Porsche 911 Carrera 4S 991 facelift (2015-2019) driver seat adjustment output control unit Wiring diagrams
This page contains all the electrical diagrams for the component. driver seat adjustment output control unit, in which he is found in the car Porsche 911 Carrera 4S 991 facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver seat adjustment output control unit wiring diagram (1 of 2)
Go to component -> Driver power seat circuit, w/ bucket seat -> DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
driver seat adjustment output control unit wiring diagram (2 of 2)
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER
DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER SEAT CONTROL UNIT
DRIVER STANDARD 2-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER STANDARD 4-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FAN CONTROL UNIT
FRESH AIR FAN MOTOR
FROM MAIN FUSE BOX (DIAGRAM 1 OF 5)
FROM MAIN FUSE BOX (DIAGRAM 4 OF 5)
FROM MIDI FUSE (DIAGRAM 1 OF 5)
FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER STANDARD 2-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER STANDARD 4-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FUSE 1
FUSE 2
FUSE 3
FUSE 4
LEFT FRONT FUSE BOX (ROW A)
LEFT REAR AXLE STEERING ADJUSTER
LIFT FUNCTION CONTROL UNIT
LIN
MAIN FUSE BOX (RIGHT SIDE OF DASH)
MIDI FUSE
N/A
PASM CONTROL UNIT
PORSCHE STABILITY MANAGEMENT (PSM) CONTROL UNIT
REAR BCM
RED WIRE
RED/BLK WIRE
RED/GRN (OR RED) WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT FUSE BOX (ROW A)
RIGHT REAR AXLE STEERING ADJUSTER
STARTING/CHARGING SYSTEM
TERM 15
TERM 30 IN
TERM 30 OUT
TERM 31
TERM 50
TO FUSE (DIAGRAM 3 OF 5)
TO LEFT FRONT FUSE BOX (ROW B) (DIAGRAM 4 OF 5)
TO RIGHT FRONT FUSE BOX (ROW B) (DIAGRAM 4 OF 5)
TO RIGHT FRONT FUSE BOX (ROW D) (DIAGRAM 3 OF 5)
VIO/YEL WIRE
W/ MEMORY
W/ MEMORY W/O MEMORY
W/ START/STOP FUNCTION
W/O MEMORY
Go to component -> Power distribution circuit (2 of 5) -> DRIVER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
