Porsche 718 Cayman 982 (2016-2024) Computer data lines circuit

ACC CONTROL UNIT ALARM SIREN ANTI-DAZZLE INTERIOR MIRROR BATTERY SENSOR BLK WIRE BRN/WHT WIRE CAN CHASSIS HIGH CAN CHASSIS LOW CAN COMFORT HIGH CAN COMFORT LOW CAN CRASH HIGH CAN CRASH LOW CAN DIAGNOSTICS HIGH CAN DIAGNOSTICS LOW CAN DISTRIBUTOR CAN DRIVE HIGH CAN DRIVE LOW CAN HIGH CAN LOW CAN MMI HIGH CAN MMI LOW CHASSIS HIGH CHASSIS LOW CLUTCH SENSOR COMFORT HIGH COMFORT LOW CONVERTIBLE TOP CONTROL UNIT DC/DC CONVERTER DRIVER'S DOOR CONTROL UNIT DRIVER'S SEAT CONTROL UNIT (UNDER DRIVER'S SEAT) ELECTRICAL STEERING GEAR ELECTRONIC IGNITION LOCK (ON STEERING COLUMN) EPB CONTROL UNIT FRONT BCM (LEFT END OF DASH) FRONT CAMERA CONTROL UNIT FRONT PASSENGER DOOR CONTROL UNIT FRONT PASSENGER SEAT CONTROL UNIT (UNDER FRONT PASSENGER SEAT) FRONT WIPER MOTOR FUSE 1 FUSE 4 GATEWAY CONTROL UNIT (LEFT SIDE OF DASH) GENERATOR GRN/BLK WIRE HOME LINK CONTROL HOT AT ALL TIMES HOT W/ KL 15 RELAY ENERGIZED INTERIOR SURVEILLANCE SENSOR LEFT FRONT FUSE BOX (ROW C) LEFT FRONT FUSE BOX (ROW D) LEFT HEADLIGHT LIN 1 LIN 2 LIN 3 LIN MAIN FUSE BOX MAIN FUSE BOX NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/RED WIRE ORG/VIO WIRE PASM CONTROL UNIT PSM CONTROL UNIT RAIN SENSOR REAR BCM (UNDER DRIVER'S SEAT) RED/YEL WIRE RIGHT END OF DASH) RIGHT HEADLIGHT ROOF CONSOLE ROTARY LIGHT SWITCH STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN LOCK (ON STEERING COLUMN) STEERING COLUMN SWITCHING MODULE TERM 15 TERM 30 TERM 31 VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/YEL WIRE W/O LED

2 HIGH 2 LOW A/C CONTROL UNIT ACL (PWM) AIR BAG CONTROL UNIT BACKUP CAMERA (IF EQUIPPED) (CENTER REAR OF VEHICLE) BLU/GRY WIRE BRN/WHT WIRE CAN DRIVE HIGH CAN DRIVE LOW CAN EXTENDED HI CAN EXTENDED HIGH CAN EXTENDED LO CAN EXTENDED LOW CAN HI CAN HIGH CAN INFO HIGH CAN INFO LOW CAN LO CAN LOW CAN MMI HIGH CAN MMI LOW CAN PRIVATE DIAGNOSTIC PLUG SOCKET DISPOSAL LINE DME CONTROL UNIT ENGINE SOUND GENERATOR CONTROL UNIT 2 FUSE 9 HIGH CENTRAL PROCESSOR HOT AT ALL TIMES INSTRUMENT CLUSTER KL 30 LEFT HEADLIGHT LEFT LANE CHANGE ASSISTANT ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/VIO WIRE PARK ASSIST CONTROL UNIT (IF EQUIPPED) (UNDER LEFT SEAT) PDK CONTROL UNIT RDK CONTROL UNIT RED/YEL WIRE RIGHT FRONT FUSE BOX (ROW B) RIGHT HEADLIGHT RIGHT LANE CHANGE ASSISTANT SEAT OCCUPANCY DETECTION CONTROL UNIT SELECTOR LEVER CONTROL UNIT SG HEADLIGHT STOPWATCH VIO WIRE VIO/WHT WIRE W/ BACKUP CAMERA W/ LED W/ PARKING ASSISTANT WLAN CONTROL UNIT
