Wiring Diagrams for Porsche 911 Carrera 4S 991 (2011-2015)

Active bodyworks circuit

Automatic a/c circuit, w/o turbo Automatic a/c circuit, w/ turbo

Anti-lock brakes circuit, w/o turbo Anti-lock brakes circuit, w/ turbo

Anti-theft circuit, w/o turbo Anti-theft circuit, w/ turbo

Front controller circuit, w/o turbo Front controller circuit, w/ turbo Rear control unit circuit, w/o turbo Rear control unit circuit, w/ turbo Vehicle electrical system control module circuit

Computer data lines circuit, w/o turbo Computer data lines circuit, w/ turbo

Cooling fan circuit, w/o turbo Cooling fan circuit, w/ turbo

3.4l, cruise control circuit

3.8l, cruise control circuit

3.8l twin turbo, cruise control circuit

Defogger circuit, w/o turbo Heated mirrors circuit, w/o turbo Rear defogger & heated mirrors circuit, w/ turbo

Electronic power steering circuit Power tilt steering column circuit

Dynamic chassis control circuit Electronic level control circuit, w/o turbo Electronic level control circuit, w/ turbo

Wiring diagram engine performance 3.4l

Wiring diagram engine performance 3.8l

Wiring diagram engine performance 3.8l twin turbo

Backup lamps circuit Exterior lamps circuit, w/o turbo Exterior lamps circuit, w/ turbo

Ground distribution circuit, w/o turbo Ground distribution circuit, w/ turbo

Headlights circuit, w/o turbo w/o cornering headlights Headlights circuit, w/turbo w/ cornering headlights Headlights circuit, w/turbo w/o cornering headlights

Horn circuit, w/o turbo Horn circuit, w/ turbo

Instrument cluster circuit, w/o turbo Instrument cluster circuit, w/ turbo

Interior lights circuit, w/o turbo Interior lights circuit, w/ turbo

Driver"s memory seat circuit Memory mirrors circuit, w/o turbo Memory mirrors circuit, w/ turbo Passenger"s memory seat circuit Steering column memory circuit

Navigation circuit, w/ burmester Navigation circuit, w/o turbo w/ bose Navigation circuit, w/o turbo w/o bose Navigation circuit, w/ turbo convertible w/ bose Navigation circuit, w/ turbo w/ bose Navigation circuit, w/ turbo w/o bose Parking assistant circuit, w/o turbo Parking assistant circuit, w/ turbo

Power distribution circuit, w/o turbo Power distribution circuit, w/ turbo

Power door locks circuit, w/o turbo Power door locks circuit, w/ turbo

Auto anti-dazzling mirror circuit, w/o turbo Auto anti-dazzling mirror circuit, w/ turbo Power mirrors circuit, w/o turbo Power mirrors circuit, w/ turbo

Driver power seat circuit, w/o turbo base Driver power seat circuit, w/o turbo except base Driver power seat circuit, w/ turbo base Driver power seat circuit, w/ turbo except base Heated seats circuit, w/o turbo w/o passenger power seat Heated seats circuit, w/o turbo w/ passenger power seat Heated seats circuit, w/ turbo Passenger power seat circuit, w/o turbo base Passenger power seat circuit, w/o turbo except base Passenger power seat circuit, w/ turbo base Passenger power seat circuit, w/ turbo except base

Convertible top circuit Sunroof circuit

Power windows circuit, w/o turbo Power windows circuit, w/ turbo

Base radio circuit Optical waveguide circuit Premium radio circuit, turbo w/ bose Premium radio circuit, turbo w/o bose Premium radio circuit, w/ burmester Premium radio circuit, w/o turbo w/ bose Premium radio circuit, w/o turbo w/o bose

Electronic parking brake circuit, w/o turbo Shift interlock circuit, w/o turbo Shift interlock circuit, w/ turbo

3.4l, charging circuit 3.4l, starting circuit

3.8l, charging circuit 3.8l, starting circuit

3.8l twin turbo, charging circuit 3.8l twin turbo, starting circuit

Supplemental restraints circuit, w/o turbo Supplemental restraints circuit, w/ turbo

A/t circuit, w/o turbo A/t circuit, w/ turbo Awd circuit Pdk circuit

Tailgate & fuel door release circuit

Warning systems circuit, w/o turbo Warning systems circuit, w/ turbo

Front wiper/washer circuit, turbo w/o rain sensor Front wiper/washer circuit, turbo w/ rain sensor Front wiper/washer circuit, w/o turbo Rear wiper circuit, w/o turbo Rear wiper circuit, w/ turbo

ALARM HORN ALARM SIREN AMPLIFIER SW O/P ANTI-LOCK BRAKES SYSTEM ANTI-REMOVAL LOCK ASK AMPLIFIER BOSE AMPLIFIER BURMESTER AMPLIFIER BURMISTER AMPLIFIER CENTRAL LOCK ANTENNA CENTRAL LOCK OUTER DOOR HANDLE CENTRAL LOCK ROTARY LATCH CENTRAL LOCK SAFE LOCKED STATUS DRIVER DOOR LOCK DRIVER'S DOOR CENTRAL LOCK SAFE LED DRIVER'S DOOR LOCK DRIVER'S DOOR ODDMENTS TRAY LIGHT EMITTTING DIODE DRIVER'S DOOR PANEL LIGHT EMITTTING DIODE ELECTRONIC IGNITION LOCK ELECTRONICS IGNITION LOCK FRONT LOCK MICRO SW FRONT PASSENGER CENTRAL LOCK SAFE LED FRONT PASSENGER DOOR CENTRAL LOCK SAFE LED FRONT PASSENGER DOOR LOCK FRONT PASSENGER DOOR ODDMENTS TRAY LIGHT EMITTING DIODE FRONT PASSENGER DOOR PANEL LIGHT EMITTING DIODE HIGH RANGE HORN IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL CYLINDER 1 IGNITION COIL CYLINDER 2 IGNITION COIL CYLINDER 3 IGNITION COIL CYLINDER 4 IGNITION COIL CYLINDER 5 IGNITION COIL CYLINDER 6 IGNITION LOCK CONTACT 1 IGNITION LOCK CONTACT 2 IGNITION LOCK CONTACT 3 IGNITION LOCK CONTACT 4 IGNITION LOCK CONTACT 5 IGNITION LOCK CONTACT 6 IGNITION LOCK CONTACT 7 IGNITION LOCK LIGHT IGNITION LOCK SW 1 IGNITION LOCK SW 2 IGNITION LOCK SW 3 IGNITION LOCK SW 4 IGNITION LOCK SW 5 IGNITION LOCK SW 6 KEY LOCK LEFT DIODE LEFT DOOR LOCK LEFT DOOR LOCK LIGHT LEFT REAR INTERIOR LIGHT EMITTING DIODE LEFT TWO-TONE HORN LOCK MTR CDL LOW RANGE TWO-TONE HORN P/N START LOCK SIG PASSENGER SIDE DOOR LOCK LIGHT REAR LOCK MICRO SW RIGHT DIODE RIGHT DOOR LOCK RIGHT DOOR LOCK LIGHT RIGHT LOW RANGE TWO-TONE HORN RIGHT REAR INTERIOR LIGHT EMITTING DIODE SHIFT LOCK STARTER RLY STEERING COLUMN LOCK SUB- WOOFER AMPLIFIER SW 1 IGNITION LOCK SW 3 IGNITION LOCK SW 4 IGNITION LOCK TERM 30 CENTRAL LOCK SYST THEFT PROTECTION ALARM HORN TWO-TONE HORN TERM 30 W/ BOSE AMPLIFIER, BURMESTER AMPLIFIER W/ BURMESTER AMPLIFIER, BOSE AMPLIFIER, TELEVISION TUNER WITHDRAWAL LOCK ZV SAFE/LOCK STATUS

(RIGHT SIDE OF ENGINE ACTUATOR A ACTUATOR B ACTUATOR, TANK COVER CLOSE ACTUATOR, TANK COVER OPEN ADJUSTING MOTOR CATCH ACTUATOR CENTRAL FLAP MOTOR CENTRAL LOCK MOTOR CENTRAL VALVE SERVO MOTOR CLOSE LATCH MOTOR + DEFROST FLAP SERVO MOTOR DRIVER'S DOOR POWER WINDOW MOTOR DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR ELECTRIC CONVERTIBLE MOTOR TOP ELECTRIC CONVERTIBLE TOP MOTOR ENGINE BLOCK) ENGINE COMPARTMENT FAN ENGINE COMPARTMENT PURGE FAN 1 ENGINE COMPARTMENT PURGE FAN 2 ENGINE COMPT TEMP ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE SENS 2 ENGINE SPEED EXTENDED VENT ELEMENT SERVO MOTOR FAN BACKREST MOTOR FAN ENGINE COMPARTMENT FAN SEAT MOTOR FL TEMP VALVE SERVO MOTOR FRESH AIR FAN MOTOR FRESH/RECIRC AIR FLAP SERVO MOTOR FRONT FOOTWELL SERVO MOTOR FRONT PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR FRONT REAR PASSENGER DOOR POWER WINDOW MOTOR FRONT SEAT HEIGHT ADJUSTMENT MOTOR FRONT SERVO MOTOR TEMPERATURE VALVE FRONT WIPER MOTOR HOOD LATCHING HOOK MOTOR LEFT BASIC EXTERIOR MIRROR SERVO MOTOR LEFT EPB MOTOR + LEFT FRONT WIPER MOTOR LEFT MEMORY SERVO MOTOR EXTERIOR MIRROR LEFT MIRROR FOLDING MOTOR LEFT REAR POWER WINDOW MOTOR LEFT REAR SIDE FLAP MOTOR LEFT SEAT WIDTH ADJUSTMENT VALVE BLOCK PUMP MOTOR LOCK MOTOR CDL LUGGAGE COMPARTMENT LID ACTUATOR LUMBAR PUMP MOTOR MIRROR ADJUST MOTOR X MIRROR ADJUST MOTOR X MIRROR ADJUST MOTOR Y MIRROR ADJUST MOTOR Y MIRROR ADJUSTMENT MOTOR Y MIRROR MOTOR CONTROL Y MIRROR MOTOR SPLY MIRROR MOTOR X MIRROR MOTOR X/Y MOTOR 1 MOTOR 1/2 MOTOR 2 MOTOR + UP MOTOR +FORE/AFT MOTOR A MOTOR B MOTOR CLOSE, MOTOR MONITORING MOTOR SEAT FORE, AFT ADJUSTMENT MOTOR SEAT FORE-AND -AFT ADJUSTMENT MOTOR SPLY OPEN LATCH MOTOR + PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR POTI ENGINE 1 POTI ENGINE 2 PUMP MOTOR RAM AIR FLAP SERVO MOTOR REAR SEAT HEIGHT ADJUSTMENT MOTOR REAR SEAT HEIGHT HEIGHT ADJUSTMENT MOTOR REAR SIDE FLAP MOTOR + OPEN REAR WINDOW WIPER MOTOR RETRACT MOTOR + RETURN PUMP MOTOR RIGHT BASIC EXTERIOR MIRROR SERVO MOTOR RIGHT EPB MOTOR - RIGHT FRONT WIPER MOTOR RIGHT MEMORY SERVO MOTOR EXTERIOR MIRROR RIGHT MIRROR FOLDING MOTOR RIGHT REAR POWER WINDOW MOTOR RIGHT SEAT ADJUSTMENT VALVE BLOCK PUMP MOTOR SAFE MOTOR SAVE MOTOR SEAT ANGLE ADJUSTMENT MOTOR SEAT BACKREST ADJUSTMENT MOTOR SEAT DEPTH ADJUSTMENT MOTOR SEAT FORE/ AFT ADJUSTMENT MOTOR SEAT FORE/AFT ADJUSTMENT MOTOR SERVO MOTOR SERVO MOTOR X SERVO MOTOR Y STEPPER MOTOR STEPPER MOTOR ALWAR 2 STEPPER MOTOR ALWR 1 STEPPER MOTOR ALWR 2 TAILGATE ACTUATOR TAILGATE UNLOCK ACTUATOR THROTTLE VALVE MOTOR + TOP OF ENGINE) WIND DEFLECTOR MOTOR WIND DFLTR MOTOR LOWER + WIND DFLTR MOTOR RAISE + WINDSHIELD WIPER MOTOR WIPER MOTOR WIPER MOTOR + WASHER FLUID PUMP + WIPER MOTOR + WASHING FLUID PUMP + WIPER MOTOR STAGE 1 WIPER MOTOR STAGE 2 WIPER MOTOR SUPPLY ZV MOTOR LOCK ZV MOTOR LOCK SAFE ZV MOTOR SAFE ZV SAFE MOTOR

ANTENNA 1 ANTENNA 2 ANTENNA 3 ANTENNA DIVERSITY ANTENNA IN LUGGAGE COMPT 1 ANTENNA IN PASS COMPT 1 ANTENNA IN PASS COMPT 2 ANTENNA SPLY BASIC ANTENNA CENTRAL LOCKING ANTENNA CTRL LOCKING ANTENNA DIGITAL ANTENNA EXTERNAL ANTENNA GPS ANTENNA GSM ANTENNA LEFT ANTENNA AMPLIFIER LEFT ANTENNA B-PILLAR LEFT B-PILLAR PAS ANTENNA LEFT REAR OUTER WHEEL HOUSING PAS ANTENNA LUGGAGE COMPARTMENT 1 PAS ANTENNA LUGGAGE COMPT 1 ANTENNA + PAS COMPT 1 ANTENNA + PAS COMPT 2 ANTENNA + PASSENGER COMPARTMENT 1 PAS ANTENNA PASSENGER COMPARTMENT 2 PAS ANTENNA RIGHT ANTENNA AMPLIFIER RIGHT ANTENNA B-PILLAR RIGHT B-PILLAR PAS ANTENNA RIGHT REAR OUTER WHEEL HOUSING PAS ANTENNA SDARS ANTENNA TELEPHONE ANTENNA W/ ANTENNA DIVERSITY W/ BASE ANTENNA W/ EXTERNAL ANTENNA W/ EXTERNAL ANTENNA W/O EXTERNAL ANTENNA W/O ANTENNA DIVERSITY W/O ANTENNA DIVERSITY W/ ANTENNA DIVERSITY W/O EXTERNAL ANTENNA

BUTTON 1, 2 OFF BUTTON LOCAL BUTTON MODULE BUTTON SIG CENT LOCK BUTTON CENTCONSOLE BUTTON MODULE CENTER CONSOLE BUTTON MODULE CENTRAL LOCKING SYSTEM BUTTON CL BUTTON LED CL BUTTON LED DOOR PANEL LED CL BUTTON LED CLOSE BUTTON FL CLOSED BUTTON FR CMT LOCK BUTTON SIG CNT LOCK BUTTON SIG DRIVER DOOR MEMORY BUTTON MODULE DRIVER'S DOOR BUTTON MODULE DRIVER'S DOOR MEMORY BUTTON MODULE DRIVER'S POWER WINDOW BUTTON MODULE EMERGENCY OPENER BUTTON EPB BUTTON FRONT COVER OPENER BUTTON FRONT LID BUTTON FRONT LID OPEN BUTTON FRONT LID OPENER BUTTON FRONT LUGGAGE COMPARTMENT EMERGENCY OPENER BUTTON FRONT PASSENGER DOOR MEMORY BUTTON MODULE FRONT PASSENGER DOOR POWER WINDOW BUTTON FRONT REAR PASSENGER DOOR POWER WINDOW BUTTON FRONT/REAR OPEN LID BUTTON MODULE HAZARD WARNING BUTTON HAZARD WARNING LIGHT BUTTON HOME LINK BUTTON 1 HOME LINK BUTTON 2 HOMELINK BUTTON 1 HOMELINK BUTTON 2 LEFT PWR WIND BUTTON LEFT STEERING WHEEL TIPTRONIC BUTTON LEFT TIPTRONIC BUTTON LF BUTTON, CLOSE NTC BUTTON PASSENGER'S DOOR MEMORY BUTTON MODULE PASSENGER'S POWER BUTTON MODULE PRESS REGULATOR 1 PRESS REGULATOR 2 PRESS REGULATOR 3 PRESS REGULATOR 4 PRESS REGULATOR 5 PRESS REGULATOR 6 PRESSURE REGULATOR 7 PSM PASSIVELY BUTTON PWR WIND BUTTON REAR COVER OPENER BUTTON REAR LID BUTTON REAR LID OPEN BUTTON REAR LID OPENER BUTTON REAR SPOILER MOD BUTTON RF BUTTON, CLOSE RIGHT STEERING WHEEL TIPTRONIC BUTTON RIGHT TIPTRONIC BUTTON RT PWR WIND BUTTON SET BUTTON SILL BUTTON MODULE STEERING WHEEL HORN BUTTON TERM 31 SET BUTTON WARNING LIGHT BUTTON

B+ PLUG SOCKET DIAGNOSIS CONNECTOR DIAGNOSIS PLUG SOCKET DIAGNOSTIC PLUG SOCKET FRONT CENTER CONSOLE PLUG SOCKET FRONT PASSENGER FOOTWELL PLUG SOCKET GLOVE BOX PLUG SOCKET PACKAGE TRAY SOCKET RIGHT FRONT CENTRE CONSOLE PLUG SOCKET RIGHT FRONT PASSENGER FOOTWELL PLUG SOCKET SOCKET 2

CENTRE BUTTON CONTROL MODULE COMBINED STEERING CONTROL MODULE DME CONTROL MODULE FRONT BODY CONTROL MODULE FRONT CONTROL MODULE REAR BODY CONTROL MODULE

A/C CONTROL UNIT A/C OPERATING UNIT AIR BAG CONTROL UNIT ALL-WHEEL DRIVE CONTROL UNIT CLIMATRONIC CONTROL UNIT CONTROL UNIT TERM 30 CONVERTIBLE TOP CONTROL UNIT COOLING WATER BLOWER CONTROL UNIT COOLING WATER FAN CONTROL UNIT CORNER SENSITIVE HEADLIGHT CONTROL UNIT CORNER SENSITIVE HEADLIGHTS CONTROL UNIT CTRL UNIT 1 DEACT CTRL UNIT 3 TERM 31 DIVERSITY CONTROL UNIT DME CONTROL UNIT DOOR EXIT OP CTRL UNIT DR PANEL LT OP CTRL UNIT DRIVER DOOR CONTROL UNIT DRIVER SEAT CONTROL UNIT DRIVER'S DOOR CONTROL UNIT DRIVER'S SEAT CONTROL UNIT ELECTRIC FUEL PUMP CONTROL UNIT ELECTRONIC STEERING COLUMN ADJUSTMENT CONTROL UNIT EPB CONTROL UNIT FAN CONTROL UNIT FRONT CONTROL UNIT FRONT END CONTROL UNIT FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER SEAT ADJUSTMENT CONTROL UNIT FRONT PASSENGER SEAT CONTROL UNIT FRONT PASSENGER STANDARD 2 WAY SEAT ADJUSTMENT CONTROL UNIT FRONT PASSENGER STANDARD 4-WAY SEAT ADJUSTMENT CONTROL UNIT FRONT PASSENGER'S DOOR CONTROL UNIT FRONT PASSENGER'S SEAT CONTROL UNIT FUEL PUMP CONTROL UNIT FUEL PUMP SYSTEM CONTROL UNIT GATEWAY CONTROL UNIT HOME LINK CONTROL UNIT LEAKAGE DIAGNOSIS UNIT LEFT COMFORT SEAT CONTROL UNIT LEFT DRIVER SPORT SEAT ADJUSTMENT OPPOSITE CONTROL UNIT LEFT MOUNT 2 UNIT LEFT REAR DOOR CONTROL UNIT LEFT SEAT MEMORY CONTROL UNIT LH CTRL UNIT MIRROR MOUNT CONTROL UNIT MOUNTS CONTROL UNIT PARK ASSIST CONTROL UNIT PARK ASSISTANT CONTROL UNIT PARK DISTANCE CONTROL UNIT PARKING ASSISTANT CONTROL UNIT PAS CONTROL UNIT PASM CONTROL UNIT PASSENGER DOOR CONTROL UNIT PASSENGER SEAT CONTROL UNIT PASSENGER'S DOOR CONTROL UNIT PCM CONTROL UNIT PDCC SPORT CONTROL UNIT PDK CONTROL UNIT PSM CONTROL UNIT RDK CONTROL UNIT REAR CONTROL UNIT RH CTRL UNIT MIRROR RIGHT COMFORT SEAT CONTROL UNIT RIGHT MEMORY SEAT CONTROL UNIT RIGHT MOUNT 1 UNIT RIGHT REAR DOOR CONTROL UNIT RIGHT SEAT MEMORY CONTROL UNIT SEAT OCCUPANCY DETECTION CONTROL UNIT SELECTOR LEVEL CONTROL UNIT SELECTOR LEVER CONTROL UNIT STEERING WHEEL ELECTRONICS CONTROL UNIT TERM 30 UNIT MOUNT THROTTLE VALVE ADJUSTMENT UNIT TIRE PRESSURE CONTROL UNIT TIRE PRESSURE MONITORING CONTROL UNIT UNIT MOUNT 1 UNIT MOUNT 1 HIGH UNIT MOUNT 1 LOW UNIT MOUNT 2 UNIT MOUNT 2 HIGH UNIT MOUNT 2 LOW UNIT MOUNTS CONTROL UNIT VEHICLE ELECTRICAL CONTROL UNIT VEHICLE ELECTRICAL SYSTEM CONTROL UNIT WEIGHT RECOGNITION CONTROL UNIT

BATTERY FUSE BOX FUSE 1 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE BOX BATTERY FUSE HOLDER A FUSE HOLDER B FUSE HOLDER C FUSE HOLDER D FUSE HOLDER E FUSE HOLDER F LEFT FRONT FUSE BOX LIN MAIN FUSE BOX MAIN FUSE BOX MAXI FUSE MAXI FUSE BOX MAXI FUSE C MIDI FUSE REAR FUSE BOX REAR FUSE HOLDER RIGHT FRONT FUSE BOX RIGHT FUSE HOLDER

ADDITIONAL HEADLIGHT HEADLIGHT WASHER HEADLIGHT WASHER FLUID PUMP HEADLIGHT WASHERD HEADLIGHT WASHING FLUID PUMP LEFT AUXILIARY HEADLIGHT LEFT HEADLIGHT LEFT HEADLIGHT ASSEMBLY LEFT XENON HEADLIGHT RIGHT AUXILIARY HEADLIGHT RIGHT HEADLIGHT RIGHT HEADLIGHT ASSEMBLY RIGHT XENON HEADLIGHT RIGHT/LEFT ADDITIONAL TOP HEADLIGHT TERM 30 HEADLIGHT WASHER TOP ADDITIONAL HEADLIGHT

CUSHION HEATING ELEMENT DMTL-HEATING DRIVER'S DOOR HEATER MIRROR GND MIRR HEATING HEATING CUSHION ELEMENT HEATING ELEMENT THERMOSTAT MAP HEATING GROUND L SEAT HEATER SPLY LEFT DOOR MIRROR HEATING LEFT SEAT HEATER LEFT SEAT HEATER SUPPLY LEFT SEAT HEATING LEFT SIDE BACKREST BOLSTER HEATING LEFT SIDE BOLSTER HEATING ELEMENT LSF HEATER NK MIRR HEATER MIRR HEATING MIRR HEATING GND MIRROR HEATER MIRROR HEATING GND OXY SENS HEATER PASSENGER'S DOOR HEATER MIRROR R SEAT HEATER SPLY REAR WINDOW HEATER RIGHT DOOR MIRROR HEATING RIGHT SEAT HEATER RIGHT SEAT HEATER SUPPLY RIGHT SEAT HEATING RIGHT SIDE BACKREST BOLSTER HEATING RIGHT SIDE BOLSTER HEATING ELEMENT RIGHT SIDE BOLSTERS HEATING ELEMENT SEAT BACKREST HEATING ELEMENT SEAT CUSHION/ SIDE BOLSTERS HEATING ELEMENT SEAT CUSHIONS/ SIDE BOLSTER HEATING ELEMENT STEERING WHEEL HEATER STEERING WHEEL HEATING

RIGHT REAR BRAKE PAD WEAR INDICATOR

DAYTIME RUNNING LIGHTS INTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM INTERIOR LIGHTS SYSTEMS LEFT COURTESY LIGHTS MIRROR LEFT FRONT FOG LAMP LEFT VENTS LIGHTS LF DAYTIME RUNNING LIGHTS MIDDLE VENT LIGHTS MIDDLE VENTS LIGHTS PSM PASSIVELY BULB RF DAYTIME RUNNING LIGHTS RIGHT COURTESY LIGHTS MIRROR RIGHT FRONT FOG LAMP RIGHT SIDE TURN SIGNAL, MARKER LAMP RIGHT VENT LIGHTS RIGHT VENTS LIGHTS

AIR PUMP CLOSE HD+ HYDRAULIC PUMP COOLANT PUMP DUAL CENTER WASHER PUMP ELECTRICAL WATER PUMP FRONT DUAL WASHING PUMP FRONT PUMP FUEL PUMP FUEL PUMP RLY 1 FUEL PUMP RLY 2 FUEL PUMP SIG HYDRAULIC PUMP 1 CLOSE HOOD ++ HYDRAULIC PUMP 1 OPEN HOOD + OPEN HD+ HYDRAULIC PUMP PUMP GROUND REAR DUAL WASHING PUMP REAR PUMP SECONDARY AIR PUMP SECONDARY PUMP TANK FLANGE FUEL PUMP WASHER FLUID PUMP WASHING FLUID PUMP WASHING FLUID PUMP SUPPLY WINDSHIELD WASHER FLUID PUMP

CAN HIGH REAR WINDOW HEATED RELAY DME RELAY DME RELAY 1 DME RELAY 2 ELECTRIC FUEL PUMP RELAY 1 ELECTRIC FUEL PUMP RELAY 2 EMERGENCY POWER SUPPLY RELAY EMERGENCY POWER SUPPLY RELAY 1 EMERGENCY VOLT SUPPLY 1 RELAY ENGINE COMPARTMENT PURGE FAN HIGH RELAY ENGINE COMPARTMENT PURGE FAN LOW RELAY ENGINE FLUSH HIGH RELAY ENGINE FLUSH HIGH SUPPORT RELAY 2 ENGINE FLUSH LOW RELAY ENGINE RELAY FAN RELAY FUEL PUMP RELAY HEADLIGHT CLEANER PUMP RELAY HEADLIGHT WASHER PUMP RELAY HEADLIGHT WASHER RELAY HEADLIGHT WASHING RELAY HEATED REAR WINDOW RELAY HEATER RELAY HORN ONE, TWO SUPPORT RELAY HOT W/ DME 1 RELAY ENERGIZED HOT W/ DME RELAY 1 ENERGIZED HOT W/ DME RELAY ENERGIZED HOT W/ EMERGENCY POWER SUPPLY RELAY ENERGIZED HOT W/ KL 15 RELAY ENERGIZED HOT W/ KL 30 RELAY ENERGIZED HOT W/ TERM 15 RELAY ENERGIZED HOT W/ TERMINAL 15 RELAY ENERGIZED KL 15 RELAY LED 2- SIDE MARKER LIGHT RELAY TERM 31 LEFT FAN RELAY LEFT FAN RELAY SUPPORT 1 LOW ENGINE FLUSH RELAY REAR WINDOW DEFOGGER RELAY REAR WINDOW HEATED ADAPTER 7 RELAY REAR WINDOW HEATED RELAY POSITION 1 REAR WINDOW HEATER ADAPTER RELAY REAR WINDOW HEATER RELAY RELAY ENERGIZED RELAY KL 15 RELAY SUPPORT 1 RELAY TERM 30 RELAY TERM 50 RELAY TWO-TONE HORNS RIGHT FAN RELAY SUPPORT 1 SECONDARY AIR PUMP RELAY START LOCK RELAY STARTER RELAY STARTER SUPPORT RELAY 2 TERMINAL 15 RELAY TWO-TONE HORNS RELAY TWO-TONE HORNS RELAY SUPPORT 1 VALVE RELAY

ACC SENSOR GND FL ACC SENSOR GND FR ACC SENSOR SIG FL ACC SENSOR SIG FR ACC SENSOR SUPPLY FL ACC SENSOR SUPPLY FR AIR QUALITY SENSOR ALWR SENSOR 1 ALWR SENSOR GND BATTERY SENSOR BRAKE FLUID LEVEL SENSOR BRAKE FLUID SENSOR BRAKE VACUUM SENSOR CAMSHAFT SENSOR 1 CAMSHAFT SENSOR 1 CYLINDER 1-3 CAMSHAFT SENSOR 2 CAMSHAFT SENSOR 2 CYLINDER 4-6 CAMSHAFT SENSOR BANK 1 CAMSHAFT SENSOR BANK 2 CENTRAL LOCK PROXY SENSOR CHARGE AIR PRESSURE, TEMPERATURE SENSOR CLOSED HALL SENSOR - CLUTCH SENSOR COOLANT CYLINDER HEAD TEMPERATURE SENSOR COOLANT RETURN TEMPE- RATURE SENSOR COOLANT TEMPERATURE SENSOR CRANKSHAFT SPEED SENSOR DRIVER DOOR INNER HANDLE SENSOR DRIVER SIDE A-PILLAR SENSOR DRIVER UPFRONT SENSOR DRIVER'S DOOR OUTER HANDLE SENSOR DRIVER'S DOOR PRESSURE SENSOR DRIVER'S SEAT POSITION SENSOR 1 DRIVER'S SIDE AIR BAG SENSOR DRVR FRONT SENSOR DRVR SIDE AB SENSOR ENGINE COMPARTMENT TEMPERATURE SENSOR ENGINE SENSOR ENGINE SPEED SENSOR EXHAUST TEMPERATURE SENSOR FAN OUTPUT TEMPER- ATURE SENSOR FRONT PASSENGER DOOR INNER HANDLE SENSOR FRONT PASSENGER DOOR OUTER HANDLE SENSOR FRONT PASSENGER OUTER DOOR HANDLE SENSOR FRONT PASSENGER SIDE A-PILLAR SENSOR FRONT PASSENGER UPFRONT SENSOR FRONT PASSENGER'S DOOR PRESSURE SENSOR FRONT PROXIMITY SENSOR FUEL LEVEL SENSOR FUEL LEVEL SENSOR GND FUEL PUMP FUEL LEVEL SENSOR GROUND SENSOR HALL SENSOR HALL SENSOR 1 HALL SENSOR 2 HALL SENSOR SUPPLY 2+ HALL SENSOR WIND DEFLECTOR HALL SENSOR WIND DEFLECTOR RAISED HALL SENSOR+ CLOSED HALL SENSOR, BACKREST ANGLE ADJUSTM HALL SENSOR, SEAT ANGLE ADJUSTMENT HALL SENSOR, SEAT BACKREST ADJUSTMENT HALL SENSOR, SEAT DEPTH ADJUSTMENT HALL SENSOR, SEAT HEIGHT ADJUSTMENT HEATED OXYGEN SENSOR CATALYTIC CONVERTER BANK 1 HEATED OXYGEN SENSOR CATALYTIC CONVERTER BANK 2 HEIGHT SENSOR GND FL HEIGHT SENSOR GND FR HEIGHT SENSOR GND RL HEIGHT SENSOR GND RR HEIGHT SENSOR SIG FL HEIGHT SENSOR SIG FR HEIGHT SENSOR SIG RL HEIGHT SENSOR SIG RR HEIGHT SENSOR SUPPLY FL HEIGHT SENSOR SUPPLY FR HEIGHT SENSOR SUPPLY RL HEIGHT SENSOR SUPPLY RR HIGH RAIL PRESSURE SENSOR HOOD TORQUE ANGLE SENSOR INTAKE AIR PRESSURE, TEMPERATURE SENSOR INTAKE AIR SENSOR INTAKE AIR TEMPER- ATURE SENSOR INTAKE MAN PRESSURE SENSOR INTERIOR SENSOR INTERIOR SURVEILLANCE SENSOR KNOCK SENSOR 1 KNOCK SENSOR #2 LEAKAGE DIAGNOSTICS TEMPERATURE SENSOR UNIT LEAKAGE TEMPERATURE SENSOR DIAGNOSIS UNIT LEFT BLOWER SENSOR LEFT FRONT ACCELERATION SENSOR LEFT FRONT AIR BAG SENSOR LEFT FRONT AUTOMATIC HEADLIGHT AIMING VERTICAL SENSOR LEFT FRONT BRAKE PAD WEAR CONTACT SPEED SENSOR LEFT FRONT BRAKE PAD WEAR CONTACT/SPEED SENSOR LEFT FRONT FOOTWELL BLOWER SENSOR LEFT FRONT HEIGHT SENSOR LEFT FRONT INSIDE PDC SENSOR LEFT FRONT OUTSIDE PDC SENSOR LEFT FRONT WEIGHT SENSOR LEFT FRONT WHEEL SPEED SENSOR LEFT REAR AUTOMATIC HEADLIGHT AIMING VERTICAL SENSOR LEFT REAR BRAKE PAD WEAR CONTACT SPEED SENSOR LEFT REAR BRAKE PAD WEAR CONTACT/SPEED SENSOR LEFT REAR HEADLIGHT AIMING VERTICAL SENSOR LEFT REAR INNER SIDE PDC SENSOR LEFT REAR INSIDE PDC SENSOR LEFT REAR OUTSIDE PDC SENSOR LEFT REAR VERTICAL SENSOR LEFT REAR WEIGHT SENSOR LEFT REAR WHEEL SPEED SENSOR LEFT SIDE AIR BAG SENSOR LEVEL SENSOR LEVEL SENSOR FL- LF SPEED SENSOR SUPPLY LF SUPPLY PROXIMITY SENSOR LF TERM 31 PROXIMITY SENSOR LR SPEED SENSOR SUPPLY LUMBAR AIR CHAMBER DISTANCE MEASUREMENT SENSOR MAT PRESSURE SENSOR NEUTRAL GEAR SENSOR NTC COOLANT TEMPERATURE SENSOR NTC ENGINE COMPARTMENT TEMPERATURE SENSOR OIL LEVEL SENSOR OIL LEVEL SENSOR SHIELD OIL PRESSURE SENSOR OIL PRESSURE/ TEMPERATURE SENSOR OIL TEMPERATURE SENSOR GEAR WHEEL SET MANUAL TRANSMISSION 991 OIL TEMPERATURE SENSOR GEAR WHEEL SET PDK 991 OPEN HALL SENSOR - OUT SIDE TEMPERATURE SENSOR OUTPUT SENSOR FOOTWELL OUTSIDE SENSOR OUTSIDE TEMPERATURE SENSOR OXYGEN SENSOR OXYGEN SENSOR AHEAD OF CATALYTIC CONVERTER BANK 1 OXYGEN SENSOR AHEAD OF CATALYTIC CONVERTER BANK 2 PASM LEFT REAR HEIGHT SENSOR PASM RIGHT REAR HEIGHT SENSOR PASS FRONT SENSOR PASS SIDE AB SENSOR PASSENGER SEAT POSITION SENSOR PASSENGER TEMPERATURE SENSOR PASSENGER'S SIDE AIR BAG SENSOR PEDAL VALUE SENSOR PEDAL VALUE SENSOR 1 PEDAL VALUE SENSOR 1 GROUND POTENTIOMETER PEDAL VALUE SENSOR 2 PEDAL VALUE SENSOR 2 GROUND POTENTIOMETER PEDAL VALVE SENSOR PEDAL VALVE SENSOR 2 PRESSURE SENSOR PROXIMITY SENSOR PROXY SENSOR SUPPLY FL PROXY SENSOR SUPPLY FR RAIL PRESSURE SENSOR RAIN SENSOR RAIN SENSOR ORIENTATION LIGHT RAIN SENSOR SHIELD GROUND RAIN SENSOR SIGNAL RAIN SENSOR SUPPLY + RATE OF SENSOR RATE OF TURN SENSOR REAR ACC SENSOR GND REAR ACC SENSOR SIG REAR ACC SENSOR SUPPLY REAR ACCELERATION SENSOR REAR SIDE FLAPS CLOSED HALL SENSOR LATCHING HOOK READY REAR SIDE FLAPS OPEN HALL SENSOR REFRIGERANT PRESSURE SENSOR RF SPEED SENSOR INPUT RF SPEED SENSOR SUPPLY RF SUPPLY PROXIMITY SENSOR RF TERM 31 PROXIMITY SENSOR RIGHT BLOWER SENSOR RIGHT FRONT ACCELERATION SENSOR RIGHT FRONT AIR BAG SENSOR RIGHT FRONT BRAKE PAD WEAR CONTACT/ SPEED SENSOR RIGHT FRONT BRAKE PAD WEAR CONTACT/SPEED SENSOR RIGHT FRONT FOOTWELL BLOWER SENSOR RIGHT FRONT HEIGHT SENSOR RIGHT FRONT INSIDE PDC SENSOR RIGHT FRONT OUTSIDE PDC SENSOR RIGHT FRONT VERTICAL SENSOR RIGHT FRONT WEIGHT SENSOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR BRAKE PAD WEAR CONTACT SPEED SENSOR RIGHT REAR BRAKE PAD WEAR CONTACT/SPEED SENSOR RIGHT REAR INNER SIDE PDC SENSOR RIGHT REAR INSIDE PDC SENSOR RIGHT REAR OUTSIDE PDC SENSOR RIGHT REAR WEIGHT SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT SIDE AIR BAG SENSOR RR SPEED SENSOR SUPPLY SENSOR CLUSTER SENSOR GND SENSOR GROUND SENSOR SIG SPEED SENSOR SPOILER HALL SENSOR SUN SENSOR TEMP SENSOR TEMPERATURE SENSOR TEMPERATURE SENSOR LEAKAGE DIAGNOSIS UNIT TERM 31 PROXIMITY SENSOR TERM 31 PROXIMITY SENSOR FL TERM 31 PROXIMITY SENSOR FR TILT SENSOR TORQUE SENSOR U SENSOR UNIT MOUNT 1 SENSOR GND UNIT MOUNT 1 SENSOR SIG UNIT MOUNT 1 SENSOR SUPPLY UNIT MOUNT 2 SENSOR GND UNIT MOUNT 2 SENSOR SIG UNIT MOUNT 2 SENSOR SUPPLY WASHER FLUID LEVEL SENSOR WEAR SENSOR WHEEL SPEED SENSOR

BOSE SUBWOOFER BURMESTER SUBWOOFER AMPLIFIER CEN SPEAKER - CENTER BOSE SPEAKER CENTER DASH BOARD TWEETER SPEAKER CENTER SPEAKER CENTER SPEAKER DASHBOARD DRIVER DOOR MID-RANGE SPEAKER DRIVER'S DOOR MID-RANGE SPEAKER FL SPEAKER - FR SPEAKER - FRONT PASSENGER DOOR MID-RANGE SPEAKER HIGH END SUBWOOFER AMPLIFIER LEFT DASH BOARD TWEETER SPEAKER LEFT DASHBOARD 2-WAY SPEAKER LEFT DASHBOARD TWEETER SPEAKER LEFT DOOR LOW RANGE SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT MID-RANGE SPEAKER LEFT REAR 2 WAY SPEAKER LEFT REAR MID-RANGE SPEAKER LEFT REAR WIDE BAND SPEAKER LEFT TWEETER SPEAKER LF LOW RANGE SPEAKER - LF LOW SPEAKER - LF MID RANGE SPEAKER - LR MID-RANGE SPEAKER + PASSENGER DOOR MID RANGE SPEAKER REMOTE SUBWOOFER RF LOW RANGE SPEAKER - RF LOW SPEAKER - RF MID RANGE SPEAKER + RIGHT DASH BOARD TWEETER SPEAKER RIGHT DASHBOARD 2-WAY SPEAKER RIGHT DASHBOARD TWEETER SPEAKER RIGHT DOOR LOW RANGE SPEAKER RIGHT FRONT MID-RANGE SPEAKER RIGHT REAR 2 WAY SPEAKER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR WIDE BAND SPEAKER RIGHT TWEETER SPEAKER RR MID-RANGE SPEAKER + SUBWOOFER AMPLIFER HIGH END SUBWOOFER BURMESTER AMPLIFER SUBWOOFER SIG - SUBWOOFER SW IN SUBWOOFER SW O/P

ADJ CTRL SWITCH AUTOMATIC LIGHT SWITCH BACKUP LIGHT SWITCH BELT BUCKLE QUERY SWITCH BRAKE FLUID LEVEL CONTROL SWITCH BRAKE PEDAL SWITCH CENTRAL LOCKING SWITCH CHANGEOVER SWITCH CLUTCH INTERLOCK SWITCH CLUTCH PEDAL SWITCH LOW/START ENABLE P/N CLUTCH SWITCH CONTROL SWITCH GROUND COOLANT LEVEL SWITCH COOLING WATER LEVEL SWITCH CTRL SWITCH DRIVER POWER WINDOW SWITCH DRIVER SEAT BELT BUCKLE SWITCH DRIVER SEAT BELT LOCK SWITCH DRIVER'S SEAT BELT BUCKLE QUERY SWITCH ELECTRONIC SLIDING ROOF SWITCH FOG LIGHT SWITCH FRONT LOCK MICRO SWITCH FRONT MICRO SWITCH LID LATCHING HOOK GLOVE COMPARTMENT LIGHT, MICRO SWITCH GLOVE COMPARTMENT MICRO SWITCH GLOVE COMPARTMENT SWITCH HAZARD WARNING SWITCH HOME LINK SWITCH 1 HORN SWITCH IGNITION SWITCH INTAKE MANIFOLD SWITCH-OVER VALVE LATCHING HOOK HOOD SWITCH LEFT OUTSIDE DOOR HANDLE MICRO SWITCH LEFT POWER SEAT SWITCH LEFT SEAT ADJUSTMENT SWITCH LEFT SEAT WIDTH ADJUSTMENT SWITCH LIGHT SWITCH LIGHT SWITCH POSITION 0 LOW BEAM SWITCH LUGGAGE COMPARTMENT EMERGENCY OPEN SWITCH MEMORY SWITCH MIRROR ADJ CTRL SWITCH MIRROR ADJUSTMENT CHANGE OVER SWITCH MIRROR ADJUSTMENT CHANGEOVER SWITCH MIRROR SEL CTRL SWITCH OPEN/CLOSE SWITCH OPERATING SWITCH GROUND PARK SWITCH PARK/NEUTRAL/ CLUTCH SWITCH START RELEASE PARKING BRAKE CONTACT SWITCH PASSENGER AIR BAG OFF SWITCH PASSENGER POWER WINDOW SWITCH PASSENGER SEAT BELT BUCKLE SWITCH PASSENGER SEAT BELT LOCK SWITCH PASSENGER SIDE SEAT BELT BUCKLE QUERY SWITCH PASSENGER'S AIR BAG OFF SWITCH REAR FOG LIGHT SWITCH REAR SEAT WIDTH ADJUSTMENT SWITCH REED SWITCH A REED SWITCH B REVERSING LIGHT SWITCH RIGHT OUTSIDE DOOR HANDLE MICRO SWITCH RIGHT POWER SEAT SWITCH RIGHT SEAT ADJUSTMENT SWITCH RIGHT SEAT WIDTH ADJUSTMENT SWITCH ROTARY LIGHT SWITCH SEAT ADJUSTMENT SWITCH SEAT LUMBAR 4-WAY SWITCH SEAT WIDTH ADJUSTMENT SWITCH SEL CTRL SWITCH SIDE MARKER LIGHT SWITCH SPOILER SWITCH STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN SWITCH MODULE STOP LIGHT SWITCH STOP SWITCH STOPLIGHT SWITCH SWITCH 1 SWITCH 2 SWITCH 3 SWITCH 4 SWITCH 5 SWITCH 6 SWITCH 7 SWITCH FOLDING SWITCH MEMORY SAVE TAILGATE LOCK MICRO SWITCH TAILGATE SWITCH TURN SIGNAL SWITCH WASHER FLUID LEVEL SWITCH WASHING FLUID LEVEL SWITCH WIPER SWITCH

A/C COMPRESSOR VALVE + AC VALVE ADJUSTM VALVE 2 BLEED ADJUSTM VALVE 3 BLEED AIR CLEANER FLAP VALVE BACKREST WIDTH ADJUSTM VALVE 1 BLEED CIRCULATION AIR/ OUTSIDE AIR VALVE CLOSE CTRL VALVE- CONTROL VALVE COOLANT BYPASS VALVE COOLANT SHUT-OFF VALVE 2 GEAR WHEEL SET MANUAL TRANSMISSION COOLANT SHUT-OFF VALVE 2 GEAR WHEEL SET PDK COOLANT SHUT-OFF VALVE 5 COOLING WATER SHUTOFF VALVE DIVERTER VALVE EXHAUST FLAP VALVE FLOW CONTROL VALVE GND AC VALVE HYDRAULIC PUMP 1 OPEN CTRL VALVE+ INT THROTTLE VALVE PDCC LEFT FRONT SHOCK ABSORBER VALVE LEFT FRONT SHOCK ABSORBERS VALVE LEFT REAR SHOCK ABSORBER VALVE LEFT REAR SHOCK ABSORBERS VALVE LEFT SEAT ADJUSTMENT VALVE BLOCK LEFT VALVE LIFT CONTROL VALVE CYLINDERS 1-3 LIFT CONTROL VALVE CYLINDERS 4-6 LUMBAR BOTTOM VALVE 3 LUMBAR BOTTOM VALVE 3 BLEED LUMBAR BOTTOM VALVE 3 VENTILATE LUMBAR BOTTOM VALVE 4 LUMBAR BOTTOM VALVE 4 BLEED LUMBAR TOP VALVE 1 LUMBAR TOP VALVE 1 BLEED LUMBAR TOP VALVE 1 VENTILATE LUMBAR TOP VALVE 2 LUMBAR TOP VALVE 2 BLEED OIL PRESS VALVE OIL PRESSURE REGULATING VALVE OIL PRESSURE REGULATION VALVE OPEN CTRL VALVE- PLUS VALVE QUANTITY CONTROL VALVE RIGHT FRONT SHOCK ABSORBER VALVE RIGHT FRONT SHOCK ABSORBERS VALVE RIGHT REAR SHOCK ABSORBER VALVE RIGHT REAR SHOCK ABSORBERS VALVE RIGHT SEAT ADJUSTMENT VALVE BLOCK RIGHT VALVE SEAT ADJUSTMENT VALVE BLOCK SEAT WIDTH ADJUSTM VALVE 3 BLEED SEAT WIDTH ADJUSTM VALVE 4 VENTILATE SEAT WIDTH ADJUSTMENT VALVE BLOCK SHOCK ABS VALVE FL HIGH SHOCK ABS VALVE FL LOW SHOCK ABS VALVE FR HIGH SHOCK ABS VALVE FR LOW SHOCK ABS VALVE RL HIGH SHOCK ABS VALVE RL LOW SHOCK ABS VALVE RR HIGH SHOCK ABS VALVE RR LOW SHUT-OFF VALVE SHUT-OFF VALVE PDK COOLANT SHUT-OFF VALVE PDK RADIATOR 1 SOLENOID VALVE HIS SOUND SYMPOSER VALVE TANK VALVE TANK VENT VALVE THROTTLE VALVE THROTTLE VALVE ACTVAL 1 THROTTLE VALVE ACTVAL 2 THROTTLE VALVE GROUND VALVE 1 VALVE 1 VENTILATE VALVE 2 VALVE 2 BLEED VALVE 3 BLEED VALVE 3 VENTILATE VALVE 4 VALVE 4 BLEED VALVE 4 VENTILATE VALVE BLEED VALVE BLOCK GROUND VALVE FOR TUNING FLAP 1 VALVE HS VALVE LS VALVE PUMP HS VALVE PUMP LS WATER VALVE

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/PNK WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/RED WIRE ORG/VIO WIRE ORG/WHT WIRE PNK AUX L + WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

1, 2, OFF 3.8L TWIN TURBO 5 V SUPPLY 12 V "K" LEAD DIAGNOSIS (IN RIGHT REAR (NOT A/T M/T ACCUMUL FLAP ACTIVE BODYWORKS SYSTEM ADJUSTM BTN GND ADJUSTM BTN SIG ADJUSTMENT CODED AIR BAG AIR BAG 1- AIR BAG 2+ AIR BAG GND AIR BAG GROUND AIR BAG OFF DISPLAY AIR BAG STEERING COLUMN 1 AIR BAG STEERING COLUMN 2 AIR BAG TERM 31 AIR BAG TRIGGERING DIAGNOSTIC AIR CLEANER AIR COND COMPRESSOR AIR CONDITIONING COMPRESSOR AIR CONDITIONING FAN AIR CONDITIONING SYSTEM ALWR GROUND ALWR SENS 1 ALWR SENS 2 AM/FM 1+2 AMBIENT LIGHT AMP ON ANALOG 1 ANALOG 2 ANGLE ADJUSTMENT ANT CU LOCKING ANT SHIELD ANTENNAS SPLY ANTI-DAZZLE - ANTI-DAZZLE DOOR MIRROR ANTI-DAZZLE INTERIOR MIRROR ANTI-DAZZLING INTERIOR MIRROR ANTI-THEFT SYSTEM AREA LIGHTING ASHTRAY LIGHTING ASK AMPLIFER AUTO ANTI-DAZZLE MIRROR CIRCUIT AUTOMATIC LIGHT AUTOMATIC LIGHT SW AUX 1 IN L + AUX 1 RETURN AUX 1 RTN AUX GND AUX IN R + AUX L + AUX R + AUX RTN AUX SHIELD BACK MOTORS + BACK SEAT FORE, AFT ADJUSTMENT BACK SEAT FORE-AND-AFT ADJUSTMENT BACK UP SIGNAL BACKREST ADJUSTMENT BACKREST ANGLE BACKREST ANGLE ADJUSTM BACKREST ANGLE ADJUSTMENT 1 BACKREST ANGLE ADJUSTMENT 2 BACKREST BACK BACKREST FAN BACKREST FORWARD BACKREST VENTILATION BACKREST WIDTH ADJUSTM BACKUP LAMPS CIRCUIT BACKUP LIGHT BACKUP LIGHT SW BACKUP SIGNAL BANK 1) BANK 2 BAR IGNITION CYLINDER 1 MODULE BAR IGNITION CYLINDER 2 MODULE BAR IGNITION CYLINDER 3 MODULE BAR IGNITION CYLINDER 4 MODULE BAR IGNITION CYLINDER 5 MODULE BAR IGNITION CYLINDER 6 MODULE BAR IGNITION MODULE CYLINDER 1 BAR IGNITION MODULE CYLINDER 2 BAR IGNITION MODULE CYLINDER 3 BAR IGNITION MODULE CYLINDER 4 BAR IGNITION MODULE CYLINDER 5 BAR IGNITION MODULE CYLINDER 6 BEHIND CATALYTIC CONVERTER BANK 1 BEHIND CATALYTIC CONVERTER BANK 2 BLIND SHUTTER BLOWER STAGE 2 BLUETOOTH HANDSET BLW SNSR FOOT WELL RI BLWR SNSR FOOTWELL BOSE AMPLIFER BOSE SUB WOOFER BOTTOM CHAMBER BRAKE BOOSTER BRAKE FLUID LEVEL BRAKE FLUID RESERVOIR CONTAINER BRAKE PAD WEAR BRIDGE PLUG BRIDGE PLUG 1 TERMINAL 31 BRK PAD WEAR BRK PEDAL SW BRK SIG BS+ BTS GND BTS SIG BURMESTER AMPLIFER CAMSHAFT ADJUSTER BANK 1 CAMSHAFT ADJUSTER BANK 2 CAMSHAFT ADJUSTMENT 1 CAMSHAFT ADJUSTMENT 2 CAMSHAFT SENS CAMSHAFT SENS 1 CAMSHAFT SENS 2 CAN CHASSIS HIGH CAN CHASSIS LOW CAN COMF HIGH CAN COMF LOW CAN COMFORT HI CAN COMFORT HIGH CAN COMFORT LO CAN COMFORT LOW CAN CRASH HIGH CAN CRASH LOW CAN DIAGNOSTICS HIGH CAN DIAGNOSTICS LOW CAN DISPLAY HIGH CAN DISPLAY LOW CAN DRIVE HI CAN DRIVE HIGH CAN DRIVE LO CAN DRIVE LOW CAN DRV HI CAN DRV HIGH CAN DRV LO CAN DRV LOW CAN HI CAN HI COMFORT CAN HI DISPLAY CAN HIGH CAN HIGH 1 CAN HIGH COMFORT CAN HIGH DIAGNOSTICS CAN HIGH DISP CAN HIGH DISPLAY CAN HIGH DRIVE CAN HIGH DRIVE TERM 15 CAN L CAN LO CAN LO COMFORT CAN LO DISPLAY CAN LOW CAN LOW 1 CAN LOW COMFORT CAN LOW DIAGNOSTICS CAN LOW DISP CAN LOW DISPLAY CAN LOW DRIVE CAN MMI HIGH CAN MMI LOW CAN VERTEILER CAN WAKE UP CAN WAKEUP CAN-H CANWAKE UP CATCH UNLOCK CON 1 CATCH UNLOCK CON 2 CD RADIO UMS CENTER COCKPIT AIR VENT LIGHTING CENTER LSP DASH BOARD CENTRAL FLAP CENTRAL LOCKED STATUS CENTRAL STATUS SAFE LOCKING CENTRE AIR VENT LIGHTING COCKPIT CHARGE AIR PRESSURE CHARGE AIR PRESSURE POSITIONER 1 CHARGE AIR PRESSURE POSITIONER 2 CHARGE AIR TEMP CHARGER GND CHARGER POWER CIGAR LIGHTER CIRCULATING AIR CLOSE CIRCULATING AIR/OUTSIDE AIR CLK SIG H- CLOCK IMMOBILIZER CLS ALARM CLUTCH SW CLUTCH SW DOWN CLUTCH SW UP COM TX COMBINED STEERING COLUMN MODULE COMFORT HI COMFORT HIGH COMFORT LO COMFORT LOW COMP CURENT COMPRESSOR VOLTAGE COMPT PURGE FAN COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM CONTROL LEFT CONTROL LINE CONTROL RIGHT CONVERTIBLE COUPE COOLANT SW COOLING FANS SYSTEM COOLING WATER COOLING WATER BLOWER FAN COOLING WATER LEVEL COOLING WATER TEMP SENS COURTESY LIGHT CRASH I/P CRASH INPUT CRASH OUT CRASH OUTPUT CRASH SIG CRASH SIGNAL CTRL LINE CTRL SW, TERM 31 CURRENT DISTRI- BUTOR CURRENT DISTRIBUTOR CVBS IN CVBS-IN GROUND CYL 1 HS CYL 1 LS CYL 2 HS CYL 2 LS CYL 3 HS CYL 3 LS CYL 4 HS CYL 4 LS CYL 5 HS CYL 5 LS CYL 6 HS CYL 6 LS CYLINDER 1 CYLINDER 1-3 CYLINDER 2 CYLINDER 3 CYLINDER 4 CYLINDER 4-6 CYLINDER 5 CYLINDER 6 DATA IMMOBILIZER DATA LINE DATA LINE CLOCK DATA LINE DATA DC O/P DC/DC CONVERTER DEFOGGER SYSTEM DFA LR DIAGNOSIS K DIAGNOSIS MSG DIM LED DISPOSAL LINE DISTANCE SENS DISTANCE SENS 1 DISTANCE SENS 2 DISTANCE SENS 3 DISTANCE SENS 4 DOOR CONTACT DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM DOOR PANEL LED DOOR SILL LIGHTING DRIVER BELT FORCE LIMITER DRIVER BELT TENSIONER DRIVER DOOR WOOFER DRIVER KNEE AIR BAG DRIVER ROLL-OVER BAR DRIVER SEAT BELT PRETENSIONER DRIVER SIDE DRIVER STANDARD 2 WAY SEAT ADJUSTMENT DRIVER STANDARD 4 WAY SEAT ADJUSTMENT DRIVER'S MIRROR DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVER'S SEAT LUMBAR SUPPORT DRIVER'S SEAT SEAT HEIGHT ADJUSTMENT DRIVER'S SIDE HEAD AIR BAG DRIVER'S STANDARD 2 WAY SEAT ADJUSTMENT DRIVER'S STANDARD 4 WAY SEAT ADJUSTMENT DRV AIR BAG STAGE 1 - DRV AIR BAG STAGE 2 - DRV BUCKLE DRV PRETENSIONER - DRV SEAT POSITION DRV UPFRONT SENS + DRV/PASS CODING DRVR BUCKLE DRVR HEAD AB - DRVR THORAX AB + E-BOX STEERING WHEEL EISS ILL EISS ILLUMINATION ELECTRICAL STATIC DISCHARGE ELECTRICAL STEERING GEAR ELECTRONIC STEERING WHEEL ELV SPLY EMER UNLOCK LUGG COMPT EMERGENCY POWER PIN ENABLE TERM 15 ENABLINE ELV ENABLING SIG ENCODER PIN GROUND ENG COMPT PURGE FAN ENG COMPT TEMP SENS ENG SCAVENGE BLOWER STAGE 2 EVAP TEMP EXHAUST FLAP CONTROL EXT HALL + EXT HALL GND EXT SENS - EXTEND MTR + EXTEND SPOILER EXTENDED SPOILER EXTENDED SPOILER SW EXTENT CABLE PRE- INSTALLATION SEAT FAN ACTUATION FAN BACKREST FAN CTRL FAN CTRL 1 FAN CTRL 2 FAN FEED BACK FAN FINAL STAGE FAN FINAL STAGE TERM 15 FAN SEAT FILLER FLAP CONN 1 FILLER FLAP CONN 2 FINAL STAGE FAN FINAL STAGE FAN TERM 15 FL DASHBOARD + FL TRIGGER MODULE LIN BUS DATA FL TRIGGER MODULE LIN BUS GND FL TRIGGER MODULE LIN BUS SUPPLY FL TWEETER + FM 3+4 FM OUT FOG LIGHT FOG LIGHT SUPPLY FOLDING MIRROR CHANGE-OVER SW FOOTWELL DEFROST FOOTWELL DEFROST FLAP FOOTWELL LIGHT FOOTWELL) FORCE LIMITER DRV- FORCE LIMITER, PASS+ FORE-AND-AFT FR DASHBOARD + FR TRIGGER MODULE LIN BUS DATA FR TRIGGER MODULE LIN BUS GND FR TRIGGER MODULE LIN BUS SUPPLY FR TWEETER + FRESH AIR UP FRONT BCM FRONT BLUETOOTH CHARGING TRAY FRONT CONTROLLER CIRCUIT FRONT EVAPORATOR TEMPERATURE FRONT FOG LIGHT SW FRONT LID FRONT LID ACTUATING ELEMENT FRONT LID LATCHING HOOK MICROSWITCH FRONT LID LIGHT FRONT LID MICRO SW FRONT LUGGAGE COMPARTMENT LIGHT FRONT LUGGAGE COMPT LIGHT FRONT PASSENGER DOOR WOOFER FRONT PASSENGER ROLL-OVER BAR FRONT PASSENGER SEAT THORAX AIR BAG FRONT SEAT HEIGHT ADJUSTMENT FRONT SENS SIG FRT ALWR SENS IN 1 FRT LCK MICRO SW FRT LUGG COMPT LT FUEL FILLER NECK GROUND FUEL INJECTOR CYLINDER 1 FUEL INJECTOR CYLINDER 2 FUEL INJECTOR CYLINDER 3 FUEL INJECTOR CYLINDER 4 FUEL INJECTOR CYLINDER 5 FUEL INJECTOR CYLINDER 6 FUEL LEVEL SEN GND FUEL LVL SENS FUN IND FUN IND 2 FUN IND OFF FUN IND SET FUNCTION IND FUNCTION LIGHT CLS ALARM FUNCTION LT CLS ALARM FUSES HOLDER A FUSES HOLDER B FUSES HOLDER C FUSES HOLDER D FUSES HOLDER E FUSES HOLDER F FZV SIG GLOVE BOX LIGHT GLOVE BOX MICRO SW GND ACTR GND ALWR SENS GND CONN 1 GND CONN 2 GND DIPPED BEAM GND ENG SENS 3 GND HI BEAM GND MTR AHBA GND SENS GND SENS 1 GND SENS 2 GND SNSR GP AIR BAG GP ELECTRONIC GP ELECTRONICS GP PDK GP PSM GP-6 GPS HF IN GROUND CONNECTION 1 GROUND CONNECTION 2 GROUND DISTRIBUTION SYSTEM GROUND POTI GROUND, SENSORS HAAL SENS HALL CLOSED HALL MTR GND HALL OPEN HALL SENS HALL SENS 1 - HALL SENS 2 HALL SENS FORE/AFT + HALL SENS HEIGHT + HALL SIG 1 HANDSFREE MICROPHONE + HANDSFREE MICROPHONE OPERATION/ MICROPHONE SOUND ACQUISITION HAZARD IND LT HAZARD-WARNING IND LIGHT HEAD AIR BAG DRV SIDE - HEAD AIR BAG DS ESD GROUND HEAD AIR BAG FR PASS SIDE + HEAD AIR BAG PS ESD GROUND HEADLIGHTS SYSTEM HEATED BACKREST HEIGHT ADJUSTMENT HI BEAM HI PRESS SNSR HIGH BEAM HIGH MOUNT STOP LT HIGH MOUNTED STOP LIGHT HIGH MOUNTED STOP LIGHT BODY HIGH PRESSURE SENS HIS SUPPLY HOME LINK LED HOME LINK LIN HOME LINK TRANS- MITTER HOME LINK TRANSMITTER HOMELINK TRANSMITTER HOOD COMP LID CLOSED/OPEN HALL SNS HOOD TORQUE ANGLE SNS+ HOOD LATCH SENSORS HOOD ROT ANG SNS HALL HOOD TORQUE ANGLE SNS- HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START HOT W/ HT GND SENS HT SENS GND HT SENS SIG HT SENS SPLY HT SIG SENS HT SNSE SIG HT SNSE SPLY HT SPLY SENS I POD CHARGING VOLT + IGN CKT BELT TENS DRV + IGN CKT BELT TENS FR PASS- IGN CKT R/O PROT DRV - IGN CKT R/O PROT FR PASS + IGNITION CYL 1 IGNITION CYL 2 IGNITION CYL 3 IGNITION CYL 4 IGNITION CYL 5 IGNITION CYL 6 IN FRONT LEFT - IN FRONT OF MOTORS + IN FRONT RIGHT - IN REAR LEFT - IN REAR RIGHT - IND OFF IND SET INFRONT OF INJECTOR CYLINDER 1 INJECTOR CYLINDER 2 INJECTOR CYLINDER 3 INJECTOR CYLINDER 4 INJECTOR CYLINDER 5 INJECTOR CYLINDER 6 INNER DOOR HANDLE SIG INNER DOOR HANDLE SIGNAL INNER DR HANDLE SIG INNER TEMP SURFACE INNR TEMP COMP INSIDE DOOR HANDLE LIGHT INSIDE DOOR HANDLE LT INSIDE DR HANDLE MICRO SW INSIDE LIGHT SW TERM 30 INSTRUMENT CLUSTER INSTRUMENTAL CLUSTER INT LIGHT GND INTAKE PRESS INTAKE TEMP INTER LK INTERIOR LIGHT GROUND INTERIOR LIGHT TERM 30 INTERIOR LIGHT TERMINAL INTERIOR LIGHT) INTERLOCK - IPN GROUND IPOD ACC DET IPOD ACCESORY IDENT IPOD ACCESRY IDENT IPOD CHARGE GND IPOD CHARGEPOWER + IPOD CHARGING VOLT + IPOD DETECT IPOD IDENT IPOD RX IPOD TX IPOD VOLTAGE + KL 30 KL 31 KNEE AIR BAG DRV SIDE + KNEE AIR BAG DS ESD GROUND KNEE AIR BAG PASS SIDE - KNEE AIR BAG PS ESD GROUND L H/L BEAM TERM 30 L HIGH BEAM L LOW BEAM L SIDE TURN/MARKER LT L SIDE TURN/MARKER SPLY L STOP LIGHT LAMBDA CTRL LATCHING HK MICROSWITCH LATCHING MICROSWITCH GND LE LSP- WOOFER LED 1 LED 2 LED ACTUATING ELEMENT LED DOOR PANEL LED MEMORY OFF LED MEMORY SET LEFT AIR VENT LIGHTING COCKPIT LEFT ANTI- DAZZLE INTERIOR MIRROR SHIELD LEFT ANTI-DAZZLE INTERIOR MIRROR LEFT BRAKE LIGHT LEFT COCKPIT AIR VENT LIGHTING LEFT COOLING WATER BLOWER LEFT COOLING WATER FAN LEFT DOOR SILL LIGHTING LEFT FAN LEFT FOG LIGHT LEFT FOOTWELL LIGHT LEFT FRONT LEFT FRONT BRAKE PAD WEAR IND LEFT FRONT DOOR SILL LIGHTING LEFT FRONT FOOTWELL LIGHT LEFT FRONT HEATED SPRAY JET LEFT FRONT OUT LEFT FRONT SIDE MARKER LT LEFT FRONT TPM TRIGGER MODULE LEFT FRONT TRIGGER MODULE LEFT FRONT TURN SIG LED LEFT HEAD AIR BAG LEFT HEAD- LIGHT LEFT HEATED SPRAY JET LEFT HEATED SPRAY JETS LEFT HIGH BEAM LEFT HOOD COMP LID CLOSED HALL SNS LEFT HOOD COMP LID OPEN HALL SNS MS LATCH LOCKED LEFT LOW BEAM LEFT MAKE-UP LIGHT LEFT MAKEUP MIRROR LEFT MIRROR FUNCTION DSPLY LEFT NUMBER PLATE LIGHT LEFT RADIATOR FAN LEFT REAR LEFT REAR BRAKE PAD WEAR IND LEFT REAR RL- LEFT REAR SHOCK ABSORBER LEFT REAR TPM TRIGGER MODULE LEFT REAR TRIGGER MODULE LEFT REAR TWEETER LEFT REVERSING LIGHT LEFT SEAT LEFT SEAT NTC LEFT SEAT TEMP SENS LEFT SEAT THORAX AIR BAG LEFT SEAT VENTILATION LEFT SG LED TURN SIGNAL TOP LEFT SIDE CUSHION BOLSTERS LEFT SIDE HEATED BOLSTER LEFT SIDE MARKER LIGHT LEFT SIDE MARKER LT LEFT SIDE TURN SIGNAL LEFT STEERING WHEEL REMOTE CONTROL LEFT STOP LIGHT LEFT TAIL LIGHT LEFT TAIL LIGHT ASSEMBLY LEFT TAILLIGHT LEFT TAILLIGHT ASSEMBLY LEFT TOP TURN SIGNAL LED LEFT VENTS LIGHT LEFT VOLTAGE CONVERTER LEFT XENON HEADLIGHTS LEVEL SENS LF DAYTIME RUNNING LT LF FOG LT LF HIGH BEAM LF LOW BEAM LF SHOCK ABSORBER + LF SIDE DIRECTION IND LF SIDE IND LF SIDE MARKER LIGHT LF SIDE MARKER LT LF SIDE TURN SIGNAL MARKER LT LF SPED SENS SIG INPUT LF SPED SENS SIG INPUT GROUND LF TRIGGER MOD SUPPLY LF TURN SIG LF TURN SIGNAL LF TWEETER+ LH FOG, DRL, SIDE MARKER LT TERM 30 LH HIGH/LOW BEAM + LH LIN MTR LH LOW BEAM LH MIRROR FUNCTION LH MIRROR LED SELECTION LH MTR A LH MTR B LH REAR TURN SIG LH SPLY MTR LH TERM 30 TURN SIGNAL LH UB+ CTRL LICENSE PLATE LICENSE PLATE LIGHTING LIGHT REDUNDANT LIGHT SW LIN 1 LIN 2 LIN 3 LIN 3 COMFORT LOW LIN BUS LIN DATA LIN DATA A/C LIN DATA VECHILE LIN GND LIN INPUT LIN MTR LIN MTR AHBA LIN OUTPUT LIN SPLY+ LK SIG LOCAL PW SW LOCATING LIGHT LOCKING SOL - LOW BEAM LOW BEAM SW LOWER SEAT LOWERING DOOR WINDOWS LR FOG LIGHT LR IND LR SHOCK ABSORBER - LR TRIGGER MOD SUPPLY LR TURN SIG LR TWEETER + LR VERTICAL SENS GND LR VERTICAL SENS SIGNAL LR VERTICAL SENS SUPPLY LSF SIG LSP + LSP+ WOOFER LE LSP- CENTER LSP- CENTRE LT REAR SPOILER FUNCTION LT REDUNDANT LT SEAT HTER LT SEAT NTC LT SEAT TEMP LT SIDE VENT BLOWER LT SW POSITION 0 LUGG COMPT EMER UNLOCKING SW LUGG COMPT UNLOCK LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPT LT LUMBAR FWD/BACK LUMBAR GROUND LUMBAR HIGH LOW LUMBAR PRESSURE BOTTOM LUMBAR PRESSURE TOP LUMBAR SUPPORT CURVATURE LUMBAR SUPPORT DOWN LUMBAR SUPPORT HEIGHT LUMBAR SUPPORT UP LUMBAR SW FORWARD/BACK LUMBAR SW HIGH/LOW LVDS IN + LVL GRD LVL SENS MEM CTRL SW MEM OFF MEM SET MEMORY CTRL SW MEMORY SW MICROPHONE 1 - MICROPHONE 1 RETURN MICROPHONE 2 + MICROPHONE 2 RETURN MICROPHONE GND MICROPHONE SHIELD MICROPHONE SHLD MICROSWITCH 18 MICROSWITCH 19 MICROSWITCH A MICROSWITCH B MICROSWITCH FRONT LID MIDDLE LEVEL MIRROR ADJUSTMENT MIRROR CHANGEOVER MIRROR CHANGEOVER SW MIRROR COURTESY LIGHT MIRROR EC GLASS MIRROR EC GLASS GND MIRROR POS 1 MIRROR POS 2 MIRROR POSITION 1 MIRROR POSITION 2 MIRROR POTI - MIRROR POTI POS X MIRROR POTI POS Y MIRROR POTI TERM 31 MIRROR POTI X MIRROR POTI Y MIRRORS SYSTEM MOBILE PHONE MOBILE PHONE PREPARATION MOUNTING HIGH SIDE MOUNTING LOW SIDE MRKR LT MS LATCH RELEASED MTR SEAT BACKREST ADJUSTMENT NEGATIVE TEMPERATURE COEFFICIENT EVAPORATOR NEUT GEAR SENS NTC- NUMBER PLATE LIGHT + OIL LEVEL GND OIL LEVEL SENS OIL PRESS OIL PRESS SENS OIL PRESSURE OIL PRESSURE SENS OIL TEMP + OIL TEMP SENS ON-BOARD COMPUTER OPERATING SW OPERATION GND SW ORIENTATION LT OUT FRONT LEFT + OUT FRONT RIGHT + OUT PUT OUT REAR LEFT + OUT REAR RIGHT - OUT RIGHT REAR + OUT SIDE TEMP OUTER DOOR OUTSIDE TEMP SENS OUTSIDE TEMP SENS GND OXY SENS 1 GND OXY SENS 1 SIG OXY SENS 2 GND OXY SENS 2 SIG OXYGEN SENS GND OXYGEN SENS SIG P SW/NEUT SW P/N STR PARK SW PARKING BRAKE CONTACT PARKING BRAKE FUNCTION PASS AIR BAG PASS AIR BAG OFF INPUT REDUNDANT PASS AIR BAG STAGE 1 - PASS AIR BAG STAGE 2 - PASS BUCKLE PASS HEAD AB - PASS IT STG 1 + PASS IT STG 2 - PASS PRETENSIONER - PASS SEAT POSITION PASS THORAX AB + PASS UPFRONT SENS - PASS'S AIR BAG OFF SW INPUT PASSENGER AIR BAG ESD GROUND PASSENGER AIR BAG STAGE 1 PASSENGER AIR BAG STAGE 2 PASSENGER BELT FORCE LIMITER PASSENGER BELT TENSIONER PASSENGER KNEE AIR BAG PASSENGER PW SW PASSENGER SEAT BELT PRETENSIONER PASSENGER SIDE PASSENGER SIDE HEAD AIR BAG PASSENGER'S BUCKLE PASSENGER'S MIRROR PASSENGER'S SEAT HEIGHT ADJUSTMENT PASSENGER'S SIDE AIR BAG 1 PASSENGER'S SIDE AIR BAG 2 PASSENGER'S SIDE LUMBAR SUPPORT SEAT PCM 3 PDL VALUE SENS 1 GND PDL VALUE SENS 1 SIG PDL VALUE SENS 2 GND PDL VALUE SENS 2 SIG PEDAL SENS PEDAL VALUE PEDAL VALUE SENS PMP CURRENT PORSCHE ACCESS SYSTEM PORSCHE COMMUNICATION MANAGEMENT POSITION 1/2 MEMORY SW POSITION ID POSITIONER 1 POSITIONER 2 POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER WINDOWS) PRESS SENS PRESSURE SENS + PRESSURE SENS DRV DOOR PRESSURE SENS PASS DOOR + PRESSURE SIG PRESSURE SIGNAL PRK BRK FUN PUMPING CURRENT PURGE FAN 1 PWM ACTUATION IN PWM ACTUATION INPUT PWM SIG PWR GND PWR RLY PWR SPLY RLY PWR WIND MTR 2 PWR WINDOW MTR 1 PWR WINDOW MTR 2 R H/L BEAM TERM 30 R HIGH BEAM R LOW BEAM R SIDE MARKER LIGHT R SIDE TURN/MARKER LT R STOP LIGHT RADIATOR FAN CTRL 1 RADIATOR FAN CTRL 2 RADIO HF RADITOR FAN CTRL 1 RADITOR FAN CTRL 2 RAISE SEAT RB DIAG REAR ALWR SENS IN 2 REAR BCM REAR FOG LIGHT REAR FOG LIGHT SW REAR LID REAR LID MICRO SW REAR OF LUGGAGE COMPT) REAR PWR WIND REAR SEAT HEIGHT ADJUSTMENT REAR SENS SIG REAR SIDE CLOSE FLAP MTR + REAR SIDE FLAP REAR SIDE OPEN FLAP MTR + REAR SPOILER EXTENSION REAR SPOILER FUNC LT REAR SPOILER RETRACTION REAR WDW REAR WINDOW HEATED REAR WINDOW MODULE REAR WINDOW WIPER REFRIGERANT PRSS SNSR REMOTE + RESONANCE FLAP RETRACT SPOILER REVERSING LIGHT RF DAYTIME RUNNING LT RF FOG LT RF HIGH BEAM RF LOW BEAM RF SHOCK ABSORBER + RF SIDE DIRECTION IND RF SIDE IND RF SIDE MARKER LIGHT RF SIDE MARKER LT RF SIDE TURN SIGNAL/MARKER LT RF TRIGGER MOD SUPPLY RF TURN SIG RF TURN SIGNAL RF TWEETER - RF VERTICAL SENS GND RF VERTICAL SENS SIGNAL RF VERTICAL SENS SUPPLY + RH HI BEAM 26 25 LH HI BEAM RH HIGH/LOW BEAM + RH LIN MTR RH LOW BEAM RH MIRROR FUNCTION RH MIRROR LED SELECTION RH MTR A RH MTR B RH REAR TURN SIG RH SEAT NTC RH SENS + RH SPLY MTR RH TERM 30 TURN SIGNAL RH UB+ CTRL RI LSP- WOOFER RI/LE SHUTTER LID RIGHT AIR VENT LIGHTING COCKPIT RIGHT ANTI-DAZZLE DOOR MIRROR RIGHT BRAKE LIGHT RIGHT COCKPIT AIR VENT LIGHTING RIGHT COOLING WATER BLOWER RIGHT COOLING WATER FAN RIGHT FAN RIGHT FOG LIGHT RIGHT FOOTWELL LIGHT RIGHT FRONT RIGHT FRONT BLUETOOTH CHARGING TRAY RIGHT FRONT BRAKE PAD WEAR IND RIGHT FRONT DOOR SILL LIGHTING RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT HEATED SPRAY JET RIGHT FRONT HIGH BEAM RIGHT FRONT LOW BEAM RIGHT FRONT SHOCK ABSORBER RIGHT FRONT SIDE MARKER LT RIGHT FRONT TPM TRIGGER MODULE RIGHT FRONT TRIGGER MODULE RIGHT FRONT TURN SIG LED RIGHT HEAD AIR BAG RIGHT HEAD- LIGHT RIGHT HEATED SPRAY JET RIGHT HEATED SPRAY JETS RIGHT HIGH BEAM RIGHT LOW BEAM RIGHT MAKE-UP LIGHT RIGHT MAKEUP MIRROR RIGHT MIRROR FUNCTION DSPLY RIGHT NUMBER PLATE LIGHT RIGHT RADIATOR FAN RIGHT REAR RIGHT REAR BRAKE PAD WEAR IND RIGHT REAR RR+ RIGHT REAR TPM TRIGGER MODULE RIGHT REAR TRIGGER MODULE RIGHT REAR TWEETER RIGHT REVERSING LIGHT RIGHT SEAT RIGHT SEAT NTC RIGHT SEAT TEMP SENS RIGHT SEAT THORAX AIR BAG RIGHT SEAT VENTILATION RIGHT SG LED TURN SIGNAL TOP RIGHT SIDE CUSHION BOLSTERS RIGHT SIDE HEATED BOLSTER RIGHT SIDE MARKER LIGHT RIGHT SIDE TURN SIGNAL RIGHT STEERING WHEEL REMOTE CONTROL RIGHT STOP LIGHT RIGHT TAIL LIGHT RIGHT TAIL LIGHT ASSEMBLY RIGHT TAILLIGHT RIGHT TAILLIGHT ASSEMBLY RIGHT TOP TURN SIGNAL LED RIGHT TURN SIG RIGHT VOLTAGE CONVERTER RIGHT XENON HEADLIGHTS RING BRAKE DIAGNOSIS RING BRK DIAGNOSIS RL LSP- WOOFER RL TRIGGER MODULE LIN BUS DATA RL TRIGGER MODULE LIN BUS GND RL TRIGGER MODULE LIN BUS SUPPLY RLY TERM 50 ROOF CONSOLE ROTARY LATCH RPM SENS 1 RPM SENS 2 RR DIR IND RR FOG LIGHT RR SHOCK ABSORBER + RR SPED SENS SIG INPUT RR TRIGGER MOD SUPPLY RR TRIGGER MODULE LIN BUS DATA RR TRIGGER MODULE LIN BUS GND RR TRIGGER MODULE LIN BUS SUPPLY RR TURN SIG RR TWEETER - RR WIND DEF RLY RT SEAT HTER RT SEAT TEMP RT SIDE VENT BLOWER SAT RADIO HF IN SCAVENGE BLOWER STAGE 2 SEAT ADJ SW BACKREST ADJ SEAT ADJ SW GROUND SEAT ADJUSTMENT SW ANGLE ADJUSTMENT SEAT ADJUSTMENT SW BACKREST ANGLE SEAT ADJUSTMENT SW HEIGHT ADJUSTMENT SEAT ANGLE ADJUSTMENT SEAT ANGLE ADJUSTMENT 1 SEAT ANGLE ADJUSTMENT 2 SEAT BACKREST ADJST SEAT BACKREST ADJUSTM 1 SEAT BACKREST ADJUSTM SW SEAT BACKREST ADJUSTMENT SEAT BACKREST ADJUSTMENT 2 SEAT CUSHION BOLSTER SEAT CUSHION DEPTH SEAT CUSHION SW SEAT CUSHION VENTILATION SEAT DEPTH ADJ SW SEAT DEPTH ADJUSTMENT SEAT DEPTH ADJUSTMENT 1 SEAT DEPTH ADJUSTMENT 2 SEAT FAN SEAT HEIGHT ADJUSTMENT SEAT HEIGHT ADJUSTMENT 1 SEAT HEIGHT ADJUSTMENT 2 SEAT RECLINE ADJUSTMENT PASSENGER SEAT SEAT WIDTH ADJUSTM SEAT) SEATS SYSTEM SELECTOR LEVER SELECTOR LEVER 1 SELECTOR LEVER 3 SELECTOR LEVER POSITION SELECTOR LEVER SUPPLY SELECTOR LEVER SW POS SELECTOR, LOCKED SENS 1 GND SENS 3 GND SENS GND SENS GND 2 SENS GROUND SENS R- SENS SIG SENS SIG FA SENS SIG RA SENSORS 1 GND SENSORS 2 GND SERIAL INTER FACE SERIAL INTERFACE SHIELD ANT 1 SHIELD ANT 2 SHIELD ANT 3 SHIFT INTERLOCK SYSTEM SHIFTLOCK - SHIFTLOCK GND SHUT-OFF VLV SHUTTER LID RI/LE SIDE MARKER LIGHT SIDE MARKER LT SW SIDE SENS FOR C-PILLAR DRV + SIDE SENS FOR C-PILLAR PASS + SIDE TAIL LIGHT SIGNAL 1 SIGNAL 2 SIGNAL 3 SIGNAL 4 SIGNAL ANT 2 SIGNAL ANT 3 SIGNAL FLI SIGNAL FLO SIGNAL FRI SIGNAL FRO SIGNAL RLI SIGNAL RLO SIGNAL RRI SIGNAL RRO SIGNAL SENS 1 SIGNAL SENS 2 SLIDING ROOF DRIVE SLIDING ROOF ENABLING SIG SNS GND SNSR GND SOL VLV 1 SOL VLV 2 SOLAR LT SOLAR RIGHT SOUND SYMPOSER - SOUND SYSTEMS SPD SENS SPEED SENDER SPLY POTENTIOMETER SPLY SENS 1 SPLY SENS 2 SPOILER EXTENDED MICRO SW SPOILER RETRACTED MICRO SW SPORT 2 FUNC LIGHT SPORT CHRONO SPORT MODE FUNC LIGHT SPRAY JETS ST INTERLOCK START REL P/N DOWN CLUTCH SW START RELEASE STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STATUS POS X STATUS POS Y STEERING COLUMN ADJUSTMENT STEERING COLUMN COMBINED MODULE STEERING COLUMN SWITCHING MODULE STEERING COLUMN W/ TIPTRONIC STEERING WHEEL ELECTRONICS STG 1 + STG 2 + STOP LIGHT STOP LIGHT SPOILER STOP LIGHT SW STOP WATCH SUN ROOF ENABLING SIGNAL SUN SENS SUP PROX SENS SUPPLEMENTAL RESTRAINTS SYSTEM SUPPLY ACTUATORS SUPPLY DRIVE LINK ELV SUPPLY SENS SW IN SW NVLD - SW OUT 6 SW OUT A SW OUT C SW OUT D SW OVER SWITCHED PLUS TAILGATE RELEASE TAILGATE SW TAILGATE UNLOCKING TANK COVER TANK COVER GROUND TANK COVER TERM 30 TANK LEAK DIAGN TANK LEAKAGE TANK LEAKAGE DIAGNOSTICS MODULE TANK VENT VLV TARGA LID TELEPHONE HAND SET TELEPHONE HANDSET TELEVISION TUNER TELEVISION TUNER SHIELD TEMP COMPT TEMP FLAP TEMP GND TEMP RADIATOR TEMP SENS TEMP SURFACE TEMP/OIL PRESSURE TEMPERATURE FLAP TER 15 TERM 15 TERM 15 ACTUATION LOW TERM 15 DIAGNOSIS TERM 15 EMERGENCE LIGHT TERM 15 HEATED SPRAY JETS TERM 15 IN DIAGNOSTICS TERM 15 START TERM 30 TERM 30 1 TERM 30 DAMPER TERM 30 ELECTRONICS TERM 30 LEFT TERM 30 LOAD TERM 30 MOTORS TERM 30 POWER WINDOW TERM 30 RIGHT TERM 30 SUPPLY TERM 30-2 TERM 30-3 TERM 31 TERM 31 CTRL SW TERM 31 GND TERM 31 MEM SAVE CTRL SW TERM 31 POWER MIRROR TERM 31 PROX SENS TERM 50 TERM 50 ACTUATION HIGH TERM 50 DIAGNOSIS TERM 50 DIAGNOSTICS TERM 58 TERM 58 D TERM 87 TERMINAL 15 TERMINAL 30 TERMINAL 31 TERMINAL ACTUATION LOW TERMINAL ORIENTATION LT THERMOSTAT MAP THORAX AIR BAG THORAX AIR BAG DRV SIDE - THORAX AIR BAG FR PASS SIDE + THRO VLV GND THROT VLV 1 THROT VLV MTR - THROTTLE VLV MTR + THROTTLE VLV SENS 1 THROTTLE VLV SENS 2 TO LEFT DOOR TO LEFT SEAT TO RIGHT DOOR TO RIGHT SEAT TOG MASSE TOP CHAMBER TPM DOWN TPM UP TRANSM OIL TEMP+ TRANSMISSION DISCONNECTION POINT 1 TRANSMISSION DISCONNECTION POINT 2 TRANSMISSIONS SYSTEM TREM 15 TRIGGER MODULE GND TRIGGER MODULE SIGNAL TRUNK ENTERTAINMENT TRUNK ENTERTAINMENT OPEN TRUNK ENTRAPMENT CLOSED TRUNK, TAILGATE, FUEL DOORS SYSTEM TT PDK DOWN TURN SIG TURN SIGNAL TV 1 TV 2 TV 3 TV TUNER TWO-TONE HORNS + U BAT ENG RLY U-ANT UBATT H+ UMS PCM UNLOCKING CATCH CONNECTION 1 UNLOCKING CATCH CONNECTION 2 UNLOCKING CATCH GROUND UNLOCKING LUGGAGE COMPT USED) VALUE SENS VERS AHBA VERTICAL ADJUSTMENT VERTICAL SENS GND VIDEO GND VIDEO SIG VIDEO SIGNAL VIDEO SIGNAL GND VOLLT RE+ W/ 475/352 030/031 W/ 475/352/030/031 W/ 618/619 W/ 665/695 W/ 669 W/ 676 W/ MEMORY W/ MEMORY SEAT W/ MULTIFUNCTION STEERING COLUMN MODULE W/ TELEVISION TUNER W/ TIPTRONIC STEERING COLUMN MODULE W/ XES W/ XES W/O XES W/O 475/352 030/031 W/O 475/352/030/031 W/O BOSE W/O MEMORY W/O MSW W/O XES WAKE UP CLUSTER/PCM WAKE-UP WAKE-UP LINE WASHER FLUID LEVEL WASHER FLUID LVL WASHER FLUID RESERVOIR) WASHING FLUID LEVEL WATER TEMP WDW DISPLAY REAR OVER WIND DEFLECTOR HALL SNS RIGHT HOOD COMP LID CLOSED HALL SNS WIND DFLTR RAISD HLL SNS WINDOW CODED WINDOW LE WINDOW RI WINDSHIELD WIPER MTR WIPER MTR BRAKE STREAM GND WIPER/WASHER SYSTEM ZV CLOSE/OPEN KEY SW ZV CLOSE/UP KEY ZV DAY TERM 31 ZV FUNCTION IND ZV OUTSIDE DOOR HANDLE ZV ROTARY CATCH ZV TERM 31 ZV TURN CASE
