension circuit

Wiring diagram engine performance 3.0l turbo

Wiring diagram engine performance 3.8l turbo

Exterior lights circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit Night vision circuit

Interior lights circuit

Driver"s memory seat circuit Memory mirrors circuit Passenger"s memory seat circuit Steering column memory circuit

Emergency call circuit Lane change assistance circuit Navigation circuit, base Navigation circuit, premium w/ bose Navigation circuit, premium w/ burmester Parking assistant circuit Real top view circuit Rear camera circuit Vehicle positioning system circuit

Power distribution circuit

Power door locks circuit

Auto anti-dazzling mirror circuit Power mirrors circuit

Driver heated seat circuit Driver power seat circuit Front passenger heated seat circuit Front passenger power seat circuit

Convertible top circuit Sunroof circuit

Power windows circuit

Base radio circuit Optical wave guide circuit Premium radio circuit, w/ bose Premium radio circuit, w/ burmester

Electronic parking brake circuit Shift interlock circuit

Charging circuit Starting circuit

Supplemental restraints circuit

A/t circuit Awd circuit Rear differential lock circuit

Tailgate & fuel door release circuit

Warning systems circuit

Front wiper/washer circuit Rear wiper circuit

ALARM HORN AMPLIFIER FOR BASS LOUDSPEAKER ANTI-LOCK BRAKES SYSTEM BACKUP HORN BACKUP HORN SIREN BASS HORN BODY GROUND CENTRAL LOCK ROTARY LATCH CENT LOCK ROTARY LATCH CENTER LOCK SAFE LOCKED STATUS CENTRAL LOCK CENTRAL LOCK ROTARY LATCH CENTRAL LOCK SAFE LOCKED STATUS CENTRAL LOCK SHIELD CENTRAL LOCK SYSTEM CENTRAL LOCKING FRONT PASSENGER SIDE SAFE LOCK FUNCTION WARNING LAMP CENTRAL LOCKING SAFE LOCK FUNCTION WARNING LAMP COIL 1 COIL 2 DIGITAL SOUND PACKAGE AMPLIFIER ELECT IGNITION LOCK SW 1 ELECT IGNITION LOCK SW 2 ELECT IGNITION LOCK SW 3 ELECT IGNITION LOCK SW 4 HORN O/P HORN OUTPUT LOCK TANK LID LOCK WARNING LAMP MOBILE TELEPHONE AERIAL AMPLIFIER MS VG IN LOCK ITEM START LOCK STARTER TERMINAL 50 STEERING COLUMN LOCK CONTROL ELEMENT TERM 30 HORN TREBLE HORN W/ BOSE AMPLIFIER W/ BURMESTER AMPLIFIER

ADJUSTABLE REAR SPOILER MOTOR ADJUSTING MOTOR 1+2 AIR RECIRCULATION FLAP CONTROL MOTOR ANGLE MOTOR ENTER + ANGLE MOTOR EXTEND + ANTI-ROLL BAR UNCOUPLING MOTOR CABRIOLET WINDBREAK MOTOR CENTER FLAP CONTROL MOTOR CENTER LOCK MOTOR LOCK CENTER LOCK MOTOR UNLOCK CENTER LOCKING MOTOR SAFE CENTRAL LOCK MOTOR LOCK CENTRAL LOCK MOTOR LOCK CENTRAL LOCKING MOTOR SAFE CENTRAL LOCK MOTOR SAFE/LOCK CENTRAL LOCK MOTOR UNLOCK CENTRAL LOCKING MOTOR SAFE CNT LOCK MOTOR LOCK CONVERTIBLE ROOF BOX LID LOCK MOTOR DC MOTOR + DEFROSTER FLAP CONTROL MOTOR DRIVER SEAT DEPTH ADJUSTMENT MOTOR DRIVER SIDE FOLD-IN MIRROR MOTOR DRIVER SIDE MIRROR ADJUSTMENT MOTOR DRIVER SIDE MIRROR ADJUSTMENT MOTOR 2 ENGINE + LOCKING ENGINE + UNLOCKING ENGINE COMPARTMENT COOLING ENGINE COMPARTMENT COOLING FAN ENGINE COMPARTMENT COOLING FAN 2 ENGINE CONTROLS SYSTEM ENGINE CONTROLS, ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS ENGINE CONTROLS, ANTI-LOCK BRAKES, EXTERIOR LIGHTS SYSTEMS ENGINE CONTROLS, INSTRUMENT CLUSTER SYSTEMS ENGINE GROUND ENGINE SENDER TEMP REGULATION ENGINE SENDER TEMPERATURE REGULATION ENGINE SPEED SENDER FOOTWELL FLAP CONTROL MOTOR FRESH AIR FLAP CONTROL MOTOR FRONT LUGGAGE COMPARTMENT MANUAL RELEASE ACTUATOR FRONT LUGGAGE COMPARTMENT RELEASE ACTUATOR FRONT PASSENGER SEAT DEPTH ADJUSTMENT MOTOR FRONT PASSENGER SIDE FOLD-IN MIRROR MOTOR FRONT PASSENGER SIDE MIRROR ADJUSTMENT MOTOR FRONT PASSENGER SIDE MIRROR ADJUSTMENT MOTOR 2 FUEL TANK FILLER FLAP CENTRAL LOCKING ACTUATOR GND ENGINE GND FOR ACTUATOR SENS HALL INK ANGLE MOTOR HALL INK ANGLE MOTOR VCC HALL INK LIFT MOTOR VEC HALL INK RH ANGLE MOTOR HALL INT LIFT MOTOR HALL POS ANGLE MOTOR HALL POS LIFT MOTOR HALL POS LIFT MOTOR VCC HYDRAULIC PUMP MOTOR INDIRECT VENTILATION FLAP CONTROL MOTOR LEFT EPB MOTOR + LEFT FRONT BACKREST ADJUSTMENT MOTOR LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR LEFT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR LEFT FRONT SEAT RAKE ADJUSTMENT MOTOR LEFT PARKING BRAKE MOTOR LEFT TEMPERATURE FLAP CONTROL MOTOR LIFT MOTOR ENTER + LIFT MOTOR EXTEND + MAP-CONTROLLED ENGINE COOLING SYSTEM THERMOSTAT MIRROR ADJUSTMENT MOTOR X MIRROR ADJUSTMENT MOTOR Y MOTOR 1 MOTOR 1 EXTENSION MOTOR 1 RETRACTION MOTOR 2 MOTOR 2 EXTENSION MOTOR 2 RETRACTION MOTOR A MOTOR B MOTOR ROOF LOCK + MOTOR ROOF UNLOCK + MOTOR VCC NTC GND MOTOR NTC MOTOR RADIATOR BLIND CONTROL MOTOR RADIATOR BLIND CONTROL MOTOR 2 RADIATOR BLIND CTRL MOTOR REAR WINDOW WIPER MOTOR RIGHT EPB MOTOR - RIGHT FRONT BACKREST ADJUSTMENT MOTOR RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR RIGHT FRONT SEAT LONGITUDINAL ADJUSTMENT MOTOR RIGHT FRONT SEAT RAKE ADJUSTMENT MOTOR RIGHT PARKING BRAKE MOTOR RIGHT TEMPERATURE FLAP CONTROL MOTOR SLIDING SUNROOF MOTOR SO ENGINE WIND DEFLECTOR - STEERING COLUMN AXIAL ADJUSTMENT MOTOR STEERING COLUMN VERTICAL ADJUSTMENT MOTOR TAILGATE RELEASE ACTUATOR TEMPERATURE SENDER FOR ENGINE TEMPERATURE REGULATION THROTTLE VALVE MOTOR + VALVE BLOCK ON ENGINE WIND DEFLECTOR MOTOR X-AXLE ADJUSTING MOTOR Y-AXLE ADJUSTING MOTOR

ANTENNA FRONT CENTER CONSOLE ANTENNA ON FRONT CENTER CONSOLE ANTENNA ON FRONT CENTER CONSOLE REAR LID ROTARY LATCH CONTACT COUPLING BOX TELEPHONE ANTENNA DRIVER CARD ANTENNA FRONT PARKING ANTENNA GPS ANTENNA GSM ANTENNA GSM ANTENNA 3 LEFT REAR ANTENNA LUGGAGE COMPARTMENT ANTENNA LUGGAGE COMPT ANTENNA REAR LEFT ANTENNA REAR RIGHT ANTENNA RIGHT REAR ANTENNA

ADJ BUTTON + ADJUST BUTTON + DRIVER PWR WINDOW BUTTON DRIVER SIDE CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON DRIVER SIDE WINDOW REGULATOR MOTOR ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTROMECHANICAL PARKING BRAKE BUTTON FRONT PASSENGER DOOR WINDOW REGULATOR SWITCH FRONT PASSENGER SIDE CENTRAL LOCKING SYSTEM INTERIOR LOCKING BUTTON FRONT PASSENGER SIDE WINDOW REGULATOR MOTOR FRT PASS PWR WINDOW BUTTON IGNITION, LIGHT BUTTON MODULE LEFT REAR WINDOW REGULATOR MOTOR LOCKING BUTTON LED LUGGAGE COMPARTMENT MANUAL RELEASE BUTTON MASSAGE BUTTON MEM BUTTON LED MEM BUTTON MOD MEM BUTTON MOD MEM BUTTON MEM SET BUTTON MEMORY BUTTON MEMORY BUTTON LED MEMORY BUTTON MOD MEMORY BUTTON MODULE MEMORY SET BUTTON PARK ASSIST STEERING BUTTON PRESSURE REGULATOR 1 PRESSURE REGULATOR 2 PRESSURE REGULATOR 3 PRESSURE REGULATOR 4 PRESSURE REGULATOR 5 PRESSURE REGULATOR 6 PRESSURE REGULATOR 7 PRESSURE REGULATOR 8 RIGHT REAR WINDOW REGULATOR MOTOR WINDOW REGULATOR BUTTON

CAMERA GROUND CAMERA SUPPLY FRONT CAMERA FRONT CAMERA DRIVER ASSIST SYSTEMS FRONT CAMERA GROUND FRONT OVERHEAD VIEW CAMERA FRT OVERHEAD VIEW CAMERA LEFT OVERHEAD VIEW CAMERA LH OVERHEAD VIEW CAMERA NIGHT VISION SYSTEM CAMERA REAR CAMERA GROUND REAR OVERHEAD VIEW CAMERA RH OVERHEAD VIEW CAMERA RR OVERHEAD VIEW CAMERA

B+ SOCKET PASSENGER'S SIDE 12 V SOCKET

ADAPTIVE CRUISE CONTROL UNIT ADAPTIVE SUSPENSION CONTROL UNIT ADJUSTABLE REAR SPOILER CONTROL UNIT AERODYNAMICS CONTROL UNIT AIR BAG CONTROL UNIT ALL-WHEEL DRIVE CONTROL UNIT AUDIO, VIDEO ADDITIONAL CONNECTIONS UNIT AUTOMATIC GEARBOX CONTROL UNIT BATTERY MONITOR CONTROL UNIT BRAKE SERVO CONTROL UNIT COMMUNICATION UNIT, EMERGENCY CALL MODULE CONTROL UNIT CONTROL UNIT GND CONTROL UNIT) CONVERTIBLE ROOF ACTUATION CONTROL UNIT CONVERTIBLE ROOF LOCK UNIT DRIVER ASSIST SYSTEMS CONTROL UNIT DRIVER ASSISTANT SYSTEM CONTROL UNIT DRIVER DOOR CONTROL UNIT DRIVER DOOR WINDOW REGULATOR OPERATING UNIT DRIVER MULTI-CONTOUR SEAT CONTROL UNIT DRIVER SIDE CENTRAL LOCKING LOCK UNIT DUAL CLUTCH GEARBOX MECHATRONIC UNIT ELECTRICALLY ADJUSTABLE STEERING COLUMN CONTROL UNIT ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT EMERGENCY CALL MODULE CONTROL UNIT, COMMUNICATION UNIT ENGINE CONTROL UNIT ENGINE SOUND GENERATOR CONTROL UNIT 2 ENGINE/ MOTOR CONTROL UNIT ENGINE/MOTOR CONTROL UNIT ENGINE/MOTOR CONTROL UNIT 2 EXHAUST FLAP CONTROL UNIT EXHAUST FLAP CONTROL UNIT 2 FRONT AXLE LIFT SYSTEM CONTROL UNIT FRONT PASSENGER AIR BAG UNIT FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL UNIT FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT FUEL DELIVERY UNIT FUEL PUMP CONTROL UNIT GARAGE DOOR OPERATION CONTROL UNIT GND, CTRL UNIT LANE CHANGE ASSIST CONTROL UNIT LANE CHANGE ASSIST CONTROL UNIT 2 LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT MULTIMEDIA SYSTEM OPERATING UNIT MULTIMEDIA SYSTEM OPERATING, DISPLAY UNIT NIGHT VISION SYSTEM CONTROL UNIT ONBOARD SUPPLY CONTROL UNIT ONBOARD SUPPLY CONTROL UNIT 2 ONBOARD SUPPLY CONTROL UNIT RELAY POWER UNIT MOUNTING CONTROL UNIT RADIO CONTROLLED PARKING CONTROL UNIT REAR WHEEL STEERING CONTROL UNIT REAR WHEEL STEERING CONTROL UNIT 2 REVERSING CAMERA SYSTEM CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT SEAT OCCUPIED RECOGNITION CONTROL UNIT SELECTOR LEVER SENSORS CONTROL UNIT SERVOTRONIC CONTROL UNIT SLIDING SUNROOF ADJUSTMENT CONTROL UNIT STEERING COLUMN ELECTRONICS CONTROL UNIT TELEPHONE, TELEMATICS CONTROL UNIT TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT VEHICLE LOCATION SYSTEM CONTROL UNIT WIND DEFLECTOR CONTROL UNIT WINDOW DEFLECTOR CONTROL UNIT

FUSE 1 FUSE 1 N/A FUSE 2 FUSE 2 FUSE 1 FUSE 2 N/A FUSE 3 FUSE 3 N/A FUSE 4 FUSE 4 N/A FUSE 5 FUSE 5 N/A FUSE 6 FUSE 6 N/A FUSE 7 FUSE 7 N/A FUSE 8 FUSE 8 N/A FUSE 9 FUSE 9 N/A FUSE 10 FUSE 10 N/A FUSE 11 FUSE 11 N/A FUSE 12 FUSE 12 N/A FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 16 N/A FUSE BOXES FUSE CARRIER 1 FUSE CARRIER 2 FUSE CARRIER 3 FUSE HOLDER A FUSE HOLDER B FUSE HOLDER C FUSE HOLDER D FUSE HOLDER E FUSE HOLDER F FUSE HOLDER J FUSE HOLDER K FUSE HOLDER L FUSE HOLDER M FUSE HOLDER N FUSE HOLDER P FUSE HOLDER Q FUSE HOLDER S FUSE HOLDER U FUSE HOLDER V MAIN FUSE BOX REAR FUSE BOX RIGHT FRONT FUSE BOX

HEADLIGHT TERM 30 WASHER SYSTEM HEADLIGHT WASHER PUMP HEADLIGHT WASHER SYSTEM PUMP LEFT FRONT HEADLIGHT RIGHT FRONT HEADLIGHT

DOOR MIRROR HEATING DOOR MIRROR HEATING GROUND FOR FR SEAT HEATING BACKREST FR SEAT HEATING SURFACE HEATER BANK 2 LEFT FRONT SEAT EXTENSION HEATER ELEMENT LF SEAT HEATING BACKREST LF SEAT HEATING SENS LF SEAT HEATING SENS BACKREST LF SEAT HEATING SENS SURFACE LF SEAT HEATING SURFACE POSITIVE CONNECTION AUXILIARY HEATER WIRING HARNESS REAR WINDOW HEATER REAR WINDOW HEATING+ RF SEAT HEATING SENS BACKREST RF SEAT HEATING SENS SURFACE RH SEAT HEATING BACKREST RH SEAT HEATING SENS RH SEAT HEATING SURFACE RIGHT FRONT SEAT EXTENSION HEATER ELEMENT SEAT HEATING IN - SEAT HEATING OUT + TANK LEAKAGE DIAGNOSTICS HEATER

COOLANT SHORTAGE INDICATOR SENDER

DOOR HANDLE ILLUMINATION BULB DRIVER DOOR STORAGE COMPARTMENT ILLUMINATION BULB DRIVER SIDE EXIT WARNING LAMP DRIVER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP FRONT PASSENGER DOOR STORAGE COMPARTMENT ILLUMINATION BULB FRONT PASSENGER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP HAND BRK WARN LAMP HANDLE ILL BULB SHELL HIGH-LEVEL BRAKE LIGHT BULB HIGH-LEVEL BRAKE LIGHT BULB 2 INTERIOR LIGHTS, DOOR LOCKS, ANTI-THEFT SYSTEMS INTERIOR LIGHTS, HEADLIGHTS SYSTEMS PASS SIDE EXIT WARNING LAMP PASSENGER SIDE EXIT WARNING LAMP PASSENGER SIDE EXTERIOR MIRROR LANE CHANGE ASSIST WARNING LAMP

ALL WHEEL DRIVE PUMP AUXILIARY PUMP FOR HEATING AUXILIARY PUMP HEATING CONTINUED COOLANT CIRCULATION PUMP CONTROLLED WATER PUMP HS VLV CONTROLLED WATER PUMP LS VLV CONVERTIBLE ROOF ACTUATION HYDRAULIC PUMP FUEL SYSTEM DIAGNOSTIC PUMP HYDRAULIC PUMP MTR HYDRAULIC PUMP VG CLOSE + CLOSE CTRL VLV + MTR HYDRAULIC PUMP VG OEFF + SI TEMP HYDRAULICS PUMP GND PUMP PHASE A PUMP PHASE B PUMP VERS + TANK LEAKAGE DIAGNOSIS PUMP WASHER PUMP WATER PUMP

HEATED REAR WINDOW RELAY HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED LEFT FAN RELAY LEFT FAN RELAY RADIATOR FAN RELAY MAIN RELAY PLUG SOCKETS OUTPUT RELAY F RADIATOR FAN RELAY RELAY A RELAY A STARTER MOTOR RELAY RELAY B RELAY KL 15 RIGHT FAN RELAY RIGHT FAN RELAY RADIATOR FAN RELAY STARTER MOTOR RELAY STARTER RELAY 1 STARTER RELAY 2 TERMINAL 15 VOLTAGE SUPPLY RELAY

5 V SENSOR GROUND DISTANCE SENSOR 5 V SENSOR GROUND PRESSURE SENSOR 5 V SUPPLY DISTANCE SENSOR 5 V SUPPLY PRESSURE SENSOR 9 V SENSOR GROUND AIR CONDITIONER SENSOR FOR FINE PARTICLE CONCENTRATION AIR HUMIDITY RAIN, LIGHT SENSOR AIR QUALITY SENSOR AMBIENT TEMPERATURE SENSOR AUTOMATIC HEATER CONTROL INTERIOR SENSOR BRAKE FLUID SENSOR COOLANT TEMPERATURE SENSOR DETECTION SENSOR DISTANCE SENSOR 1 DISTANCE SENSOR 2 DISTANCE SENSOR 3 DISTANCE SENSOR 4 DISTANCE SENSOR 5 DRIVER SIDE AIR BAG PRESSURE SENSOR DRIVER SIDE AIR BAG, HEAD CRASH SENSOR B-PILLAR DRIVER SIDE SEAT POSITION SENSOR DRIVER SIDE UP FRONT SENSOR DRV DOOR PRESSURE SENSOR DRV SIDE AIR BAG CRASH SENSOR EVAPORATOR TEMPERATURE SENSOR FL PROX SENSOR SUPPLY FR PROX SENSOR SUPPLY FRONT PASSENGER AIR BAG, HEAD CRASH SENSOR FRONT PASSENGER SEAT OCCUPIED SENSOR FRONT PASSENGER SEAT POSITION SENSOR FRONT PASSENGER UP FRONT SENSOR FRONT SPOILER POSITION SENSOR FRT PASS SIDE AIR BAG CRASH SENSOR FRT PRESSURE SENSOR PASS DOOR FRT SEAT OCCUP DETECTION SENSOR GLASS BREAKAGE SENSOR FOR REAR WINDOW HALL SENDER 2 INTAKE CAMSHAFT SENSOR BANK 2 HALL SENDER 3 OUTLET CAMSHAFT SENSOR BANK 1 HALL SENDER 4 OUTLET CAMSHAFT SENSOR BANK 2 HALL SENDER INTAKE CAMSHAFT SENSOR BANK 1 HALL SENSOR HALL SENSOR 1 HALL SENSOR 2 HALL SENSOR SIGNAL INTAKE-MANIFOLD PRESSURE SENSOR KNOCK SENSOR 1 KNOCK SENSOR #2 LAMBDA PROBE 1 AFTER CATALYTIC CONVERTER LAMBDA PROBE 1 BEFORE CATALYTIC CONVERTER LAMBDA PROBE 2 AFTER CATALYTIC CONVERTER LAMBDA PROBE 2 BEFORE CATALYTIC CONVERTER LEFT AQUAPLANING WARNING SENSOR LEFT FRONT CHEST VENT TEMPERATURE SENSOR LEFT FRONT SPEED SENSOR LEFT REAR SPEED SENSOR LF PROX SENSOR SUPPLY LH SENSOR OIL PRESSURE SENSOR GROUND PASS UP FRONT SENSOR + PEDAL SENSOR 1 DIGITAL SIG PEDAL SENSOR 1 GND PEDAL SENSOR 1 SIGNAL PEDAL SENSOR 2 GND PEDAL SENSOR 2 SIGNAL PEDAL VALUE SENSOR 1 PEDAL VALUE SENSOR 2 PRESS SENSOR GND PRESSURE SENSOR PRESSURE SENSOR 1 PRESSURE SENSOR 2 PRESSURE SENSOR 3 PRESSURE SENSOR CONTR REAR DIFF LOCK PRESSURE SENSOR SIGNAL RF PROX SENSOR SUPPLY RH SENSOR RIGHT FRONT CHEST VENT TEMPERATURE SENSOR RIGHT FRONT SPEED SENSOR RIGHT REAR SPEED SENSOR RL PROX SENSOR SUPPLY SENSOR ACTUAL VALUE 1 SENSOR ACTUAL VALUE 2 SENSOR GROUND SENSOR SUPPLY SENSOR SUPPLY 1 SENSOR SUPPLY 2 SENSOR SUPPLY 3 DISTANCE SENSOR 3 SUNLIGHT PENETRATION PHOTO SENSOR TANK BREATHER PRESSURE SENSOR 1 TEMP SENSOR SIGNAL TEMPERATURE SENSOR UP FRONT SENSOR DRIVER + WASHER FLUID LEVEL SENSOR WASHER FLUID LEVEL SENSOR SENSOR GROUND WIND DEFLECTOR HALL SENSOR

CENTER SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT REAR MID-RANGE SPEAKER LF LOW RANGE SPEAKER - LR MID-RANGE SPEAKER + LR MID-RANGE SPEAKER - RR MID-RANGE SPEAKER - REMOTE SUBWOOFER RF LOW RANGE SPEAKER - RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TREBLE SPEAKER RL MID-RANGE SPEAKER - RR MID-RANGE SPEAKER + SUBWOOFER LOADSPACE FLOOR

AIR CONDITIONING SYSTEM PRESSURE SWITCH BONNET CONTACT SWITCH BRAKE LIGHT SWITCH CENTER CONSOLE SWITCH MODULE 1 CENTER DASH PANEL SWITCH MODULE CENTER LOCK KEY SWITCH CENTRAL DASH PANEL SWITCH MODULE CHILDPROOF LOCK SWITCH CLUTCH PEDAL SWITCH CONVERTIBLE ROOF BOX LID CLOSED SWITCH CONVERTIBLE ROOF BOX LID OPEN SWITCH CONVERTIBLE ROOF LOCKING READINESS SWITCH CRUISE CONT MAIN SWITCH DRIVER INTERIOR DOOR HANDLE SWITCH DRIVER SIDE BELT SWITCH FRONT AXLE ANTI-ROLL BAR UNCOUPLING SWITCH VALVE FRONT PASSENGER INTERIOR DOOR HANDLE SWITCH FRONT PASSENGER SIDE AIR BAG DEACTIVATE KEY OPERATED SWITCH KEY SWITCH OPEN/CLOSE LEFT CONVERTIBLE ROOF BOX LID CLOSED SWITCH LEFT CONVERTIBLE ROOF BOX LID OPEN SWITCH LEFT FRONT BELT SWITCH LEFT REAR BELT SWITCH LUGGAGE COMPARTMENT LIGHT SWITCH LUGGAGE COMPARTMENT RELEASE SWITCH MIRROR ADJUSTMENT SWITCH MIRROR SELECTION SWITCH MUFU ROTARY SWITCH POWER WINDOW SWITCH LEFT POWER WINDOW SWITCH RIGHT REAR AXLE ANTI-ROLL BAR UNCOUPLING SWITCH VALVE REAR LID CLOSED SWITCH REAR WIPER MOTOR SWITCH REED SWITCH A REED SWITCH B REVERSING LIGHT SWITCH RIGHT CONVERTIBLE ROOF BOX LID CLOSED SWITCH RIGHT FRONT BELT SWITCH RIGHT REAR BELT SWITCH STEERING COLUMN ADJUSTMENT SWITCH SWITCH 1 SWITCH 2 SWITCH 3 SWITCH 4 TAILGATE RELEASE SWITCH TERM 31 INTERIOR LOCKING SWITCH UNLOCK FRONT LID BRAKE LIGHT SWITCH

A/C COMPRESSOR VALVE + CAMSHAFT CONTROL VALVE 1 CAMSHAFT CONTROL VALVE 2 BANK 2 CONTROL VALVE DRAIN VALVE EXHAUST CAMSHAFT CONTROL VALVE 1 BANK 1 EXHAUST CAMSHAFT CONTROL VALVE 2 BANK 2 FLOW CONTROL VALVE 1 HS FLOW CONTROL VALVE 1 LS FLOW CONTROL VALVE 2 HS FLOW CONTROL VALVE 2 LS FRT PASS AIR BAG IGNITER EXHAUST VALVE FUEL METERING VALVE FUEL METERING VALVE 2 HEATER SHUT-OFF VALVE HEATER SHUTOFF VALVE HYDRAULIC CONTROL VALVE 1 HYDRAULIC CONTROL VALVE 2 INLET CAMSHAFT CONTROL VALVE 1 INLET CAMSHAFT CONTROL VALVE 2 INLET CAMSHAFT CTRL VALVE 1 INLET CAMSHAFT CTRL VALVE 2 LEFT FRONT SHOCK ABSORBER DAMPING ADJUSTMENT VALVE LEFT REAR SHOCK ABSORBER DAMPING ADJUSTMENT VALVE OIL PRESSURE CONTROL VALVE OVERRUN AIR RECIRCULATION VALVE BANK 1 OVERRUN AIR RECIRCULATION VALVE BANK 2 RIGHT FRONT SHOCK ABSORBER DAMPING ADJUSTMENT VALVE RIGHT REAR SHOCK ABSORBER DAMPING ADJUSTMENT VALVE SOLENOID VALVE 1 SOLENOID VALVE 2 SOLENOID VALVE 3 SOLENOID VALVE 5, PARKING LOCK TANK BREATHER VALVE TANK VENT VALVE 1 THROTTLE VALVE ACTVAL 1 THROTTLE VALVE ACTVAL 2 THROTTLE VALVE GND THROTTLE VALVE MODULE VALVE 1 CTRL VALVE 1 PRESS 1 VALVE 1 SIG + VALVE 1 SPLY CW VALVE 1 VERS + VALVE 1 VERS GND VALVE 1, 2 GND VALVE 2 PRESS 2 VALVE 2 SIG + VALVE 2 SPLY + VALVE 2 VERS +

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN LOW PNK VIDEO OUT 1- WIRE FLEXRAY 1- INPUT PNK FLEXRAY 1+ OUTPUT WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/RED WIRE ORG/VIO WIRE ORG/WHT WIRE PNK ETHERNET DATA + WIRE PNK FLEXRAY 1+ INPUT PNK FLEXRAY 2+ OUTPUT WIRE PNK FLEXRAY 1+ INPUT WIRE PNK FLEXRAY 2+ OUTPUT PNK FLEXRAY 2+ INPUT PNK FLEXRAY 2- OUTPUT WIRE PNK FLEXRAY 2+ OUTPUT PNK FLEXRAY 2+ INPUT WIRE PNK FR BP A WIRE PNK VIDEO IN- WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

1 2 GND, BODY 2+ OUT 4-WAY SEATS 14/18-WAY SEATS +5 V ACC SENS HL+ ACC SENS VL- ACC SENS VR- ACCELERATOR PEDAL MODULE ACTIVE BODYWORKS SYSTEM ACTUAL VALUE 1 ACTUAL VALUE 2 ACTUATORS/ SENSORS ADDITIONAL INSTRUMENTS ADJUST MIRROR, LEFT ADJUST MIRROR, RIGHT AERIAL, IN REAR LOUDSPEAKER WIRING HARNESS CONNECTION AIR BAG 1- AIR BAG 2+ AIR BAG IGNITER AIR BAG OFF SW L 1 AIR BAG OFF SW L 2 AIR BAG PULSE AIR BAG PWM AIR BAG STAGE 1 + AIR BAG STAGE 2 - AIR CONDITIONING SYSTEM AIRBAG PULSE WIDTH MODULATION ALL-WHEEL DRIVE HYDRAULIC TEMPERATURE SENDER AM/FM 1 AMBIENT LIGHT LIN ANALOG GND ANALOG GROUND ANGLE OF ROTATION HOOD ANT GROUND SHLD ANTI DAZZLE MIRROR BATT DC OUTPUT BATT LOGIC BATT PWM OUTPUT BELT FORCE LIMITER + BELT TENSIONER + BLUETOOTH MOBILE PHONE COUPLING AERIAL BLUETOOTH, FRONT BLUETOOTH, REAR BLUTOOTH, REAR BODY GND BONNET CONTACT SW BONNET OPENING SENDER BOOST PRESS ADJUSTER 1 BOOST PRESS ADJUSTER 1 MTR + BOOST PRESS ADJUSTER 1 SENS + BOOST PRESS ADJUSTER 2 BOOST PRESS ADJUSTER 2 MTR - BOOST PRESS ADJUSTER 2 SENS + BOOST PRESS ADJUSTER 2 SIG BOOST PRESSURE ADJUSTER 1 SIG BRAKE FLUID BRAKE FLUID LEVEL BRAKE FLUID LEVEL WARNING CONTACT BRAKE LIGHT BRAKE PAD BRAKE PAD SENS CAMSHAFT CONTROLLER 1 INTAKE CAMSHAFT CONTROLLER 2 INTAKE CAN AFS HI CAN AFS HIGH CAN AFS LO CAN AFS LOW CAN CHASSIS HI CAN CHASSIS LO CAN COMFORT 2 HI CAN COMFORT HI CAN COMFORT HIGH CAN COMFORT LO CAN COMFORT LOW CAN CONNECT HI CAN CONNECT LO CAN DIAGNOSTICS HI CAN DIAGNOSTICS LO CAN DRIVE 1 HIGH CAN DRIVE 1 LOW CAN DRIVE HIGH CAN DRIVE LOW CAN EXTENDED HI CAN EXTENDED HIGH CAN EXTENDED LO CAN EXTENDED LOW CAN EXTENDED LW CAN HI CAN HIGH CAN HYBRID HI CAN INFO HI CAN INFO HIGH CAN INFO LO CAN INFO LOW CAN INSTR CLUSTER HI CAN INSTR CLUSTER LO CAN L CAN LO CAN LOW CAN MIB HIGH CAN MIB LOW CAN PRIVAT HI CAN PRIVAT LO CAN PRIVATE HIGH CAN PRIVATE LOW CAN PRIVATE LOW CAN TERMINATION HIGH CAN TERMINATION LOW CAPACITOR 1 CENTER CONSOLE BACKGROUND LIGHTING 1 CENTER CONSOLE BACKGROUND LIGHTING 2 CENTER COUPLING POINT IN LUGGAGE COMPARTMENT CENTER HI RANGE LOUDSPEAKER CENTER LOUDSPEAKER CENTER LOUDSPEAKER 2 CENTER REAR OF LUGGAGE COMPT) CENTER TAIL LIGHT CLUSTER CENTRAL LOCKING SHIELD CENTRAL LOCKING SYSTEM CENTRAL VENT DASH PANEL ILLUMINATION CHANNEL 1 CHANNEL 2 - CHARGE PRESSURE POSITIONER 2 WASTEGATE BANK 2 CHARGE PRESSURE POSITIONER WASTEGATE BANK 1 CHARGE PRESSURE SENDER CLASS 31 PNEUMATICS CLOSE FSK + / CLOSING AID - CODIERPIN 1 CODIERPIN 3 CODING PIN FS BFS COMFORT CAN HIGH COMFORT CAN LOW COMFORT HI COMFORT LO COMPRESSOR CLUTCH COMPRESSOR RR + COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEMS CONNECTION 3, IN REAR RIGHT DOOR WIRING HARNESS CONTINUED COOLANT CIRCULATION CONTROL ELEMENT 4 COOLANT TEMP SENDER COOLANT TEMPERATURE SENDER COOLANT TEMPERATURE SENDER CYLINDER HEAD COOLANT TEMPERATURE SENS COOLING FANS SYSTEM CPRESS SENS 1 + TANK VENT CRASH SIGNAL CRUISE CONTROL SYSTEM DASH PANEL INSERT DATA BUS DIAGNOSTIC INTERFACE DECKEL OEF VO HI DEFOGGER SYSTEM DIAGNOSTIC CONNECTION DIFF-PRESS SENS DIFF-PRESS SENS PARTICULATE FILTER 2 + DIFF-PRESSURE SENS DISPOSAL LINE DIVERTER VLV 1 DIVERTER VLV 2 DOOR CONTACT DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DRIVER + FORCE LIMITER DRIVER EXTERIOR DOOR HANDLE DRIVER SEAT BACKREST WIRING HARNESS DRIVER SEAT MULTI-CONTOUR COMPRESSOR DRIVER SEAT POSITION DRIVER SIDE AIR BAG IGNITER DRIVER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR DRIVER SIDE CENTRAL LOCKING SYSTEM DRIVER SIDE CURTAIN AIR BAG IGNITER DRIVER SIDE ENTRY LIGHT IN EXTERIOR MIRROR DRIVER SIDE EXTERIOR MIRROR ENTRY LIGHT DRIVER SIDE INTERIOR LOCKING DRIVER SIDE KNEE AIR BAG IGNITER DRIVER SIDE MICROPHONE 1 DRIVER SIDE MICROPHONE 2 DRIVER SIDE ROLL-OVER PROTECTION IGNITER DRIVER'S BUCKLE DRV AIR BAG STAGE 1 - DRV AIR BAG STAGE 2 - DRV FORCE LIMITER - DRV SEAT BELT TENSIONER DRV SIDE AIR BAG IGNITER DRV SIDE INTR LOCKING SW DRV SIDE KNEE AIR BAG + DUO-SENS 1 - BEHIND THROTT VLV DUO-SENS 1 AHEAD OF THROTT VLV EARTH POINT 5, ON CYL HEAD EC+ ELECTRICAL PRESSURE ADJUSTER 1 ELECTRICAL PRESSURE ADJUSTER 2 ELECTRICAL PRESSURE ADJUSTER 3 ELECTRICAL PRESSURE ADJUSTER 4 ELECTRICAL PRESSURE ADJUSTER 5 ELECTRICAL PRESSURE ADJUSTER 6 ELECTRICAL PRESSURE ADJUSTER 7 ELECTRICAL PRESSURE ADJUSTER 8 EMERGENCY POWER SUPPLY CONNECTION ENTRY, START SYSTEM INTERIOR AERIAL 1 ENTRY, START SYSTEM LUGGAGE COMPARTMENT AERIAL ETHERNET 1 RX LO ETHERNET 1 RX PLUS ETHERNET 1 TX LO ETHERNET 1 TX PLUS ETHERNET DATA EXHAUST FLAP 1 SETPOINT EXHAUST FLAP 2 SETPOINT EXHAUST TEMPERATURE 1 + EXT MIR POSITIVE EXTERIOR MIRROR ENTRY LIGHT EXTERNAL ANT FL MID-RANGE LOUDSPEAKER - FLEXRAY 1- FLEXRAY 1- INPUT FLEXRAY 1- OUTPUT FLEXRAY 1- OUTPUT CAN PRIVATE HIGH FLEXRAY 2 - FLEXRAY 2+ INPUT FLEXRAY 2- OUTPUT FLEXRAY BRANCH 1 BM FLEXRAY BRANCH 1 BP FLEXRAY BRANCH 2 BM FLEXRAY BRANCH 3 BM FLEXRAY BRANCH 3 BP FLEXRAY INPUT 1+ FLEXRAY INPUT 2 - FLXRY 1-IN FM 2 FOLD OUT FOLD-IN FR BM A FR MID-RANGE LOUDSPEAKER - FR SHOCK ABSORBERS VLV - FRONT FOOTWELL LIGHTING FRONT LUGGAGE COMPARTMENT LIGHT FRONT PASSENGER DOOR HANDLE FRONT PASSENGER EXTERIOR DOOR HANDLE FRONT PASSENGER SEAT MULTI-CONTOUR COMPRESSOR FRONT PASSENGER SIDE AIR BAG IGNITER FRONT PASSENGER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR FRONT PASSENGER SIDE CONTAIN AIR BAG IGNITER FRONT PASSENGER SIDE CURTAIN AIR BAG IGNITER FRONT PASSENGER SIDE ENTRY LIGHT IN EXTERIOR MIRROR FRONT PASSENGER SIDE EXTERIOR MIRROR FRONT PASSENGER SIDE KNEE AIR BAG IGNITER FRONT PASSENGER'S SIDE ROLL-OVER PROTECTION IGNITER FRONT REAR RIGHT ILLUMINATED VANITY MIRROR FRONT ROOF MODULE FRONT SPOILER ADJUSTMENT COMPRESSOR FRONT SUPPLY FOR PARK ASSIST SENS FRT LH INNER PARKING AID SNSR FRT LH PARKING AID SNDR FRT PASS SEAT BELT FRT PASS SIDE FRT RH INNER PARKING AID SNSR FRT RH PARKING AID SENDER FRT SEAT OCCUP FRT SIDE AIR BAG IGNITER FUEL LEVEL FUEL LEVEL SENS 2 FUEL LOW PRESSURE SENS GND FUEL LOW PRESSURE SENS SUPPLY FUEL LOW-PRESSURE SENS FUEL PRESSURE SENDER FUEL PRESSURE SENDER 2 FUEL PRESSURE SENDER LOW FUEL TANK SENS FUN IND FUNCTION IND FUNCTION LED FXRY 1+ IN FXRY 1- FXRY 1- OUT FXRY 2+ IN FXRY 2- FXRY 2- OUT FXRY BRANCH 1 BM FXRY BRANCH 1 BP FXRY BRANCH 4 BM FXRY BRANCH 4 BP FXRY BRANCH 8 BM FXRY BRANCH 8 BP FXRY BRANCH 9 BM FXRY BRANCH 9 BP FXRY BRANCH 10 BM FXRY BRANCH 10 BP FXRY BRANCH 11 BM FXRY BRANCH 11 BP GARAGE DOOR OPENER PROGRAMMING AERIAL GAS MODE WIRING HARNESS CONNECTION 6 GEARBOX OIL GEARBOX OIL TEMPERATURE SENDER GMS SIG GND ACTUATORS/SENSORS GND DC OUTPUT GND FOR ACTRS/SENS GND FOR ACTUATORS SENS GND FOR RR PARK ASSIST SENS GND FOR FRT PARK ASSIST SENS GND PWM OUTPUT GND ROTARY ENCODER GND, BODY GPS AERIAL 2 GPS SIGNAL GROUND ACTUATORS GROUND ACTUATORS/SENSORS GROUND DISTRIBUTION SYSTEM GROUND FOR ACTUATORS/ SENSORS GROUND FOR ACTUATORS/ SENSORS ANTI DAZZLE MIRROR GROUND FOR ACTUATORS/SENS GROUND, BODY GROUND, MICROSWITCH GROUND, SENS GSM AERIAL GSM AERIAL 2 GSM SIG GSM SIGNAL HALL FSK EXTENDED HALL FSK RETRACTED HALL POS RH ANGLE HALL REAR SPOILER SPLY HALL SENS HALL SENS 1 - HALL SENS SIG HALL SENS SUPPLY HALL SIG GND HALL SIG X HALL SIG Y HALL STV HALL VDKD LI CLOSED HALL VDKD RE CLOSED HALL WIND DEF HEAD AIR BAG DRIVER SIDE + HEAD AIR BAG DRV SIDE - HEAD AIR BAG PASS SIDE - HEADLIGHTS SYSTEM HEATED REAR WINDOW HIGH MOUNTED STOP LIGHT HOOK RECORDING HORNS SYSTEM HOT AT ALL TIMES HYDRAULIC TEMPERATURE SENDER IGN SIG IGN SIG 1 IGN SIG 2 IGN SIG 3 IGN SIG 4 IGN SIG 5 IGN SIG 6 IGNITION ON INFO HI INFO LO INJECTOR CYLINDER 1 INJECTOR CYLINDER 2 INJECTOR CYLINDER 3 INJECTOR CYLINDER 4 INJECTOR CYLINDER 5 INJECTOR CYLINDER 6 INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INTAKE CAMSHAFT INTAKE CAMSHAFT SENS BANK 1 - INTAKE CAMSHAFT SENS BANK 2 - INTERIOR MIRROR INTERNET ACCESS AERIAL INTR LOCKING SW IONISER 1 KL 30 FH KL 30 LOGIC KL 31 PNEUMATICS KL 31 TEMP SENS KL 87 ECKPE + KL.30 KL. 31 PNEUMATIK KNOCK SENS 1 BANK 1 SIG 1 KNOCK SENS 1 BANK 1 SIG 2 KNOCK SENS 2 BANK 1 SIG 1 KNOCK SENS 2 BANK 1 SIG 2 L TAIL/BRAKE LIGHT 3 LEFT "C" PILLAR) LEFT BRAKE LIGHT LEFT CONVERTIBLE ROOF FLAP LEFT COOLING FLAP POS LEFT COOLING FLAP POSI SENDER LEFT COOLING FLAP POSITION SENDER LEFT EMITTER + LEFT EXTERIOR MIRROR LED ON/OFF LEFT FOOTWELL VENT TEMPERATURE SENDER LEFT FRONT BASS LOUDSPEAKER LEFT FRONT BODY ACCELERATION SENDER LEFT FRONT BRAKE PAD WEAR SENDER LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 1 LEFT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2 LEFT FRONT CENTER PARKING AID SENDER LEFT FRONT FOOTWELL LIGHT LEFT FRONT FOOTWELL LIGHT 2 LEFT FRONT PARK ASSIST STEERING SENDER LEFT FRONT PARKING AID SENDER LEFT FRONT SEAT BACKREST FAN 1 LEFT FRONT SEAT BELT LEFT FRONT SEAT CUSHION FAN 1 LEFT FRONT SEAT HEATED BACKREST LEFT FRONT SEAT HEATED SEAT CUSHION LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TREBLE LOUDSPEAKER LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT LEFT FRONT VEHICLE LEVEL SENDER LEFT NUMBER PLATE LIGHT LEFT RADIATOR FAN LEFT REAR BODY ACCELERATION SENDER LEFT REAR BRAKE PAD WEAR SENDER LEFT REAR CENTER PARKING AID SENDER LEFT REAR ENTRY, START AUTHORIZATION AERIAL LEFT REAR FOG LIGHT LEFT REAR ILLUMINATED VANITY MIRROR LEFT REAR INTERIOR LIGHT LEFT REAR MID-RANGE/ LOUDSPEAKER LEFT REAR PARK ASSIST STEERING SENDER LEFT REAR PARKING AID SENDER LEFT REAR TREBLE LOUDSPEAKER LEFT REAR VEHICLE LEVEL SENDER LEFT REVERSING LIGHT LEFT SIDE MARKER LIGHT LEFT SUN SENS LEFT TAIL LIGHT CLUSTER LEFT TAIL/BRAKE LIGHT 1 LEFT TAIL/BRAKE LIGHT 2 LEFT TAIL/BRAKE LIGHT 3 LEFT TAIL/BRAKE LIGHT 4 LEFT TERM 30 LEFT TURN SIGNAL LEFT WINDSCREEN AERIAL LF FOOTWELL LIGHT LF LEVEL SENS + LF LEVEL SENS SIG LF LO RANGE SPKR - LF MID-RANGE LOUDSPEAKER - LF MID-RANGE LSP + LF OUTPUT SPD SENS SIG LF SHOCK ABSORBERS VLV - LF SPD SENS SIG INPUT LF TWEETER+ LH EPB ACT + LH EPB MTR + LH FRT PARK ASSIST STEERING SNDR LH LIN AQUAPLANING-SENS LH SPOILER HALL CW LH SPOILER HALL PERF LH VERS HALL CW LH VERS HALL PERF LH VERSE AQUAPLANING-SENS LIN 1 LIN 2 LIN 3 LIN 4 LIN 5 LIN 6 LIN INPUT LIN LEF FRONT CENTER PARKING AID SENDER LIN MF LIN OUTPUT LNV + IN LNV BACK LNV TASTER LNV VOR LOCATING LIGHT LOCKING PAWL LORD HIGH LOW LORD NEXT PREVIOUS LR ACCEL SENS - LR INPUT SPD SENS SIG LR LEVEL SENS + LR LEVEL SENS SIG LR OUTPUT SPD SENS LR SHOCK ABSORBERS VLV - LR TWEETER + LTE AERIAL 1 LTE AERIAL 2 LVDS 1 - LVDS 2 - LVDS 2 OUT 1+ LVDS 2 OUT 2+ LVDS IN 1- LVDS IN 2- LVDS OUT 1+ LVDS OUT 2+ MAIN CATCH TAILGATE MAIN HEADLIGHTS LEFT MAIN HEADLIGHTS RIGHT MAIN LEFT HEADLIGHTS MAP-CONTROLLED ENG COOLING SYS THERMOSTAT MARKER LIGHT MASS HALL MTR A + B MASSE HALL SENS MASSE HALL TASTER MASSEKO SEAT PAN MIB HI MICROPH SOUND REC + MICROPHONE 1 - MICROPHONE 2 + MICROPHONE 2 + 9 10 MICROPHONE 2 - 3 4 MICROSWITCH 1 MICROSWITCH 1 DRV SIDE INTR LOCKING SW MICROSWITCH 2 MICROSWITCH A MICROSWITCH B MIRROR STATUS POS X MIRROR STATUS POS Y MIRROR, ANTI-DAZZLE + MOST IN MOST OUT MOT- MS DHV LOCKED MS DVH LOCKED MS DVH UNLOCKED MTR 1 - MTR 2 EXTENSION MTR 2 RETRACTION MUFU HORIZONTAL MUFU VERTICAL MULTIMEDIA SYSTEM N/A N/A NAVIGATION SYSTEM NIGHT VISION CIRCUIT NOT USED NTC 1 NTC 2 NTC 3 NTC- NUMBER PLATE LIGHT + OIL LEVEL, OIL TEMPERATURE OIL LEVEL, OIL TEMPERATURE SENDER OIL LEVEL/ OIL TEMP SENS + OIL PRESS SENS OIL PRESS SENS GND OIL PRESSURE OIL PRESSURE REG VLV + OIL PRESSURE, OIL TEMPERATURE SENDER OIL TEMP + ONBOARD LEFT FRONT FOOTWELL LIGHT OPEN CTRL VLV + OPEN FSK - OPT WAVE GUIDE IN OPT WAVE GUIDE OUT OPTICAL WAVEGUIDE IN OPTICAL WAVEGUIDE OUT OUTER DR HNDL EXTENDED OUTER DR HNDL RETRACTED OUTLET CAMSHAFT OUTLET CAMSHAFT CONTROLLER 1 OUTLET CAMSHAFT CONTROLLER 2 OUTLET CAMSHAFT SENS BANK 1 - OUTLET CAMSHAFT SENS BANK 2 - OUTPUT 1 OUTPUT 2 OUTPUT RLY F PLUG SOCKETS OUTSIDE TEMP SENS OUTSIDE TEMPERATURE SENS OXY SENS OXY SENS SIEPF PARK ASSIST PARK BRAKE FUNCTION DISPLAY PARK/NEUTRAL START REL PARTICULATE FILTER 1 PARTICULATE FILTER 2 PASS AIR BAG STAGE 1 - PASS AIR BAG STAGE 2 - PASS FORCE LIMITER + PASS SIDE KNEE AIR BAG + PASSENGER + FORCE LIMITER PASSENGER DOOR BACKGROUND LIGHTING PASSENGER SEAT POSITION PASSENGER SIDE AUTOMATIC ANTI-DAZZLE EXTERIOR MIRROR PASSENGER SIDE BELT SW PASSENGER SIDE EXTERIOR MIRROR ENTRY LIGHT PASSENGER'S BUCKLE PASSENGER'S SIDE ROLL-OVER PROTECTION IGNITER PEDAL SENS 1 GND PEDAL SENS 2 DIGITAL SIG PEDAL SENS 2 GND PEDAL VALUE SENS PEDAL VALUE SENS 2 PHASE U PHASE V PHASE W POSITION METER + POSITION SIG 1 POSITION SIG 2 POSITION SIGNAL 1 POSITION SIGNAL 2 POSITIVE CONNECTION CLIMATRONIC WIRING HARNESS POWER DISTRIBUTION SYSTEM POWER LINKS POWER RECHTS POWER SUPPLY PRESS SENS 1 - TANK VENT PRESS SENS GND PRESS SENS SIG PRESS SENS SPLY PRESSURE DIFFERENTIAL SENDER PRESSURE DIFFERENTIAL SENDER 2 PRESSURE SENSORS GROUND PRK BRK FUN DISPLAY PULSE WIDTH PUMPE VERS + PWM GND PWR MTR X PWR MTR Y RADIATOR BLIND CTRL MTR RADIATOR FAN LEFT RADIATOR FAN RIGHT RADIATOR OUTLET COOLANT RADIATOR OUTLET COOLANT TEMPERATURE SENDER RADIO CONTROLLED PARKING AERIAL 3 RADIO CONTROLLED PARKING AERIAL 4 RAIL PRESS SENS 2 GND RAIL PRESSURE SENS 1 RAIL PRESSURE SENS 1 5 V RAIL PRESSURE SENS 1 GND RAIL PRESSURE SENS 2 RAISE WINDOW + REAL TOP VIEW CIRCUIT REAR ARMREST WIRING HARNESS CONNECTION REAR ENTRY, START AUTHORIZATION AERIAL REAR FOG LIGHT REAR FOOTWELL LIGHTING REAR RIGHT AERIAL FOR ENTRY, START AUTHORIZATION REAR SPOILER REAR SPOILER POSITION SENDER REAR SUPPLY FOR PARK ASSIST SENS REAR WINDOW WIPER REMOTE + RESET CENTRAL COMPUTER RF FOOTWELL LIGHT RF LEVEL SENS + RF LEVEL SENS SIG RF LO RANGE SPKR - RF MID-RANGE LOUDSPEAKER - RF MID-RANGE LSP + RF SPD SENS INPUT RF TWEETER - RH EPB ACT + RH EPB MTR - RH FRT PARK ASSIST STEERING SNDR RH LIN AQUAPLANING-SENS RH SPOILER HALL CW RH SPOILER HALL PERF RH VERS HALL CW RH VERS HALL PERF RH VERSE AQUAPLANING SENS RIGHT AQUAPLANING WARNING SENDER RIGHT BRAKE LIGHT RIGHT COOLING FLAP POS RIGHT COOLING FLAP POSI SENDER RIGHT COOLING FLAP POSITION SENDER RIGHT EMITTER + RIGHT EXTERIOR MIRROR LED ON/OFF RIGHT FOOTWELL VENT TEMPERATURE SENDER RIGHT FRONT BASS LOUDSPEAKER RIGHT FRONT BODY ACCELERATION SENDER RIGHT FRONT BRAKE PAD WEAR SENDER RIGHT FRONT CENTER RIGHT FRONT CENTER CONSOLE BACKGROUND LIGHTING 2 RIGHT FRONT CENTER PARKING AID SENDER RIGHT FRONT CENTER PARKING AID SENDER LEFT FRONT CENTER PARKING AID SENDER RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT FOOTWELL LIGHT 2 RIGHT FRONT HEATED SEAT CUSHION RIGHT FRONT PARK ASSIST STEERING SENDER RIGHT FRONT PARKING AID SENDER RIGHT FRONT PARKING SENS RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT BELT RIGHT FRONT SEAT CUSHION FAN 1 RIGHT FRONT SEAT HEATED BACKREST RIGHT FRONT SEAT HEATED SEAT CUSHION RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TREBLE LOUDSPEAKER RIGHT FRONT TURN SIGNAL, SIDE LIGHT RIGHT FRONT VEHICLE LEVEL SENDER RIGHT NUMBER PLATE LIGHT RIGHT RADIATOR FAN RIGHT REAR BRAKE PAD WEAR SENDER RIGHT REAR CENTER PARKING AID SENDER RIGHT REAR ENTRY, START AUTHORIZATION AERIAL RIGHT REAR FOG LIGHT RIGHT REAR ILLUMINATED VANITY MIRROR RIGHT REAR INTERIOR LIGHT RIGHT REAR MID-RANGE/ LOUDSPEAKER RIGHT REAR PARK ASSIST STEERING SENDER RIGHT REAR PARKING AID SENDER RIGHT REAR TREBLE LOUDSPEAKER RIGHT REAR VEHICLE LEVEL SENDER RIGHT REVERSING LIGHT RIGHT SIDE MARKER LIGHT RIGHT SUN SENS RIGHT TAIL LIGHT CLUSTER RIGHT TAIL/BRAKE LIGHT 1 RIGHT TAIL/BRAKE LIGHT 2 RIGHT TAIL/BRAKE LIGHT 4 RIGHT TURN SIGNAL RIGHT WINDSCREEN AERIAL RING BREAK DIAGNOSIS ROOF OPERATION WIRING HARNESS CONNECTION 2 ROTARY CATCH ROTARY LATCH CONTACT ROTARY VANE POSITION ROTATIONAL SPEED SENDER 1 ROTATIONAL SPEED SENDER 2 RR BODY ACC SENS - RR LEVEL SENS - RR LEVEL SENS SIG RR LH INNER PARKING AID SNDR RR LH PARK ASSIST STEERING SNDR RR LH PARKING AID SENDER RR RH INNER PARKING AID SNDR RR RH PARK ASSIST STEERING SNDR RR RH PARKING AID SNDR RR SHOCK ABSORBERS VLV - RR SPD SENS SIG INPUT RR TWEETER - SAFE LED SEATS SYSTEM SEATS SYSTEM SEATS SYSTEM SENS A SIG SENS BANK 2 + SENS GND SENS SIG SENS SUPPLY SENT SIG SHV AB SHV AUF SHV TASTER SI HALL VDKD LI OPEN SI HALL WINDS SET UP SI MS DVH UNLOCKED SI TEMP HYDRAULIC GND SIDE MARKER LIGHT SIG 3 SIG 4 SIG CRANKSHAFT SPEED SENDER SIGNAL 1 SIGNAL 2 SIGNAL 3 SIGNAL 4 SIGNAL GROUND SLV TASTER SNV TASTER SO MTR FSK EXTEND SO MTR WIND DEFLECTOR + SO RETRACT THE FSK MTR SOUND SYMPOSER - SOUND SYSTEMS SP ANKLAPPMOT ++ABKL SP ANKLAPPMOT -+ANKL SP KL.31 LEISTUNG SP SWA LED SP VERSTELLMOT X+RE SP VERSTELLMOT XY SP VERSTELLMOT Y+TIE SP VERSTELLMOTOR XY SPD SENS OUTPUT SPD SENS SIG SPLY FOR FRT SPLY FOR FRT PARK ASSIST SENS SPLY FOR REAR PARK ASSIST SENS SPOILER HALL CW LINKS ST WHEEL START RELEASE PARK/NEU START RELEASE PARK/NEUTRAL STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STOP LIGHT STR RLY 1 STR RLY 2 STRG CLMN ADJ STV BEFORE RETURN STV TASTER SUPPLY 1 SUPPLY 2 SUPPLY ACTUATORS 1 SUPPLY ACTUATORS 2 SUPPLY ACTUATORS 3 SUPPLY ACTUATORS 4 SUPPLY DWG SUPPLY HALL 1 SUPPLY HALL 2 SW 1 SW 2 SW 3 SW 4 SW, TAILGATE REL TAILGATE MAIN CATCH TANK BREATHER PRESS SENS 1 TANK LEAK DIAGNVALVE TEMPERATURE REGULATION TEMPERATURE SENDER BEFORE PARTICULATE FILTER TERM 15 TERM 15 ACTIVATION TERM 15 IGNITION ON TERM 15 LOAD TERM 15 WAKE UP TERM 30 TERM 30 1 TERM 30 A/C TERM 30 INTERIOR LIGHT TERM 30 LEFT TERM 30 PLUG SOCKETS TERM 30 RIGHT TERM 30 SWITCHED TERM 30-2 TERM 30-3 TERM 31 TERM 31 VALVES TERM 31-1 TERM 31-2 TERM 31-3 TERM 50 TERM 58 TERM 58 S TERM 87 TERMINAL 15 TERMINAL 50 FEEDBACK THROTT VLV ACTVAL 2 THROTT VLV GND TIP-DOWN TIP-UP TIPTRONIC DOWN TIPTRONIC UP TRANSM OIL TEMP+ TRANSMISSION OIL TEMPERATURE + TRUNK TRAPMENT ENTRI TRUNK TRAPMENT VERRI TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL TURN SIGNAL LIGHT UNLOCK FRONT LID UNLOCK REAR LID UNLOCK TANK LID UNLOCKING + USB DATA 1- USB DATA 2+ VDA LF 1 VDA LF+ VDA MUTE VDA OUT + VEHICLE LOCATION SYSTEM AERIAL 1 VEHICLE LOCATION SYSTEM AERIAL 2 VEHICLE LOCATION SYSTEM AERIAL 3 VERS HALL SPOILER 1-4 VERS ROTARY ENCODER VIDEO IN - VIDEO OUT 1+ VIDEO SIGNAL VLV - W/ 4-WAY SEATS W/ 4-WAY SEATS W/ 14/18 WAY SEATS W/ 14/18 WAY SEATS W/ DIGITAL RADIO RECEPTION W/ MEMORY W/ SUNROOF W/ TENSIONER HEIGHT ADJUSTMENT W/O DIGITAL RADIO RECEPTION W/O MEMORY W/O SUNROOF W/O TENSIONER HEIGHT ADJUSTMENT WAKE-UP WAKE-UP ETHERNET WANGENV L OPEN-CLOSE WANGENV SI ON TO WARNING LIGHT EXTERIOR MIRR WARNING LIGHT EXTERIOR MIRROR WASHER FLUID LEVEL SENS WAW HALL SIGNAL WI-FI WIDTH MODULATION WIND DEFLECTOR FIELD WIND DEFLECTOR SETUP WINDSCREEN WIPER WIPER/WASHER SYSTEM WIRING SCREEN
