Porsche 911 Carrera 4S 991 (2011-2015) adj ctrl switch wiring diagram
This page shows the only wiring diagram for the component.adj ctrl switch, which is found in the car Porsche 911 Carrera 4S 991 (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
adj ctrl switch wiring diagram (1 of 1)
1, 2, OFF
ADJ CTRL SWITCH
AREA LIGHTING
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
COURTESY LIGHT
CTRL SWITCH
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR MEMORY BUTTON MODULE
FUNCTION IND
FUSE 6
FUSE 7
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HEATING
HOT AT ALL TIMES
IND OFF
IND SET
LED MEMORY OFF
LED MEMORY SET
LEFT COURTESY LIGHTS MIRROR
LEFT DOOR MIRROR HEATING
LEFT FRONT FUSE BOX (ROW C)
LEFT MEMORY SERVO MOTOR EXTERIOR MIRROR
LEFT MIRROR FOLDING MOTOR
LH CTRL UNIT MIRROR
LH MIRROR FUNCTION
MEMORY CTRL SW
MIRROR ADJUSTMENT
MIRROR CHANGEOVER
MIRROR POSITION 1
MIRROR POSITION 2
MOTOR 1
MOTOR 1/2
MOTOR 2
MOTOR SPLY
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S DOOR MEMORY BUTTON MODULE
POTENTIOMETER
POTI ENGINE 1
POTI ENGINE 2
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RH CTRL UNIT MIRROR
RH MIRROR FUNCTION
RIGHT COURTESY LIGHTS MIRROR
RIGHT DOOR MIRROR HEATING
RIGHT FRONT FUSE BOX (ROW C)
RIGHT MEMORY SERVO MOTOR EXTERIOR MIRROR
RIGHT MIRROR FOLDING MOTOR
SEL CTRL SWITCH
SERVO MOTOR X
SERVO MOTOR Y
SET BUTTON
SPLY POTENTIOMETER
STATUS POS X
STATUS POS Y
SWITCH FOLDING
SWITCH MEMORY SAVE
TERM 31
TERM 31 SET BUTTON
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit, w/o turbo -> ADJ CTRL SWITCH
